Page 1: Air Conditioner
WINDOW AIR CONDITIONER USER MANUAL FOR MODELS: COOLING CAPACITY WAC46115R WA46YR 6,000 BTU WAC48115R WA48YR 8,000 BTU WAC410115R WA410YR 10,000 BTU WAC412115R WA412YR 12,000 BTU WAC412230R WA412ZR 12,000 BTU WAC412115M WA412YM 12,000 BTU WAC412230M WA412ZM 12,000 BTU 950-0146-revD 11-29-11... -
Page 2: Table Of Contents
CONTENTS INSTALLATION REQUIREMENTS ..........................2 Tools and Parts ..............................2 Location Requirements ............................4 Electrical Requirements ............................. 5 INSTALLATION INSTRUCTIONS ..........................7 Remove packaging materials ..........................7 Prepare Your Unit .............................. 7 Install Your Air Conditioner in the Window ......................8 Install the Support Bracket And Seal the Window .................... -
Page 3: Installation Requirements
Read and follow the instructions provided with any tools listed here. Tools Needed Phillips head screwdriver Ruler or tape measure Flat-blade screwdriver Level Pencil Scissors or Utility knife Parts Supplied For Models: WAC46115R, WAC48115R, WA46YR, WA48YR Page 2... - Page 4 For Models: WAC410115R, WAC412115R, WAC412230R, WAC412115M, WAC412230M WA410YR, WA412YR, WA412ZR, WA412YM, WA412ZM NOTE: Mounting Parts provided varies per unit of different capacity. Please check your accessories bag carefully when you open the carton. Page 3...
-
Page 5: Location Requirements
Location Requirements IMPORTANT: Observe all governing codes and ordinances. Check the location where air conditioner will be installed. Proper installation is your responsibility. Make sure you have everything necessary for correct installation. The location should provide: Grounded electrical outlet within 4 ft (122 cm) of where the power cord exits the air conditioner. -
Page 6: Electrical Requirements
Electrical Requirements Power Supply Cord NOTE: Your unit’s device may differ from the ones shown. LCDI TYPE Wiring Requirements 115-Volt (103.5 min to 126.5 max.) 0 to 13amps 15-amp time-delay fuse or circuit breaker This room air conditioner is equipped with a Use on single outlet circuit ... - Page 7 To Test your power supply cord: The power supply cord must be replaced if it 1. Plug power supply cord into a grounded 3 fails to trip when the test button is pressed prong outlet. or fails to reset. 2.
-
Page 8: Installation Instructions
Handle air conditioner gently. NOTE: This step applied to Model WAC46115R, WAC48115R, WA46YR, and WA48YR only. Prepare Your Unit NOTE: Your units may have the seal strip already attached to the top mounting rail. If applicable, skip this step. -
Page 9: Install Your Air Conditioner In The Window
Extend the left and right accordion panels to the vertical window sashes and use the screws to attach (Refer to below installation Fig. for the model you bought) Models: WAC46115R, WAC48115R, WA46YR, WA48YR Page 8... -
Page 10: Install The Support Bracket And Seal The Window
Use type B screw for WAC46115R, WAC48115R, WA46YR, and WA48YR For WAC410115R, WAC412115R, WAC412230R, WAC412115M, WAC412230M, WA410YR, WA412YR, ... -
Page 11: Air Conditioner Use
AIR CONDITIONER USE ---------------------------------------------------------------------------------------------------------------------------------- Cool Mode Feature NOTE: If the air conditioner is off and is then turned on while set Use the Cool mode at Low, Med, High or Auto Fan to a Cool setting or if turned from a fan setting to a Cool Speed for cooling. -
Page 12: Air Conditioner Controls
Starting Your Air Conditioner - Digital Control IMPORTANT: If you turn off the air conditioner, wait at least Do not try to operate your air conditioner in the 3 minutes before turning it back on. This cooling mode when outside temperature is prevents the air conditioner from blowing a below 64ºF. -
Page 13: Remote Control
How to set: The Delay 1-24hr light will turn on and the display will indicate the number of hours before the air Delayed “ON”; Air Conditioner must be off. conditioner will turn off. To change the time before Press the Delay 1-24hr button. turn off, press the Increase ▲... -
Page 14: Mechanical Controls
Mechanical Controls Mode Control TEMPERATURE control at the highest number available on your knob. High Cool, Low Cool For Quieter & Nighttime Cooling—Select Low Cool Provide cooling with different fan speeds. with the TEMPERATURE control at midpoint. Fan settings provide air circulation and filtering without cooling. -
Page 15: Air Conditioner Care
AIR CONDITIONER CARE Your new air conditioner is designed to give you many years of dependable service. This section tells you how to clean and care for your air conditioner properly. Call your local authorized dealer for an annual checkup. Remember, the cost of this service call is your responsibility. -
Page 16: Trouble Shooting
TROUBLE SHOOTING Before calling for service, try the suggestions below to see whether you can solve your problem without outside help. An extension cord is being used. Do not use an Air conditioner will not operate extension cord with this or any other appliance. You are trying to restart the air conditioner too soon after turning the unit off. - Page 17 Windows or doors to the outside are open. Close Air Conditioner cycles on and off too all windows and doors. often, or does not cool room in cooling mode The Vent control is set to open (on some models). Push the Vent control to CLOSED for maximum The air conditioner is not properly sized for your cooling and/or heating.
-
Page 18: Specifications
SPECIFICATIONS WAC46115R WAC48115 WAC410115R WAC412115R MODEL WA46YR R WA48YR WA410YR WA412YR 6000 8000 10200 12000 Cooling Capacity Heating Capacity EER Rating Dehumidification (pints/hr) 2.54 3.38 Hitachi Compressor -188 Air Flow Max (CFM) Qingan Compressor - 212 Rated Voltage Operating Voltage Range 103.5-126.5... - Page 19 WAC412230R WAC412115M WAC412230M MODEL WA412ZR WA412YM WA412ZM Cooling Capacity 12000/12300 12000 12000/12300 Heating Capacity EER Rating Dehumidification (pints/hr) 3.38 3.17 3.17 Air Flow Max (CFM) Rated Voltage 208/230 208/230 Operating Voltage Range 198-253 103.5-126.5 198-253 Frequency/Cycle 60HZ 60HZ 60HZ Cooling Amps 6.2/5.8 11.3 6.2/5.8...
-
Page 20: Warranty
WARRANTY International Refrigeration Products warrants that the product supplied is free from defects in material and workmanship. This warranty is valid as long as this product is properly handled, installed, operated and serviced in accordance with the Installation and Operating Instructions shipped with this unit, and the warranty card is completed and mailed no later than 30 days after date of purchase.
