Page 1: Air Conditioner
WINDOW AIR CONDITIONER USER MANUAL FOR MODELS: COOLING HEATING CAPACITY CAPACITY WAC418230RX WA418ZRX 18,500/18,200 BTU WAC428230RX WA428ZRX 28,500/28,000 BTU WAH418230RX WH418ZRX 18,500/18,200 BTU 16,000/13,000 BTU 950-0179revA 01/19/2011... -
Page 2: Table Of Contents
CONTENTS INSTALLATION REQUIREMENTS ............................2 Tools and Parts ..............................2 Location Requirements ............................3 Electrical Requirements ............................. 4 INSTALLATION INSTRUCTIONS ............................5 Remove packaging materials ............................5 Remove Chassis ..............................5 Prepare the Cabinett ............................6 Install the Cabinet into the Window ........................7 Install the Support Bracket .......................... -
Page 3: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. Tools Required Flat-blade and Phillips Screwdrivers Socket wrenches Pencil Parts Supplied Ruler or tape measure ... -
Page 4: Location Requirements
Location Requirements IMPORTANT: Observe all governing codes and ordinances. Check the location where air conditioner will be installed. Proper installation is your responsibility. Make sure you have everything necessary for correct installation. The location should provide: Grounded electrical outlet within 6.5 ft (200 cm) of where the power cord exits the air conditioner. -
Page 5: Electrical Requirements
Electrical Requirements Power Supply Cord NOTE: Your unit’s device may differ from the ones shown. Power Supply Wiring Requirements Cord 230-Volt (198 min to 253 max.) 0 to 12 amps 15-amp time-delay fuse or circuit breaker This room air conditioner is equipped with a Use on single outlet circuit ... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS 3. Locate the four faceplate screws and remove. Remove packaging materials These screws will need to be re-installed prior to mounting the air conditioner Remove and dispose of/recycle packaging FIG.2 materials. Remove tape and glue residue from surfaces before turning on the air conditioner. -
Page 7: Prepare The Cabinett
For some models, it is necessary to disconnect the connector plug of the display panel from the unit. FIG.5 FIG.9 9. There may be internal packing protection as shown below. This packing material must be removed prior to installation FIG.10 FIG.6 6. -
Page 8: Install The Cabinet Into The Window
4. Install top angle and side retainers to cabinet as shown below. Install the Cabinet into the Window NOTE: Handle air conditioner gently. Be sure your air conditioner does not fall out of the opening during installation or removal. ... -
Page 9: Install The Support Bracket
3. Repeat for the left side. Adjust the cabinet 4. Tighten all 6 bolts securely. until the distance on each side is the same. 4. Attach the screws to the window sill. (Refer to below installation Fig. for the model you bought). Pre-drill holes if needed. -
Page 10: Install The Chassis Into The Cabinet
the Chassis into the Cabinet Install 1. Team lift (two people) the air conditioner chassis and carefully slide it into the cabinet. Let the front of the air conditioner hang out approximately 6”. DO NOT PUSH ON THE CONTROLS OR FINNED COILS. -
Page 11: Air Conditioner Controls (Panel)
AIR CONDITIONER CONTROLS (Panel) Before you begin, thoroughly familiarize yourself with the control panel and remote as shown below and all its functions then follow the symbol for the functions you desire. The air conditioner can be controlled by the remote or the control panel. - Page 12 Air Conditioner Controls (Continued) TO CHANGE TEMPERATURE SETTING: Change Temperature: Press or hold either Up (▲) or Press to raise Down (▼) button until the desired temperature is seen on the display. Temperature range is 62°F (17°C) Press to lower to 86°F (30°C) in 1°F (1°C) increments.
- Page 13 Air Conditioner Controls (Continued) TO SELECT THE OPERATING MODE: Select Operating Mode： To choose operating mode, press the Mode button. Each time you press the button, a mode is selected in a sequence that goes from Auto, Cool, Dry and Press the Mode Fan.
