The White Mountain Log Collection
Canyon
WARNING: If the information in these in-
plosion may result causing property damage,
personal injury or loss of life.
ble vapors and liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL GAS
use any phone in your building.
a neighbor's phone. Follow the gas sup-
plier's instructions.
— Installation and service must be performed
gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
-
-
LOG SET FOR UNVENTED
GAS LOG HEATER
VENTED DECORATIVE APPLIANCE
MODELS
LX-24CF-1
LX-30CF-1
Installer: Leave this manual with the appli-
ance.
Consumer: Retain this manual for future refer-
ence.
Log sets comply with ANSI Z21.11.2 Unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid Fuel
Burning Fireplaces. State or local codes may only
Check your state or local codes.
WARNING: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to sub-
stances in fuel or from fuel combustion which can
cause death or serious illness.
OR
Page 1
Advertisement
Table of Contents
Related Manuals for White Mountain Hearth Canyon LX-24CF-1
Summary of Contents for White Mountain Hearth Canyon LX-24CF-1
- Page 1 INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL The White Mountain Log Collection LOG SET FOR UNVENTED Canyon GAS LOG HEATER VENTED DECORATIVE APPLIANCE MODELS LX-24CF-1 LX-30CF-1 WARNING: If the information in these in- Installer: Leave this manual with the appli- ance. plosion may result causing property damage, Consumer: Retain this manual for future refer- personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Section Page Important Installation Guidelines ................ 3 General Information .................... 3 Requirements for Canada ..................4 Parts List & Parts View ..................5 Log Placement ....................6 - 13 Placement of Glowing Embers LX-(24,30)CF-1 ........14 - 16 Master Parts Distributor List ................17 How To Order Repair Parts ................ -
Page 3: Important Installation Guidelines
IMPORTANT INSTALLATION GUIDELINES Proper Log Placement Log placement is critical to proper burner performance. Logs must log and create a sooting situation. be correctly positioned onto the burner. The photos in this manual WARNING: show the proper pinned position for logs on this set. Owners need to be shown proper log placement and instructed not to move the logs. -
Page 4: Requirements For Canada
REQUIREMENTS FOR CANADA This unit cannot be installed in an UNVENTED application, this unit can only be installed as a VENTED application with these WITH GLASS DOORS CLOSED requirements. IMPORTANT SAFETY INFORMATION or near the appliance. This unit complies with ANSI Z21.60and CGA 2.26 Decorative eration. -
Page 5: Parts List & Parts View
PARTS LIST & PARTS VIEW Attention: When ordering parts, it is very important that part number and description of part coincide. LX-(24,30)CF-1 INDEX INDEX TOP VIEW FRONT VIEW Part No. Index No. Description LX-24CF-1 LX-30CF-1 R10457 R10472 Center Log R10458 R10473 Right Middle Log R10461... -
Page 6: Log Placement
LOG PLACEMENT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are Refer to Figure 1 for the following warning. - Page 7 LOG PLACEMENT FRONT VIEW TOP VIEW R10576-0-0110 Page 7...
- Page 8 LOG PLACEMENT Place Right Middle Log (B) in gap between burner bottom and rear log support. The large end of the log is on the right. The curve FRONT VIEW TOP VIEW Page 8 R10576-0-0110...
- Page 9 LOG PLACEMENT Place Right Rear Log (C) on right pin (3) on rear log shelf. The knob on the log will rest on the Right Middle Log. FRONT VIEW TOP VIEW R10576-0-0110 Page 9...
- Page 10 LOG PLACEMENT Slide Left Rear Log (D), charred point down, into gap between burner base and rear log shelf and under Center Log. FRONT VIEW TOP VIEW Page 10 R10576-0-0110...
- Page 11 LOG PLACEMENT Place Left Front Log (E) onto two left pins (4 and 5) on burner base. FRONT VIEW TOP VIEW R10576-0-0110 Page 11...
- Page 12 LOG PLACEMENT Place Right Front Log (F) onto two right pins (6 and 7) on burner base. FRONT VIEW TOP VIEW Page 12 R10576-0-0110...
-
Page 13: Log Placement
LOG PLACEMENT Place Crossover Log (G) onto pins on Center Log and Right Rear Log. FRONT VIEW TOP VIEW R10576-0-0110 Page 13... - Page 14 PLACEMENT OF GLOWING EMBERS LX-(24,30)CF-1 Page 14 R10576-0-0110...
- Page 15 PLACEMENT OF GLOWING EMBERS LX-(24,30)CF-1 R10576-0-0110 Page 15...
-
Page 16: Placement Of Glowing Embers Lx-(24,30)Cf-1
PLACEMENT OF GLOWING EMBERS Replacement glowing embers must be purchased from Empire Placement of the glowing embers is very individual and light Comfort Systems, Inc. Application of excess glowing embers coverage will provide your best effects. We recommend separation may adversely affect performance of the heater and may cause of the glowing embers by hand and make your coverage as light sooting. -
Page 17: Master Parts Distributor List
MASTER PARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit. -
Page 18: Service Notes
SERVICE NOTES Page 18 R10576-0-0110... -
Page 19: Service Notes
SERVICE NOTES R10576-0-0110 Page 19... - Page 20 Empire Comfort Systems Inc. 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. Comfort Systems If you have a service or repair question, please contact your dealer. www.empirecomfort.com Page 20 R10576-0-0110...
