- Page 1 Cold Water High Pressure Cleaner with Combustion Engine M 400 M 500 To be read carefully before start-up! von Oertzen GmbH • Ferdinand-Harten-Str. 10 • 22949 Ammersbek • Tel. +49 40 604110 • Fax +49 40 6041149 www.oertzen-gmbh.de • info@oertzen-gmbh.de...
-
Page 2: Table Of Contents
Table of Content Introduction page Safety Instructions pages 4 – 5 Configuration/Illustration pages 6 – 7 Start-up/Operation/Shut-down pages 8 – 12 Maintenance and Care pages 13 – 14 Technical Data page Trouble-Shooting pages Declaration of Conformity page... -
Page 3: Introduction
Introduction By buying the OERTZEN equipment you have purchased one of the most durable and reliable high pressure cleaners available on the market. Its balanced ratio of water flow (temperature) and working pressure perfectly meets all cleaning requirements. The OERTZEN high pressure cleaners and accessories conform to all European safety regulations which is guaranteed by the CE symbol on the type plate. -
Page 4: Safety Instructions
Unsuitable respectively defective high pressure hoses often cause severe accidents during operation. Therefore high pressure hoses to be carefully inspected before start-up and replaced by original OERTZEN equipment in case of damage. Use of other than original OERTZEN equipment (hand nut marked with OERTZEN), results in expiry of the EC Declaration of Conformity, as well as product liability and warranty. - Page 5 After work the machine to be locked and secured against unauthorized/accidental operation by means of the safety lever. Use of equipment and/or consumables which is/are not delivered or expres- sively approved by OERTZEN results in expiry of the EC Declaration of Conformity, as well as product liability and warranty.
-
Page 6: Configuration/Illustration
Configuration/Illustration The machines of the Mobile series consist of a low speed, high pressure inline plunger pump, driven by a low-emission 4-stroke engine in V-design. In order to extend the engine lifetime, an oil shortage cut-out is installed, which switches off the engine in case the oil level drops below specified limits. An oil-greased reduction gearbox flanged between pump and engine reduces the high pressure pump speed and as a result extends the maintenance intervals of the pump. -
Page 8: Start-Up/Operation/Shut-Down
(sight glass/dip stick), correct oil level of combustion engine (dip stick). Only oil qualities approved by OERTZEN to be used. High pressure pump: special pump oil OERTZEN OSP, reduction gear: special pump oil OERTZEN OSP, combustion engine: OERTZEN special motor oil OSM. - Page 9 Connections Water Supply Connect water inlet (6) of the machine to water source with a clean hose (diameter see table page 9). Before connecting water supply hose, rinse it thoroughly. In case of connection to the potable water distribution, observe DIN 1988 (for momentary connections use a backflow preventer with non- return function and ventilation).
- Page 10 Operation From production month 07/2005 on the Mobile series is equipped with an EMERGENCY STOP switch (2 a). In case of emergency push EMERGENCY STOP switch. After elimination of cause EMERGENCY STOP switch to be released by pulling it out, otherwise machine cannot be re-started.
-
Page 11: Maintenance And Care
• Thoroughly clean high pressure hose. In case of damage (cuts, abrasions, kinks) replace high pressure hose for safety reasons. • Only original OERTZEN high pressure hoses to be used. Otherwise Declaration of Conformity and warranty will expire. • Reel up high pressure hose properly without any loops. - Page 12 First oil change after 50 operating hours, all further oil changes every 500 operating hours, min. once a year. Correct oil level to be checked every day. Exclusively OSP pump oil to be used. Use of oil qualities not approved by OERTZEN results in expiry of warranty.
- Page 13 Battery Maintenance work to be carried out according to manufacturer’s instructions. Check acid level every week. Refill distilled water whenever needed. Water Filter The cartridge filter (5) is arranged in the water inlet (6) and must be inspected prior to start up. Change filter cartridge, if needed. Supply of polluted water or dirty strainer will cause severe damage on the pump and safety/control valve.
-
Page 14: Technical Data
Technical Data Technical Data Mobil 400 Mobil 500 Water consumption/adjustable 500 – 1320 l/h 500 – 1020 l/h Unloading pressure 405 bar 520 bar Working pressure/adjustable 385 bar 500 bar Power rating 22 PS/16,2 kW 22 PS/16,2 kW Fuel consumption at full load 7,7 l/h 7,7 l/h Tank volume... -
Page 15: Trouble-Shooting
Trouble Shooting Electric power can cause severe injuries. Defective electrical compo- nents to be immediately replaced, possible causes for accidents to be eliminated without delay. Any repair work must only be carried out by qualified personnel. Only original equipment expressively approved by the manufacturer to be installed, as otherwise warranty and Declaration of Conformity will expire, health and safety standards are not guaranteed.
