System Specifications - MSI Wind Box DC110 User Manual

Overview

System Specifications

Processor
■ Intel ® Celeron Processor 847
Chipset
■ Intel ® NM70 Chipset
Memory
■ 1 DDR3 1333 SO-DIMM slot
■ Supports the maximum of 4GB
LAN
■ Wired LAN: supported by Realtek
■ Wireless LAN: optionally supported through mini-PCIE WLAN module
Audio
■ HDA Codec by Realtek
■ Flexible 5.1-channel audio with jack sensing
■ Compliant with Azalia 1.0 spec
1-8
Input/Output (I/O)
■ 6 USB 2.0 ports
■ 1 DC power jack
■ 1 RJ-45 LAN jack
■ 1 speaker jack
■ 1 headphone jack
■ 1 microphone jack
■ 1 VGA-out port
■
1 HDMI-out port
■ 1 Optical S/PDIF-out jack
Storage
■ Hard Disk Drive: 2.5", SATAII
■ Card Reader: 3-in-1 card reader
RTL8111E Gigabit Ethernet controller
®
ALC662
®
