MODELS:
HBDV300 & HBDV400
WARNINGS
IF THE INFORMATION IN THESE INSTRUCTIONS ARE
NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE,
PERSONAL INJURY OR LOSS OF LIFE.
–
Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
–
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fi re department.
–
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
WARNING: Improper installation, adjustment,
alteration, services or maintenance can cause injury or
property damage. Refer to this manual. For assistance
or additional information consult a qualifi ed installer,
service agency or the gas supplier.
This appliance may be installed in an aftermarket*,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certifi ed kit is used.
* Aftermarket: Completion of sale, not for purpose of resale,
from the manufacturer.
READ BEFORE INSTALLING. SAVE THESE INSTRUCTIONS
HBDV SERIES
DIRECT VENT
GAS FIREPLACE
INSTALLATION AND
OPERATING INSTRUCTIONS
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
CHILDREN AND ADULTS SHOULD
BE ALERTED TO THE HAZARDS OF
HIGH SURFACE TEMPERATURE AND
SHOULD STAY AWAY TO AVOID BURNS
OR CLOTHING IGNITION.
Y O U N G C H I L D R E N S H O U L D B E
SUPERVISED WHEN THEY ARE IN THE
SAME ROOM AS THE APPLIANCE.
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED ON
OR NEAR THE APPLIANCE.
KEEP THE ROOM AREA CLEAR AND
FREE FROM COMBUSTIBLE MATERIALS,
GASOLINE, AND OTHER FLAMMABLE
VAPORS AND LIQUIDS.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Direct Vent Gas Fireplace HBDV300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Monessen Hearth Direct Vent Gas Fireplace HBDV300

Summary of Contents for Monessen Hearth Direct Vent Gas Fireplace HBDV300

  • Page 1 MODELS: HBDV300 & HBDV400 WARNINGS IF THE INFORMATION IN THESE INSTRUCTIONS ARE NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. – Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: Table Of Contents

    CONTENTS Important Safety Information ... 3 Product Features ... 5 Code Approval ... 5 Pre-Installation Information ... 6–9 High Elevation Installation ... 6 Orifi ce Sizes, Pressures and BTUs ... 6 Before You Start ... 6 Fireplace Framing ... 7 Fireplace Dimensions...

  • Page 3: Important Safety Information

    INSTALLER Please leave these instructions with the appliance. • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fi replace. • Any change to this fi replace or its controls can be dangerous. • Improper installation or use of this fi replace can cause serious injury or death from fi...
  • Page 4 IMPORTANT SAFETY INFORMATION Continued from page 3 12. Do not use this fireplace to cook food or burn paper or other objects. 13. Never place anything on top of fireplace. 14. Do not use any solid fuels (wood, coal, paper, cardboard, etc.) in this fireplace.

  • Page 5: Product Specifications

    PRODUCT SPECIFICATIONS • This appliance has been certi- fied for use with either natural or propane gas. See appropriate data plates. • This appliance is not for use with solid fuels. • The appliance is approved for bedroom or bedsitting room installations.

  • Page 6: Pre-Installation Information

    PRE-INSTALLATION INFORMATION HIGH ELEVATIONS Input ratings are showin in BTU per hour adn are certified without deration for elevations up to 4,500 feet (1,370m) above sea level. For elevations above 4,500 feet (1,370m) in USA, installations must be in accordance with the current ANSI Z223.1/NFPA 54 and/or local codes having jurisdiction.

  • Page 7: Fireplace Framing

    FIREPLACE FRAMING Firebox framing can be built before or after the appliance is set in place. Construct firebox framing following Figure 2 and the chart below for your specific installation requirements. See Figure 3 on Page 8 for firebox dimensions. The framing headers may rest on the top of the firebox standoffs.

  • Page 8: Fireplace Dimensions

    PRE-INSTALLATION INFORMATION DESCRIPTION Letter Overall Front Width Inside Width Glass Width CTR Pipe Rear L/R Rear Width Glass Height Total Height Depth Figure 3 - Fireplace Dimensions HBDV300 HBDV400 DESCRIPTION " " Height to Standoffs " 32" CTR Pipe Height Rear 27"...

  • Page 9: Pre-Installation Information

    FIREPLACE LOCATION Plan for the installation of your appliance. This includes determining where the unit is to be installed, the vent configuration to be used, framing and finishing details, and whether any optional accessories (i.e. blower, wall switch, or remote control) are desired.

  • Page 10: Clearances

    CLEARANCES CLEARANCES TO COMBUSTIBLES Follow these instructions carefully to ensure safe installation. Failure to follow in struc tions exactly can create a fi re hazard. The appliance cannot be installed on a carpet, tile or other combustible material other than wood fl ooring. If installed on carpet or vinyl fl ooring, the appliance shall be installed on a metal, wood or noncombustible material panel ex tend ing full width and depth of the appliance.

