1. dESIGNATIONS
B1.
B2.
B3.
B4.
B5.
B6.
B7.
B8.
B9.
B10. Pitchfader
B11.
B12. Key Lock Button
B13. Sync Button (Shift: C/D) [Traktor PRO]
B14. Cue Button (Shift: Preview)
B15. Shift Button
B16. Gain Knob
B17. EQ High Knob (Shift: Filter)
B18. EQ Mid Knob (Shift: Key)
B19. EQ Low Knob (Shift: Shift: Pan) [Traktor PRO]
B20. Trax Encoder (Shift: Folder)
B21. Load Button (Shift: Deck C/D Button) [Traktor PRO]
B22. Loop In / Set Cue Button (Shift: Loop In Button Deck C/D) [Traktor PRO]
B23. Loop Out / Reloop Button (Shift: Loop Out Deck C/D) [Traktor PRO]
B24. Auto Loop Button (Shift: Auto Loop Deck C/D) [Traktor PRO]
B25. Loop Active Display (Shift: FX Select Advanced Mode) [Traktor PRO]
B26. FX Value 1-3 Encoder (Shift: FX Select 1-3)
B27. Activate 1-2 Buttons
B28. Activate 3 Button (Shift: FX 1 Routing Button) [Traktor PRO]
B29. FX On Advanced Mode (Shift: FX 2 Routing Button) [Traktor PRO]
B30. Dry/Wet Turning Knob (Shift: Auto Loop Increase/Decrease)
B31. Master Volume
B32. Headphones Volume
B33. Cue Mix Fading
B34. Kensington Lock
20
B13
B14 B15 B16
B12
B6
B3 B2 B1
Play/Pause Button (Shift: Deck C/D) [Traktor PRO]
Cue Button (Shift: Deck C/D) [Traktor PRO]
CUP Button (Shift: Deck C/D) [Traktor PRO]
Linefader
Crossfader
Jog Wheel
Search Button
Scratch Button
FX Dry/Wet Button
Pitch Bend Button (Shift: Close/Open Folder)
B21 B20
B17
B31
B32 B18
B33 B19
B8 B9
B7
B4
B5
B22
B27
B23
B10
B24 B26 B30
B25 B28 B29
B11
B34
