User Manual "Streaming Client" - V1.31 - 8. Jan. 2007

3 Device Configuration

You can adjust network settings, streaming sources,
monitoring settings and more with the Web interface. To
enter the configuration mode you will need:
• the IP address announced over the audio outputs (see
the Quick Install Guide)
• a standard web browser
Open your web browser and type in the IP address of
the Barix device in the URL field and hit the "Enter" key.
• Example: "192.168.0.12"
You will see the following window content:
To store changed settings click on Apply button at the
end of the page. The device will restart with the new
settings.
To obtain a quick insight into the configuration
parameters click on the icon (red question mark) next
to the section title. The help information will show up in
the right, grey frame of the browser window.
Device Configuration 13
