PONDEROSA
wArNINg: If the information in these in-
structions are not followed exactly, a fire or ex-
plosion may result causing property damage,
personal injury or loss of life.
— Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
— wHAT TO DO If YOu SMeLL gAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from
a neighbor's phone. follow the gas sup-
plier's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
INSTALLATION INSTrucTIONS
AND OwNer'S MANuAL
LOg SeT fOr uNVeNTeD
gAS LOg HeATer
VeNTeD DecOrATIVe APPLIANce
MODeLS
LS-18P-2
LS-24P-1
LS-30P-1
Installer: Leave this manual with the appli-
ance.
consumer: retain this manual for future refer-
ence.
Log sets comply with ANSI Z21.11.2 unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid fuel
Burning fireplaces. State or local codes may only
allow operation of log sets in a vented configuration.
check your state or local codes.
wArNINg: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to sub-
stances in fuel or from fuel combustion which can
cause death or serious illness.
Or
Page 1
Advertisement
Table of Contents
Related Manuals for White Mountain Hearth PONDEROSA LS-18P-2
Summary of Contents for White Mountain Hearth PONDEROSA LS-18P-2
- Page 1 The White Mountain Log Collection PONDEROSA LOg SeT fOr uNVeNTeD gAS LOg HeATer VeNTeD DecOrATIVe APPLIANce MODeLS LS-18P-2 LS-24P-1 LS-30P-1 wArNINg: If the information in these in- structions are not followed exactly, a fire or ex- plosion may result causing property damage, Installer: Leave this manual with the appli- personal injury or loss of life.
-
Page 2: Table Of Contents
Important Installation Guidelines ................. 3 General Information ..................... 3 Requirements for Canada ..................4 Log Placement ....................5-7 LS-18P-2 Photos ....................8 LS-24P-1 Photos ....................9 LS-30P-1 Photos ....................10 Parts List & Parts View ..................11 Master Parts Distributor List ................12 How to Order Repair Parts ................. -
Page 3: Important Installation Guidelines
IMPORTANT INSTALLATION GUIDELINES Proper Log Placement wArNINg: Do not allow fans to blow directly into the fireplace. Log placement is critical to proper burner performance. Logs Avoid any drafts that alter burner flame patterns. must be correctly positioned onto the burner. The photos in this wArNINg: Do not use a blower insert, heat exchanger insert or manual show the proper pinned position for logs on this set. -
Page 4: Requirements For Canada
reQuIreMeNTS fOr cANADA WARNING; DO NOT OPERATE THIS GAS LOG SET This unit cannot be installed in a UNVENTED application, this wITH gLASS DOOrS cLOSeD unit can only be installed as a VENTED application with these requirements. • Clothing or other flammable material should not be placed on or near the appliance. -
Page 5: Log Placement
LOG PLACEMENT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are not properly and firmly positioned in the appliance. - Page 6 LOG PLACEMENT 8. Insert boss on upper middle right (H) log into recess on middle right (G) log and on front grate bar 9. Place recess in middle center (I) log onto boss on rear center (E) log and resting on front left (A) log. 10.
-
Page 7: Log Placement
LOG PLACEMENT Apply loose material (glowing embers) per appropriate Installation Instructions and Owner's Manual. Replacement of loose material (glowing embers) must be purchased from Empire Comfort Systems, Inc. Application of excess loose material (glowing embers) may adversely affect performance of the heater. WARNING: All previously applied loose material must be removed prior to reapplication. -
Page 8: Ls-18P-2 Photos
EMBER PLACEMENT LS-18P-2 PHOTOS Page 8 25739-0-0309... -
Page 9: Ls-24P-1 Photos
EMBER PLACEMENT LS-24P-1 PHOTOS 25739-0-0309 Page 9... -
Page 10: Ls-30P-1 Photos
EMBER PLACEMENT LS-30P-1 PHOTOS Page 10 25739-0-0309... -
Page 11: Parts List & Parts View
PARTS LIST & PARTS VIEW Attention: When ordering parts, it is very important that part number and description of part coincide. Index No. Part Number Part Number Part Number LS-18P-2 LS-24P-1 LS-30P-1 Description R-8361 R-8368 Front Left Log R-8353 R-8775... -
Page 12: Master Parts Distributor List
For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Star-fire Distributors... -
Page 13: Notes
SerVIce NOTeS 25739-0-0309 Page 13... - Page 14 SerVIce NOTeS Page 14 25739-0-0309...
- Page 15 SerVIce NOTeS 25739-0-0309 Page 15...
- Page 16 Empire Comfort Systems Inc. EMPIRE EMPIRE 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com...
