5.7.1 USB DATA FORMATS

The USB I/F uses non-return-to-zero inverted (NRZI) encoding for data transmissions, in which a
1 is represented by no change (between bit times) in signal level and a 0 is represented by a change
in signal level. Bit stuffing is employed prior to NRZ1 encoding so that in the event a string of 1's
is transmitted (normally resulting in a steady signal level) a 0 is inserted after every six consecutive
1's to ensure adequate signal transitions in the data stream.
The USB transmissions consist of packets using one of four types of formats (Figure 5-9) that
include two or more of seven field types.
♦
Sync Field – 8-bit field that starts every packet and is used by the receiver to align the
incoming signal with the local clock.
♦
Packet Identifier (PID) Field – 8-bit field sent with every packet to identify the attributes (in.
out, start-of-frame (SOF), setup, data, acknowledge, stall, preamble) and the degree of error
correction to be applied.
♦
Address and Endpint Fields – 7- and 4-bit fields (respectively) that provide source/destination
information required in token packets.
♦
Frame Field – 11-bit field sent in Start-of-Frame (SOF) packets that are incremented by the
host and sent only at the start of each frame.
♦
Data Field – 0-1023-byte field of data.
♦
Cyclic Redundancy Check (CRC) Field – 5- or 16-bit field used to check transmission
integrity.
Token Packet
SOF Packet
Data Packet
Handshake Packet
Figure 5-9. USB Packet Formats
Data is transferred LSb first. A cyclic redundancy check (CRC) is applied to all packets (except a
handshake packet). A packet causing a CRC error is generally completely ignored by the receiver.
Sync Field PID Field
(8 bits) (8 bits)
Sync Field PID Field
(8 bits) (8 bits)
Sync Field PID Field
(8 bits) (8 bits)
Sync Field PID Field
(8 bits) (8 bits)
Compaq iPAQ Series of Desktop Personal Computers
Second Edition - February 2001
Technical Reference Guide
Addr. ENDP.
Field Field
(7 bit ) (4 bit )
Frame Field CRC Field
(11 bits) (5 bits)
Data Field
(0-1023 bytes)
CRC Field
(5 bits)
CRC Field
(16 bits)
5-23