- Page 14 Air Conditioner Controls (Continued) TIMER: AUTO START/STOP FEATURE: TIMER FUNCTION: Press the Timer button to select "On or Off". After the time is selected the unit will either turn on or off after the timer has timed out. Example: ...
-
Page 15: Remote Control
REMOTE CONTROL Handling and location of the remote controller Use the remote controller at a distance of 16 ft., or less, from the appliance. Point it towards the receiver on the air conditioner. Communication is confirmed with a beep. CAUTIONS ... -
Page 16: Function Buttons
Function buttons MODE button Press this button to select ON/OFF button the desired operation mode Operation starts when this from AUTO, COOL, DRY, button is pressed and HEAT (cool & heat model stops when it is pressed only) and FAN. again. -
Page 17: Remote Operation
Remote Operation Auto operation Ensure the unit is plugged in and power is on. 1. Press the ON/OFF button to start the air conditioner. 2. Press the MODE button to select Auto. 3. Press the TEMP UP/DOWN button to set the desired temperature. -
Page 18: Sleep Operation
Remote Operation (cont.) Dehumidifying (DRY) operation Ensure the unit is plugged in and power is 1. Press the ON/OFF button to start the air conditioner. 2. Press the MODE button to select DRY. 3. Press the TEMP UP/DOWN button to set the desired temperature. -
Page 19: Timer Operation
Remote Operation (cont.) Timer operation Press the TIMER button to initiate the Auto-start and Auto-stop setting program of the unit. The time can be set for 0~24 hours. To set the Auto-start/stop time. 1. Press the TIMER button, when the TIMER ON indicator displayed on the LED window of the air conditioner, it indicates the Auto Start setting program is initiated. -
Page 20: Important Information
Important Information The Cool circuit has an automatic 3 minute time delayed start if the unit is turned off and on quickly. This prevents overheating of the compressor and possible circuit breaker tripping. The fan will continue to run during this time. ... -
Page 21: Normal Sounds
Normal Sounds When your air conditioner is operating normally, you may hear sounds such as: Droplets of water hitting the condenser, causing a pinging or clicking sound. The water droplets help to cool the condenser. Air movement from the fan. ... -
Page 22: Air Conditioner Care
AIR CONDITIONER CARE Your new air conditioner is designed to give you many years of dependable service. This section tells you how to clean and care for your air conditioner properly. Call your local authorized dealer for an annual checkup. Remember, the cost of this service call is your responsibility. -
Page 23: Troubleshooting
TROUBLESHOOTING Before calling for service, try the suggestions below to see whether you can solve your problem without outside help. You are trying to restart the air conditioner too Air conditioner will not operate soon after turning the unit off. Wait at least 3 minutes after turning the unit off before trying to restart the air conditioner. - Page 24 Windows or doors to the outside are open. Close Air Conditioner cycles on and off too all windows and doors. often, or does not cool room in cooling mode The Vent control is set to open (on some models). Push the Vent control to CLOSED for maximum The air conditioner is not properly sized for your cooling and/or heating.
-
Page 25: Specifications
SPECIFICATIONS WAC418230RX WAH418230RX WAC428230RX IRP Catalog No. WA418ZRX WH418ZRX WA428ZRX 18500/18200 18500/18200 28500/28000 Cooling Capacity Heating Capacity 16000/13000 EER Rating Dehumidification (pints/hr) Air Flow Max (CFM) (H/M/L) 441/394/353 459/406/347 541/500/447 Rated Voltage 230/208 230/208 230/208 198-253 198-253 198-253 Operating Voltage Range... -
Page 26: Warranty
WARRANTY International Refrigeration Products warrants that the product supplied is free from defects in material and workmanship. This warranty is valid as long as this product is properly handled, installed, operated and serviced in accordance with the Installation and Operating Instructions shipped with this unit, and the warranty card is completed and mailed no later than 30 days after date of purchase.