  • Page 11: Securing Fireplace To Floor Or Framing

    SECURING FIREPLACE TO FLOOR OR FRAMING The fireplace must be secured to the floor and/or to framing studs as shown in Figure 5. Use two (2) wood screws or masonry/ concrete screws to secure fireplace to the floor. Use four (4) screws to attach fireplace to framing. The side nailing flanges are 1/2"...

  • Page 12: Installation Information

    INSTALLATION INFORMATION FINISHING MATERIAL NOTE: Any remote wiring (i.e. remote control, wall switch, and optional fan) must be done prior to fi nal fi nishing to avoid costly reconstruction. Never obstruct or modify the air inlet or outlet grills (louvers). This may create a fi...

  • Page 13: Vent Installation

    This fireplace must be vented to the outside. The venting system must NEVER be attached to a chimney serving a separate solid fuel burning appliance. Each gas appliance must use a separate vent system. Do not use common vent systems. Horizontal sections of this vent system require a minimum of 3"...

  • Page 14: Optional Top Vent Application

    VENT INSTALLATION OPTIONAL TOP VENT APPLICATION The appliance is shipped as a rear vent unit. If the installation layout requires the unit to be a top vent configuration the appliance can be converted by following the steps below. NOTE: REMOVE AND DISCARD TOP BOX AND INSULATION ON TOP OF THE UNIT BETWEEN THE STAND-OFFS.

  • Page 15: Installation Planning

    INSTALLATION PLANNING There are two basic types of direct-vent installation: • Horizontal Termination • Vertical Termination It is important to select the proper length of vent pipe for the type of termination you choose. It is also important to note the wall thickness.
  • Page 16 VENT INSTALLATION FOR HORIZONTAL TERMINATION Vent Terminal Figure 12 - Horizontal Vent Termination Location MINIMUM DISTANCES A = Clearance above the grade, a veranda, porch, deck, or balcony [*12" (305mm) minimum]. B = Clearance to window or door that may be opened [*12" (305mm) minimum]. C = Clearance to permanently closed window [*minimum 12"...
  • Page 17 TERMINATION CLEARANCES FOR BUILDINGS WITH COMBUSTIBLE AND NONCOMBUSTIBLE EXTERIORS G=6" (152mm) Inside Corner G = Combustible 24"(610mm) Noncombustible 18"(457mm) Balcony with No Side Wall HOW TO USE THE VENT GRAPH The Vent Graph should be read in conjunction with the following vent installation instructions to determine the relationship between the vertical and horizontal dimensions of the vent system.

  • Page 18: Venting Installation

    VENTING INSTALLATION REAR (THROUGH THE WALL) APPLICATIONS When installed as a rear vent unit this appliance may be vented directly to a termination located on the rear wall behind the appliance • The maximum horizontal distance between the rear of the appliance and the outside of termination is 20" (508 m). See Figure 15.
  • Page 19 REAR WALL VENT INSTALLATION (continued) 4. Apply a bead of non-hardening mastic around the outside edge of vent cap. Position the vent cap in the center of hole on the exterior wall with the word “HOT” on the vent cap facing up.

  • Page 20: Horizontal Termination Configurations

    VENT INSTALLATION HORIZONTAL TERMINATION CONFIGURATIONS Since it is very important that the venting system maintain its balance between the combustion air intake and the flue gas exhaust, certain limitations as to vent configurations apply and must be strictly adhered to. The Vent Graph, showing the relationship between vertical and horizontal side wall venting, will help to determine the vari- ous dimensions allowable.

  • Page 21: Horizontal Termination Configuration

    HORIZONTAL TERMINATION CONFIGURATION (Continued) • If a 90° elbow is used in the horizontal vent run (level height maintained) the horizontal vent length is reduced by 36". See Figures 21 and 22, page 20. This does not apply if the 90°...

  • Page 22: Below Grade Installations

    VENT INSTALLATION BELOW GRADE INSTALLATIONS When it is not possible to meet the required vent terminal clearances of 12" above grade level, a snorkel kit is recommended. It allows installation depth down to 7" (178mm) below grade level. The 7" (178mm) is measured from the center of the horizontal vent pipe as it penetrates through the wall.

  • Page 23: Vertical (Through-The-Roof) Applications

    VERTICAL (THROUGH-THE-ROOF) APPLICATIONS This Gas Fireplace has been approved for, • Vertical installations up to 40' (12m) in height. Up to a 10' (3m) horizontal vent run can be installed within the vent system using a maximum of two 90° elbows. See Figure 28. NOTE: Horizontal sections of this vent system require a minimum of 3"...

