White Mountain Hearth LSU24RR-1 Installation Instructions And Owner's Manual

Rock creek log set for vented and unvented multi-sided gas log heater

Advertisement

Quick Links

The White Mountain Log Collection:
ROCK CREEK
WARNING: If the information in these in-
structions are not followed exactly, a fire or ex-
plosion may result causing property damage,
personal injury or loss of life.
— Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch; do not
use any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.

INSTALLATION INSTRUCTIONS

AND OWNER'S MANUAL
LOG SET FOR
VENTED AND UNVENTED
MULTI-SIDED GAS LOG HEATER
MODELS
LSU18RR-1
LSU24RR-1
LSU30RR-1
Installer: Leave this manual with the appli-
ance.
Consumer: Retain this manual for future refer-
ence.
Log sets comply with ANSI Z21.11.2 Unvented
Heaters and also comply with ANSI Z21.60
Decorative Vented Appliances for Solid Fuel
Burning Fireplaces. State or local codes may only
allow operation of log sets in a vented configuration.
Check your state or local codes.
WARNING: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to sub-
stances in fuel or from fuel combustion which can
cause death or serious illness.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSU24RR-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for White Mountain Hearth LSU24RR-1

  • Page 1: Installation Instructions

    LOG SET FOR VENTED AND UNVENTED MODELS LSU18RR-1 LSU24RR-1 LSU30RR-1 ance. ence. Page 1...
  • Page 2: Table Of Contents

    Important Installation Guidelines ... 3 General Information ... 3 Log Placement ...4-6 LSU18RR-1 Photos ... 7 LSU24RR-1 Photos ... 8 LSU30RR-1 Photos ... 9 Parts List & Parts View ... 10 How to Order Repair Parts ... 11 Notes ... 11...
  • Page 3: Important Installation Guidelines

    IMPORTANT INSTALLATION GUIDELINES Proper Log Placement Log placement is critical to proper burner performance. Logs must be correctly positioned onto the burner. The photos in this manual show the proper pinned position for logs on this set. Owners need to be shown proper log placement and instructed not to move the logs.
  • Page 4: Log Placement

    Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if the logs are not properly and firmly positioned in the appliance.
  • Page 5 Insert boss of Middle Bottom Branch (log H) onto recess on logs E, B, and C. Insert boss of Middle Top Branch (log I) onto recess on log H (Center Branch) and logs A and B. Note: Omit this step for 18" log sets.
  • Page 6 Apply loose material (glowing embers) per appropriate Installation Instructions and Owner's Manual. Replacement of loose material (glowing embers) must be purchased from Empire Comfort Systems, Inc. Application of excess loose material (glowing embers) may adversely affect performance of the heater. WARNING: All previously applied loose material must be removed prior to reapplication.
  • Page 7: Lsu18Rr-1 Photos

    EMBER PLACEMENT LSU18RR-1 PHOTOS 23370-1-1107 Page 7...
  • Page 8: Lsu24Rr-1 Photos

    EMBER PLACEMENT LSU24RR-1 PHOTOS Page 8 23370-1-1107...
  • Page 9: Lsu30Rr-1 Photos

    EMBER PLACEMENT LSU30RR-1 PHOTOS 23370-1-1107 Page 9...
  • Page 10: Parts List & Parts View

    R9317 R9320 R9321 R9322 USE ONLY MANUFACTURER'S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH. Page 10 PARTS LIST & PARTS VIEW Part Number Part Number LSU24RR-1 LSU30RR-1 R9323 R9329 R9324 R9330 R9325 R9331 R9326 R9332...
  • Page 11: How To Order Repair Parts

    HOW TO ORDER REPAIR PARTS Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through the distribu- tor. Parts can be shipped directly to the service person/dealer. All parts listed in the Parts List have a Part Number.
  • Page 12 Empire Comfort Systems, Inc. 918 Freeburg Ave. Belleville, IL 62220 PH: 618-233-7420 or 800-851-3153 FAX: 618-233-7097 or 800-443-8648 info@empirecomfort.com www.empirecomfort.com Page 12 23370-1-1107...
