Control 47HC:
Frequency Range (-10 dB) 1 : 55 Hz - 17 kHz
Frequency Response (± 3 dB)
Power Capacity
Nominal Sensitivity (2.83V/1m)
Nominal Coverage Angle
Directivity Factor (Q)
Directivity Index (DI)
Rated Maximum SPL: 112 dB @ 1 m (3.3 ft) average, 114 dB peak
Rated Impedance: 8Ω (in bypass mode)
Transformer Taps: 60W 30W, 15W, (& 7.5W @ 70V)
LF Driver: 165mm (6.5 in) with polypropylene cone, butyl rubber surround,
HF Driver: 25mm (1 in) soft dome w/ dampening, ferrofluid-cooled.
Input Connectors: Two removeable locking 2-pin connectors with screw-down terminals.
Knockouts: Two (top and side)
Safety Agency: Suitable for use in air handling spaces per UL1480, UL2043, NFPA90, NFPA70A, and in
Dimensions: Ø 346 mm (13.6 in)
Cutout Size: 307 mm (12.1 in)
Ceiling Thickness Range: Accommodates tiles / drywall up
Net Weight: 6.4 kg (14 lbs)
Included Accessories:
Control 42C:
Frequency Range (-10 dB) 1 : 140 Hz - 20 kHz
Frequency Response (± 3 dB) 1 : 180 Hz - 17 kHz
Power Capacity 2 : 30 Watts Continuous Program Power
Nominal Sensitivity (2.83V/1m) 1 : 82 dB
Nominal Coverage Angle 3 : 160° conical coverage
Directivity Factor (Q) 3 : 6.6
Directivity Index (DI)
Rated Maximum SPL: 94 dB @ 1 m (3.3 ft) average, 100 dB peak
Rated Impedance: 16Ω
Driver: 60mm
Input Connectors: Two removeable locking 2-pin connectors with screw-down terminals.
Knockouts: Two (top and side)
Safety Agency: Suitable for use in air handling spaces per UL1480, UL2043, NFPA90, NFPA70A, and in
Dimensions: Ø 127 mm (5.0 in)
Cutout Size: 104 mm (4.1 in)
Ceiling Thickness Range: Accommodates tiles / drywall up to 27 mm (1.06 inches)
Net Weight: 0.7 kg (1.6 lbs)
Included Accessories:
SPECIFICATIONS
1
: 70 Hz - 14 kHz
2
: 150 Watts Continuous Program Power
75 Watts Continuous Pink Noise
1
: 93 dB
3
: 75° conical coverage
3
: 10.2
3
: 12.0dB
copper-clad coil, vented aluminum former.
Max wire 12 AWG (2.5 mm). Key: 1) + in, 2) - in, A) + loop thru, B) - loop thru
accordance with the requirements of IEC60849/EN60849
diameter
press-in grille, C-ring support backing plate, 2 tile support rails, knockout strain relief,
cutout template, paint shield
15 Watts Continuous Pink Noise
3
: 6.8dB
(2.5 in) mid-high
Max wire 12 AWG (2.5 mm). Key: 1) + in, 2) - in, A) + loop thru, B) - loop thru
accordance with the requirements of IEC60849/EN60849
diameter x 97 mm (3.8 in) mounting depth
press-in grille, C-ring support backing plate, knockout strain relief, cutout template, paint shield
x 353 mm (13.9 in) mounting depth
to 70 mm (2.75 inches) thick
thick