  • Page 24: Installation For Vertical Termination

    VENT INSTALLATION INSTALLATION FOR VERTICAL TERMINATION 1. Determine the route your vertical venting will take. If ceiling joist, roof rafters or other framing will obstruct the venting system, consider an offset. See Figure 30 to avoid cutting load bearing members. For optimal flame appearance, a restrictor disk is necessary on straight vertical runs of 20' of more.
  • Page 25 3. Cut a hole in the roof using the locating hole as a center point. (Cover any exposed open vent pipes before cutting hole 1/ 2 in roof). The 9 "x9 " (241mm x 241mm) hole must be measured on the horizontal. Actual length may be larger depending on the pitch of the roof.

  • Page 26: Flex Vent Installation

    FLEX VENT INSTALLATION 1. Flexible UL1777 listed venting may be used in any venting application where rigid direct vent components can be used. All restrictions, clearances and allowances that pertain to the rigid piping apply to the fl exible venting. Flex kits may not be modifi...
  • Page 27 3. Do not allow the fl exible vent to bend in radius tighter than 5" (127mm). Refer to Figure 2. 4. Horizontal runs of fl exible vent shall be supported at maximum 2 foot intervals; vertical runs, fi ve feet intervals.

  • Page 28: Fireplace Installation

    FIREPLACE INSTALLATION CHECK GAS TYPE Use proper gas type for the fireplace you are installing. If you have conflicting gas type, do not install fireplace. See dealer where you purchased the fireplace for proper fireplace for your gas type or conversion kit. INSTALLING GAS PIPING TO FIREPLACE / BURNER SYSTEM LOCATION INSTALLATION ITEMS NEEDED Before installing fireplace and burner system, make sure you have the items listed below.
  • Page 29 Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. NOTE : The gas line connection may be made using some municipalities have additional local codes it is always best to consult your local authorities and the current edition of the National Fuel Gas Code ANSI.Z223.1, NFPA54.

  • Page 30: Checking Gas Pressure

    CHECKING GAS PRES SURE 1. Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, STOP! Do not install the appliance. Contact your dealer immediately. 2.

  • Page 31: Remote Wall Mounted Switch

    REMOTE WALL MOUNTED SWITCH A remote wall switch and up to fifteen (15) feet of 18 gauge wire may be used with this appliance. Attach the wall switch in a junction box at the desired location on the wall. See Figure 42. Do not extend beyond the wall switch wire length provided.

  • Page 32: Glass Removal & Brick Installation

    GLASS REMOVAL & BRICK INSTALLATION GLASS FRAME REMOVAL 1. Release two clamps on bottom of fireplace. See Figure 44. 2. Tilt glass frame out and lift glass frame up until it clears three tabs on top of fireplace. 3. Set glass frame aside. Glass Frame Figure 44 - Removing Glass Frame CAUTION: Each clamp has a quick spring force.

  • Page 33: Final Installation

    PLACEMENT OF LAVA ROCK, ROCK WOOL AND LOGS 1. Make sure that the grate is hooked onto the rear bracket. 2. Sprinkle the lava rocks around and in front of the burner at bottom of firebox. 3. Place rock wool in a dime size pieces over the small holes and partially over large size holes.
  • Page 34 FINAL INSTALLATION Figure 48 - Placement of Log 2 6a. For 400 models, place log #3 into place by matching the notch on the side of the log with the protrusion on the rear log. Set the left side of the log over the cross bar of grate by placing the notch of the log on the grate bar. Be sure the log is tilted backward.

  • Page 35: Final Installation

    FINAL INSTALLATION Log #6 Log #7 Figure 53 - Placement of Log 7 (HBDV400 only). Figure 52 - Placement of Log 6 Figure 54 a & b - Andiron Placement (400DVBH and 300DVBH). INSTALLING UNIVERSAL ANDIRONS Bolt bracket through lower slot into top andiron hole. Slide clip over horizontal fi replace grate bar. See Figure 55. Top andiron hole Top bracket slot Lower andiron hole...

  • Page 36: Operating Instructions (Millivolt)

    OPERATING INSTRUCTIONS (MILLIVOLT) FOR YOUR SAFETY READ BEFORE LIGHTING A. This appliance is equipped with a pilot which must be lit with built-in piezo ignitor while following these instructions exactly. B. BEFORE OPERATING smell all around the appliance area for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.

  • Page 37: Lighting Millivolt Pilot For The First Time

    LIGHTING PILOT FOR THE FIRST TIME APPROVED LEAK TESTING METHOD You may check for gas leaks with the following methods only: • Soap and water solution • An approved leak testing spray • Electronic sniffer Never check for gas leak with open fl ame! Check for gas leaks in each of the following locations: •...

