BEAT 485 OWNER'S MANUAL
Mobile Audio System
PLL Synthesizer Stereo Radio
RDS (Radio Data System) Operation
DAB (Digital Audio Broadcasting) Operation
CD/MP3/WMA Player
Automatic Memory Storing
Full Detachable Panel
Preset Equalization
Electronic Shockproof (ESP) Function
Memory Card Interface
USB Interface
Auxiliary Input Function
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Beat 485
Summary of Contents for Beat 485
- Page 1 BEAT 485 OWNER’S MANUAL Mobile Audio System PLL Synthesizer Stereo Radio RDS (Radio Data System) Operation DAB (Digital Audio Broadcasting) Operation CD/MP3/WMA Player Automatic Memory Storing Full Detachable Panel Preset Equalization Electronic Shockproof (ESP) Function Memory Card Interface USB Interface...
-
Page 2: Table Of Contents
CONTENTS Installation ........... 3 DAB scanning........13 Take out screw before installation ..3 DAB list mode........13 DIN Front-Mount (Method A)....3 Station storing........13 Installing the unit ....... 3 CD/MP3/WMA operation.......13 Removing the unit ......4 Switching to CD mode .......13 DIN Rear-Mount (Method B) .... -
Page 3: Installation
INSTALLATION Notes: TAKE OUT SCREW BEFORE INSTALLATION Choose the mounting location where Before install the unit, please remove the the unit will not interfere with the normal two screws. driving function of the driver. Take out screw Before finally installing the unit, connect before installation. -
Page 4: Removing The Unit
INSTALLATION to fit your vehicle’s mounting area. Then use the supplied hardware (Tapping Screw and Plain Washer) to attach the other end of metal strap to a solid metal part of the vehicle under the dashboard. This strap also helps ensure proper electrical grounding of the unit. -
Page 5: Din Rear-Mount (Method B)
INSTALLATION Note: The outer trim ring, sleeve and the 5. Insert both of the supplied keys into the metal strap are not used for method B slots at the middle left and right sides of installation. the unit, then pull the unit out of the dashboard. -
Page 6: Using The Detachable Front Panel
Precautions when handing USING THE DETACHABLE FRONT PANEL Do not drop the front panel. REMOVING THE FRONT PANEL Precautions when handling 1. Press the release button on the front 1. Do not drop the front panel. panel and pull off the front panel. 2. -
Page 7: Wiring Connection
WIRING CONNECTION FOR 4X40W SYSTEM Connector A 1. N.C 2. N.C 3. N.C 4. MEMORY +12V (YELLOW) 5. AUTO ANTENNA OUTPUT (BLUE) 6. N.C 7. +12V (TO IGNITION KEY) (RED) 8. GROUND (BLACK) Connector B 1. REAR RIGHT SPEAKER (+) (VIOLET) 2. -
Page 8: Operation
OPERATION LOCATION OF KEYS 14. 1 PAU button power button release button 15. 2 SCN 3. Volume knob (when rotated) 16. 3 RPT 17. 1-6 preset buttons SEL button (when pressed) 18. 4 SHF 4. Reset button 19. 5 DIR- 5. -
Page 9: Basic Operation
OPERATION BASIC OPERATION 2) AREA EUR/USA SWITCHING ON/OFF THE UNIT Use the volume knob (3) to set EUR Switch on the unit by pressing any button or USA area frequency spacing. (except button (8) and button (2)). 3) TA SEEK/ALARM When system is on, press button (1) to Use the volume knob (3) to set TA... -
Page 10: Loudness
OPERATION 6) MASK DPI/ALL RESET FUNCTION Use the volume knob (3) to set Reset button (4) must be activated with MASK DPI or MASK ALL. either a ballpoint pen or thin metal object. Setting to mask station during The reset button is to be activated for the search: following reasons: DPI : Alternative frequencies with... -
Page 11: Station Storing
OPERATION finished. And then 6 strongest stations - Using PTY to Select Program are stored into the corresponding PTY button (24) is operated as follows: preset number button. - Program scanning Press AS/PS button (22) shortly to scan While selecting PTY engagement, its preset station. -
Page 12: Dab Operation
OPERATION When the unit was in CD (MP3) or AUX EON TA DISTANCE mode IN mode, it will switch temporarily to EON TA switch is tried to implemented radio mode. by the information of current station. Temporary switch over to an EON When EON TA DISTANCE mode is linked station when EON detects a selected, “EONTA DX”... -
Page 13: Selecting Station
OPERATION band. to move to the previous track or the The reception band will change in the following track. Track number shows on following order: display. DAB1 DAB2 DAB3 Hold button (27) or button (26) to fast reverse or fast forward. Disc play starts from when you release the button. -
Page 14: Usb Play Operation
OPERATION contain any directory, there is no directories and songs. Select the function of pressing DIR- button (19) or desired directory/songs by using the DIR+ button (20). TUNE/SEEK/TRACK UP/DOWN buttons and BND/LOU/ENT button SELECTING TRACKS BY AS/PS (7) to confirm. If the selected title is a /Navi-SCH BUTTON song, it starts to play. -
Page 15: Memory Card Operation
OPERATION select USB mode. DISC NOTES When playing the MP3 files in the device, A. Notes on discs: the operation is the same with the 1. Attempting to use non-standard shape MP3 operation described above. discs (e.g. square, start, heart) may Note：... -
Page 16: Specification
SPECIFICATION GENERAL Power Supply Requirements : DC 12 Volts, Negative Ground Chassis Dimensions : 178 (W) x 160 (D) x 50 (H) Tone Controls Bass (at 100 Hz) : ±10 dB Treble (at 10 kHz) : ±10 dB Maximum Output Power : 4x40 watts Current Drain : 15 Ampere (max.) -
Page 17: Trouble Shooting
TROUBLE SHOOTING Before going through the checklist, check wiring connection. If any of the problems persist after checklist has been made, consult your nearest service dealer. Symptom Cause Solution The car ignition switch is If the power supply is No power. not on.
