The White Mountain Log Collection:
ROCK CREEK
WARNING: If the information in these in-
or explosion may result causing property
damage, personal injury or loss of life.
— Do not store or use gasoline or other
cinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
— Installation and service must be per-
agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
LSU18RR-2 SHOWN
-
LOG SET FOR
VENTED AND UNVENTED
MULTI-SIDED GAS LOG HEATER
MODELS
LSU18RR-2
LSU24RR-2
LSU30RR-2
Installer: Leave this manual with the appli-
ance.
Consumer: Retain this manual for future
reference.
Log sets comply with ANSI Z21.11.2 Unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid Fuel
Burning Fireplaces. State or local codes may
only allow operation of log sets in a vented
WARNING: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
Page 1
Advertisement
Table of Contents
Related Manuals for White Mountain Hearth LSU18RR-2
Summary of Contents for White Mountain Hearth LSU18RR-2
-
Page 1: Installation Instructions
MULTI-SIDED GAS LOG HEATER MODELS LSU18RR-2 LSU24RR-2 LSU30RR-2 LSU18RR-2 SHOWN WARNING: If the information in these in- or explosion may result causing property damage, personal injury or loss of life. Installer: Leave this manual with the appli- — Do not store or use gasoline or other ance. -
Page 2: Table Of Contents
General Information ................. 3 Requirements for Canada ................ 4 Before You Begin ..................5 Ember Placement .................6-9 Ember Placement LSU18RR-2 Photos ............ 6 Ember Placement LSU24RR-2 Photos ............ 7 Ember Placement LSU30RR-2 Photos ............ 8 ..................9 Log Placement ..................10-22 Master Parts Distributor List .............. -
Page 3: Important Installation Guidelines
IMPORTANT INSTALLATION GUIDELINES Proper Log Placement WARNING: Log placement is critical to proper burner performance. Logs must other accessory not approved for use with this heater. be correctly positioned onto the burner. The photos in this manual Air Freshners show the proper pinned position for logs on this set. Owners need Avoid the use of scented air fresheners (plug in type air fresheners, to be shown proper log placement and instructed not to move the logs. -
Page 4: Requirements For Canada
REQUIREMENTS FOR CANADA WARNING; DO NOT OPERATE THIS GAS LOG SET WITH This unit cannot be installed in a UNVENTED application, this GLASS DOORS CLOSED unit can only be installed as a VENTED application with these requirements. or near the appliance. IMPORTANT SAFETY INFORMATION •... -
Page 5: Before You Begin
BEFORE YOU BEGIN Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are Refer to Figures 1 through 3 for the following warning. -
Page 6: Ember Placement
EMBER PLACEMENT LSU18RR-2 PHOTOS Do not cover any large ports with loose material (glowing embers) REAR FRONT TOP View - Ember Placement Shown in Shaded Area Page 6 25742-2-0514... -
Page 7: Ember Placement Lsu24Rr-2 Photos
EMBER PLACEMENT LSU24RR-2 PHOTOS Do not cover any large ports with loose material (glowing embers) REAR FRONT TOP View - Ember Placement Shown in Shaded Area 25742-2-0514 Page 7... -
Page 8: Ember Placement Lsu30Rr-2 Photos
EMBER PLACEMENT LSU30RR-2 PHOTOS Do not cover any large ports with loose material (glowing embers) REAR FRONT TOP View - Ember Placement Shown in Shaded Area Page 8 25742-2-0514... - Page 9 Attention: When ordering parts, it is very important that part number and description of part coincide. INDEX TOP VIEW FRONT VIEW USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH. Index No. Part Number Part Number Part Number LSU18RR-2 LSU24RR-2 LSU30RR-2 Description R9312 R9323 R9329 BACK RIGHT LOG R9313...
-
Page 10: Log Placement
LOG PLACEMENT PILOT AND GAS ENTRY BOTTOM LOG PLACEMENT NOTE: PILOT AND GAS ENTRY TOP LOG PLACEMENT Figure 3 Page 10 25742-2-0514... - Page 11 LOG PLACEMENT NOTE: Follow the proper installation when placing logs, when placed correctly, the logs will not cover any ports. TOP VIEW FRONT VIEW 25742-2-0514 Page 11...
- Page 12 LOG PLACEMENT Place Right Middle Log (log B) onto right middle pins of burner. TOP VIEW FRONT VIEW Page 12 25742-2-0514...
- Page 13 LOG PLACEMENT Place Left Back Log (log C) onto left back pins of burner. TOP VIEW FRONT VIEW 25742-2-0514 Page 13...
- Page 14 LOG PLACEMENT Place Left Middle Log (log D) onto left middle pins of burner. TOP VIEW FRONT VIEW Page 14 25742-2-0514...
- Page 15 LOG PLACEMENT 5. Place Right Front Log (log E) onto right front pin of burner. TOP VIEW FRONT VIEW 25742-2-0514 Page 15...
- Page 16 LOG PLACEMENT TOP VIEW FRONT VIEW Page 16 25742-2-0514...
- Page 17 LOG PLACEMENT Place Left Front Log (log G) onto left front pins of burner. TOP VIEW FRONT VIEW 25742-2-0514 Page 17...
- Page 18 LOG PLACEMENT Insert boss of Middle Bottom Branch (log H) into recess on logs E, B, and C. TOP VIEW FRONT VIEW Page 18 25742-2-0514...
- Page 19 LOG PLACEMENT log sets. TOP VIEW FRONT VIEW 25742-2-0514 Page 19...
- Page 20 LOG PLACEMENT 10. Insert boss of Top Left Branch (log K) into recess on logs C, D, and G. TOP VIEW FRONT VIEW Page 20 25742-2-0514...
- Page 21 LOG PLACEMENT 11. Insert recess of Top Right Branch (log L) into the recess on log A. TOP VIEW FRONT VIEW 25742-2-0514 Page 21...
- Page 22 LOG PLACEMENT 12. Compare the completed log installation with Figure 4. Review previous steps to make any necessary adjustments. 13. Log placement is complete. NOTE: When placed correctly, the logs will not cover any ports. TOP VIEW FRONT VIEW Page 22 25742-2-0514...
-