  • Page 38: Lighting The Burner

    OPERATING INSTRUCTIONS (MILLIVOLT) MAIN BURNER SWITCH The “ON/OFF/RS” switch for the main burner can be found behind door of the fireplace. This switch allows you to turn on and to turn off the main burner without using the gas valve knob. Make sure the button is in the “ON” position to light the main burner.

  • Page 39: Cleaning And Maintenance

    Turn off gas before servicing fi replace. It is recommended that a qualifi ed service technician perform these check-ups at the beginning of each heating season BURNER, PILOT AND CONTROL COMPARTMENT Keep the control compartment, logs, and burner areas surrounding the logs clean by vacuuming or brushing at least twice a year.

  • Page 40: Vent System

    CLEANING AND MAINTENANCE VENT SYSTEM The fireplace and venting system should be inspected before initial use and at least annually by a qualified field service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the airflow. Inspect entire venting system to ensure proper function.

  • Page 41: Standing Pilot Ignition

    STANDING PILOT IGNITION SYMPTOM POSSIBLE CAUSE 1. Spark ignitor will A. Wire disconnected. not light pilot after repeated triggering of B. Defective ignitor. piezo. C. No gas or low gas pressure. D. No Propane/LPG in tank 2. Pilot will not stay lit A.
  • Page 42 TROUBLESHOOTING STANDING PILOT IGNITION SYMPTOM POSSIBLE CAUSE 4. Frequent pilot outage A. Pilot flame may be too high or problem. too low, causing pilot safety to drop out 5. The pilot and main A. Inner vent pipe leaking burner extinguish exhaust gases back into while in operation system...

  • Page 43: Fireplace Components

    REPLACEMENT PARTS FIREPLACE COMPONENTS 54D5031...
  • Page 44 REPLACEMENT PARTS FIREPLACE COMPONENTS Item Description Standard Features Junction Box Assembly Black Louver (each) Glass Frame Assembly Andiron Kit (contains 2) Accessories/Field Installed Options Brass Louver Assembly (upper and lower) Pewter Louver Assembly (upper and lower) Thermostat Sensor Standard Firebrick Center CC Standard Firebrick Right CC Standard Firebrick Left CC Standard Firebrick Center CR...

  • Page 45: Millivolt Engine Components

    REPLACEMENT PARTS MILLIVOLT ENGINE 8A (HBDV400) 8B (HBDV300) 11, 12, 13, 14, 15 54D5031...

  • Page 46: Vent Components

    REPLACEMENT PARTS MILLIVOLT COMPONENTS ITEM DESCRIPTION Gas Valve Assembly Pilot Assembly 2C Replacement Thermocouple Replacement Igniter and Wire Replacement Thermopile Burner Tube Flexhose with Shutoff Valve Rocker Switch Piezo Igniter Injector Burner Assembly Venturi Wire Assembly Wire Assembly ACCESSORIES Thermostatic Remote Control Remote Control On/Off...

  • Page 47: Vent Components

    VENT COMPONENTS CONTINUED Refer to illustrations on previous page. QTY/ ITEM DESCRIPTION Rear Vent Termination Kit includes Termination Cap with built in vinyl siding standoff, heat defl ector, fi restop and adj 11" to 14 5/8" pipe. Side Wall Termination Kit. Includes termination cap with built in vinyl siding standoff, heat defl...

  • Page 48: Replacement Parts

    REPLACEMENT PARTS LOGS Item Description Rear Log Right Log Left Log Mid Top Log Right Top Log Left Front Log Right Front Twig HBDV300 HBDV400 54D5119 54D5023 54D5120 54D5024 54D5121 54D5025 54D5123 54D5026 54D5122 54D5027 54D5124 54D5028 54D5029 54D5031...

  • Page 49: Massachusetts Residents Only

    MASSACHUSETTS RESIDENTS ONLY: NOTES PLEASE READ AND FOLLOW THESE SPECIAL REQUIREMENTS NOTE REGARDING VENTED PRODUCTS This product must be installed by a licensed plumber or gas fi tter when installed within the Commonwealth of Massachu- setts. Any residence with a direct vent product must have a CO detector installed in the residence. Installation of the fi...
  • Page 50 SPECIAL REQUIREMENTS CONTINUED 2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certifi ed. 3. SIGNAGE. A metal or plastic identifi cation plate shall be permanently mounted to the exterior of the building at a minimum height of eight (8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment.
  • Page 51 NOTES 54D5031...
  • Page 52 NOTES 54D5031...
  • Page 53 NOTES 54D5031...

  • Page 54: Technical Services

    BASIC WARRANTY Monessen Hearth Systems (MHS) warrants the components and materials in your gas appliance to be free from manufacturing and material defects for a period of two years from date of installation. After installation, if any of the components manu- factured by MHS in the appliance are found to be defective in materials or workmanship, MHS will, at its option, replace or repair the defective components at no charge to the original owner.
