Product Information

The Power Current Sensors (PCS) and Dual Power Current Sensors (PCS2) provide power current
status for AMX equipment. Examples of such equipment are video projectors, monitors, audio
receivers, and VCRs. The PCS and PCS2 detect the AC current drawn by the equipment plugged
into its AC receptacle. You can adjust either the PCS or PCS2 to detect full on, full off, and standby
power levels.

Specifications

The following tables list specifications for the PCS and PCS2.
PCS Specifications
Dimensions
Weight
Enclosure
Power Requirement
Connectors
Indicators
Load Sensitivity
PCS2 Specifications
Dimensions
Weight
Enclosure
Power Requirement
Connectors
Dry Closure Relay Outputs
Indicators
Load Sensitivity
PCS and PCS2 Power Current Sensors
3.13" x 2.23" x 2.5" (79.5 mm x 56.6 mm x 63.5 mm)
4 oz. (114 g)
Plastic black matte finish
12 VDC @ 20 mA minimum
4-pin captive screw connector
3-prong, grounded, 120 VAC receptacle
• Standby LED
• On LED
15 A 1800 W maximum (15 A @ 120 VAC maximum)
30 mA minimum
1.51" x 5.55" x 5.45" (38.4 mm x 141.10 mm x 138.4 mm)
1 lb. 10.8 oz. (816 g)
Metal black matte finish
120 VAC @ 250 mA minimum
6-pin captive screw connector
3-prong, grounded, 120 VAC receptacle
0.5 A @120 VAC or 1 A @ 28 VDC
• 2 Standby LEDs
• 2 On LEDs
• Power LED
10 A 1200 W maximum (combined fuses)
20 mA 2.4 W minimum 120 W maximum
