Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per MSI Cubi 5 10M 419EU o cerca il tuo prodotto tra le migliori offerte di PC Desktop e Workstation Cubi Series Personal Computer Cubi B183...
Contents Copyright and Trademarks Notice ��������������������������������������������������������������������������iii Revision History ������������������������������������������������������������������������������������������������������iii Upgrade and Warranty ��������������������������������������������������������������������������������������������iv Acquisition of Replaceable Parts ����������������������������������������������������������������������������iv Technical Support ���������������������������������������������������������������������������������������������������iv Green Product Features ������������������������������������������������������������������������������������������iv Environmental Policy ����������������������������������������������������������������������������������������������� v Chemical Substances Information �������������������������������������������������������������������������� v Battery Information �������������������������������������������������������������������������������������������������� v Safety Instructions ���������������������������������������������������������������������������������������������������vi CE Conformity �������������������������������������������������������������������������������������������������������...
If a problem arises with your system and no solution can be obtained from the user’s manual, please contact your place of purchase or local distributor� Alternatively, please try the following help resources for further guidance� Visit the MSI website for technical guide, BIOS updates, driver updates and other information via http://www�...
Users should contact the local authorized point of collection for recycling and disposing of their end-of-life products� ◙ Visit the MSI website and locate a nearby distributor for further recycling information� ◙ Users may also reach us at gpcontdev@msi�com for information regarding proper Disposal, Take-back, Recycling, and Disassembly of MSI products�...
Safety Instructions ◙ Read the safety instructions carefully and thoroughly� ◙ All cautions and warnings on the equipment or user’s manual should be noted� Keep the User’s Guide that comes with the package for future reference� Keep this equipment away from humidity and high temperature� Lay this equipment on a reliable flat surface before setting it up.
Page 7
Preface Never pour any liquid into the opening that could damage or cause electrical shock� Place the power cord in a way that people are unlikely to step on it� Do not place anything on the power cord� ◙ When installing the coaxial cable to the TV Tuner, it is necessary to ensure that the metal shield is reliably connected to protective earthing system of the building�...
1� this device may not cause harmful interference, and 2� this device must accept any interference received, including interference that may cause undesired operation� MSI Computer Corp. 901 Canada Court, City of Industry, CA 91748, USA (626)913-0828 www�msi�com...
Vietnam RoHS As from December 1, 2012, all products manufactured by MSI comply with Circular 30/2011/TT-BCT temporarily regulating the permitted limits for a number of hazardous substances in electronic and electric products�...
Overview Congratulations for purchasing the Cubi Series Personal Computer� This system is your best PC choice� With the fantastic appearance, it can easily be set anywhere� The feature packed platform also gives you an exciting PC experience�...
Packing Contents Cubi B183 AC/DC Adapter AC Power Cord User Manual & VESA Mount Kit (Optional) Quick Guide (Optional) * Please contact us immediately if any of the items is damaged or missing� * The illustrations are for reference only and your packing contents may slightly vary depending on the model you purchased�...
Overview System Overview Front View Power Button Press the power button to turn the system on and off. Drive Activity Indicator LED blinks when the system is accessing the internal storage drives� USB 3�2 Gen 1 Port (Type-C) USB 3�2 Gen 1, the SuperSpeed USB, delivers up to 5Gbps high-speed data transfer for various devices, such as storage devices, hard drives, video cameras, etc�...
Page 14
Headphone Jack This connector is provided for headphones or speakers� Important Use a shielded USB 3�2 cable (at least 8” or 20cm long) when connecting a USB 3�x device to the USB 3�2 port of this product so as to avoid wireless interference�...
Page 15
Overview Right Side View Kensington Lock Port This PC provides a Kensington lock port, which allows users to secure the PC in place with a key or some mechanical PIN device and attached through a rubberised metal cable. The end of the cable has a small loop which allows the whole cable to be looped around a permanent object, such as a heavy table or other similar equipment, thus securing the PC in place.
Page 16
Rear View Power Jack The AC/DC adapter converts AC power to DC power for this jack� Power supplied through this jack supplies power to the PC� To prevent damage to the PC, always use the supplied power adapter� USB 2�0 Port The USB (Universal Serial Bus) port is for attaching USB devices such as keyboard, mouse, or other USB-compatible devices�...
Page 17
Overview LAN Jack The standard RJ-45 LAN jack is provided for connection to the Local Area Network (LAN)� You can connect a network cable to it� Yellow/ Green Green LED State Condition LED Color Green LAN link is not established� On (steady state) LAN link is established�...
Safety & Comfort Tips The Personal Computer System is a portable platform that allows you to work anywhere� However, choosing a good workspace is important if you have to work with your PC for a long period of time� 1� Your work area should have enough illumination� 2�...
Getting Started Hardware Setup Connecting the AC Power 1. Unpack the package to find the AC/DC adapter and AC power cord. 2� Connect the adapter and the power cord� 3� Connect the Power Jack� 4� Plug the power cord to the electrical outlet� Disconnecting the AC Power 5.
Page 22
Powering on the System Press the power button to power on the system�...
System Operations This chapter provides you with essential information on system operations� Important All information is subject to change without prior notice�...
Power Management Power management of personal computers (PCs) and monitors has the potential to save significant amounts of electricity as well as deliver environmental benefits. To be energy efficient, turn off your display or set your PC to sleep mode after a period of user inactivity�...
Page 25
System Operations Waking the System Up The computer shall be able to wake up from power saving mode in response to a command from any of the following: ■ the power button, ■ the network (Wake On LAN), ■ the mouse, ■...
Network Connection (Windows 10) Wired Network 1� Right-click [Start] and select [Network Connections] from the list� 2� Select [Ethernet] and then [Network and Sharing Center]� 3� Select [Set up a new connection or network]�...
Page 27
System Operations 4� Choose [Connect to the Internet] and click [Next]� 5� Select [Broadband (PPPoE)] to connect using DSL or cable that requires a user name and password� 6� Type the information from your Internet Service Provider (ISP) and click [Connect] to establish your LAN connection�...
Page 28
Wireless Network 1� Go to [Start] , click [Settings] and select [Network and Internet]� 2� A list of available WLAN connections pops up� Choose a connection from the list� 3� To establish a new connection, select [Network and Sharing Center]� 4�...
System Operations System Recovery (Windows 10) The purposes for using the System Recovery Function may include: ■ Restore the system back to the initial status of original manufacturer’s default settings� ■ When some errors have occurred to the operating system in use� ■...
Page 30
Reset this PC 1� Go to [Start] , click [Settings] and select [Update and security]� 2� Select [Recovery] and click [Get started] under [Reset this PC] to start the system recovery� 3. The [Choose an option] screen pops up. Choose between [Keep my files] and [Remove everything]�...
Page 31
System Operations Keep my files 1. Select [Keep my files]. 2� The [Your apps will be removed] screen shows a list of apps that will need to be reinstalled from the web or installation discs� Click [Next] to continue� 3� The next screen will show the changes to be made during the process� Click [Reset] to start the system reset�...
Page 32
Remove everything 1� Select [Remove everything]� 2� If you have multiple hard drives, a screen will pop up, asking you to choose between [Only the drive where Windows is installed] and [All drives]� 3. Then select between [Just remove my files] and [Remove files and clean the drive]. 3-10 4�...
Recovering the system with the F3 Hotkey Follow the instructions below to continue: 1� Restart the PC� 2� Press the F3 hotkey on the keyboard promptly when the MSI greeting appears on the display� 3� On the “Choose an Option” screen, tap “Troubleshoot”�...
