PCS2 to AXC-INP8
Connect the PCS2 output ports to the AXC-INP8 input ports, as illustrated in FIG. 2. Follow the
illustration for Input 1 through Input 8. Set the jumpers of the associated inputs on the AXC-INP8
to Switch mode. All Switch mode inputs and the Card-Frame share common GND.
AXC-INP8
FIG. 2 PCS2 to AXC-INP8
PCS to Axcent, Axcent
Connect the PCS output and power ports to the Axcent, Axcent
ports, as illustrated in FIG. 3. Provide 12 VDC power from the Panja system power supply or an
external power supply.
Axcent
2
Axcent
3
Axcent
12 VDC
FIG. 3 PCS to Axcent, Axcent2, or Axcent3
PCS2 to Axcent, Axcent
Connect the PCS2 output and power ports to the Axcent, Axcent
ports, as illustrated in FIG. 4.
Axcent
2
Axcent
3
Axcent
FIG. 4 PCS to Axcent, Axcent2, or Axcent3
PCS and PCS2 Power Current Sensors
GND
INP1
GND
INP2
2
, or Axcent
GND
I/O 1
I/O 2
GND (-)
+
2
, or Axcent
GND
I/O 1
I/O 2
3
2
, or Axcent
3
2
, or Axcent
COM
STBY
ON
Installation
COM
STBY
PCS2
ON
3
input/output (I/O)
GND
STBY
PCS
ON
PWR
3
input/output (I/O)
PCS2
5
