White Mountain Hearth ROCK CREEK LSU18RR-2 Installation Instructions And Owner's Manual

Log set for vented and unvented multi-sided gas log heate
Hide thumbs Also See for ROCK CREEK LSU18RR-2:

Advertisement

The White Mountain Log Collection:
ROCK CREEK
wArNING: If the information in these in-
structions are not followed exactly, a fire or ex-
plosion may result causing property damage,
personal injury or loss of life.
— Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
— wHAT TO DO IF YOu SMeLL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not
use any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
INSTALLATION INSTrucTIONS
AND OwNer'S MANuAL
LSU18RR-2 SHOWN
LOG SeT FOr
VeNTeD AND uNVeNTeD
MuLTI-SIDeD GAS LOG HeATer
MODeLS
LSu18rr-2
LSu24rr-2
LSu30rr-2
Installer: Leave this manual with the appli-
ance.
consumer: retain this manual for future refer-
ence.
Log sets comply with ANSI Z21.11.2 unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid Fuel
Burning Fireplaces. State or local codes may only
allow operation of log sets in a vented configuration.
check your state or local codes.
wArNING: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to
substances in fuel or from fuel combustion which
can cause death or serious illness.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROCK CREEK LSU18RR-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for White Mountain Hearth ROCK CREEK LSU18RR-2

  • Page 1 MuLTI-SIDeD GAS LOG HeATer MODeLS LSu18rr-2 LSu24rr-2 LSu30rr-2 LSU18RR-2 SHOWN wArNING: If the information in these in- structions are not followed exactly, a fire or ex- plosion may result causing property damage, personal injury or loss of life. Installer: Leave this manual with the appli- ance.
  • Page 2: Table Of Contents

    General Information ..................... 3 Requirements for Canada ..................4 Log Placement ....................5-6 Ember Placement....................7 Ember Placement LSU18RR-2 Photos ..............8 Ember Placement LSU24RR-2 Photos ..............9 Ember Placement LSU30RR-2 Photos .............. 10 Parts List & Parts View ..................11 Master Parts Distributor List ................
  • Page 3: Important Installation Guidelines

    IMPORTANT INSTALLATION GUIDELINES Proper Log Placement wArNING: Do not allow fans to blow directly into the fireplace. Log placement is critical to proper burner performance. Logs must Avoid any drafts that alter burner flame patterns. be correctly positioned onto the burner. The photos in this manual wArNING: Do not use a blower insert, heat exchanger insert or show the proper pinned position for logs on this set.
  • Page 4: Requirements For Canada

    reQuIreMeNTS FOr cANADA WARNING; DO NOT OPERATE THIS GAS LOG SET This unit cannot be installed in a UNVENTED application, this wITH GLASS DOOrS cLOSeD unit can only be installed as a VENTED application with these requirements. • Clothing or other flammable material should not be placed on or near the appliance.
  • Page 5: Log Placement

    LOG PLACEMENT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are not properly and firmly positioned in the appliance.
  • Page 6: Log Placement

    Attention: Do not use Figures 1 to 3 to order replacement logs. Refer to Page 11, Parts List and Parts View to order logs for your appropriate model number. Log Placement LSu18rr-2 Logs and Burner Shown Figure 4 Page 6...
  • Page 7: Ember Placement

    EMBER PLACEMENT Apply loose material (glowing embers) with the appropriate ember placement photos on pages 8 through 10. Replacement of loose material (glowing embers) must be purchased from Empire Comfort Systems, Inc. Application of excess loose material (glowing embers) may adversely affect performance of the heater.
  • Page 8: Ember Placement Lsu18Rr-2 Photos

    EMBER PLACEMENT LSU18RR-2 PHOTOS FRONT (VALVE SIDE) REAR Some logs have been removed for clarity Do not cover any large ports with loose material (glowing embers) REAR FRONT (VALVE SIDE) Page 8 25742-0-0309...
  • Page 9: Ember Placement Lsu24Rr-2 Photos

    EMBER PLACEMENT LSU24RR-2 PHOTOS FRONT (VALVE SIDE) REAR Some logs have been removed for clarity Do not cover any large ports with loose material (glowing embers) REAR FRONT (VALVE SIDE) 25742-0-0309 Page 9...
  • Page 10: Ember Placement Lsu30Rr-2 Photos

    EMBER PLACEMENT LSU30RR-2 PHOTOS FRONT (VALVE SIDE) REAR Some logs have been removed for clarity Do not cover any large ports with loose material (glowing embers) REAR FRONT (VALVE SIDE) Page 10 25742-0-0309...
  • Page 11: Parts List & Parts View

    PARTS LIST & PARTS VIEW Attention: When ordering parts, it is very important that part number and description of part coincide. Index No. Part Number Part Number Part Number LSu18rr-2 LSu24rr-2 LSu30rr-2 Description R9312 R9323 R9329 BACK RIGHT LOG R9313...
  • Page 12: Master Parts Distributor List

    MASTer PArTS DISTrIBuTOr LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit.
  • Page 13: Notes

    SerVIce NOTeS 25742-0-0309 Page 13...
  • Page 14 SerVIce NOTeS Page 14 25742-0-0309...
  • Page 15 SerVIce NOTeS 25742-0-0309 Page 15...
  • Page 16 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com Page 16 25742-0-0309...
