- Page 1 Operation Manual SuperMagnum 220 ELC 11/04 von Oertzen GmbH • Ferdinand-Harten-Str. 10 • 22949 Ammersbek • Tel. +49 40 604110 • Fax +49 40 6041149 www.oertzen-gmbh.de • info@oertzen-gmbh.de...
-
Page 2: Table Of Contents
Table of Content Introduction Page Safety Instructions Page 4 - 5 Design, Operation, Illustrations Page 6 - 7 Start-up/Shut-down Page 8 - 12 Maintenance and Care Page 13 - 16 Electric Wiring Diagram Page 17 Technical Data Page 17 Trouble Shooting Page 18 Declaration of Conformity Page 19... -
Page 3: Introduction
Introduction The OERTZEN high pressure cleaner is one of the most durable and reliable machines on the market. Its balanced ratio of water quantity and operating pressure allows to carry out all cleaning and disinfection work. It conforms to the National and European Safety Regulations. The CE label guarantees fulfilment of all relevant National and European Safety Regulations (EN). -
Page 4: Safety Instructions
OERTZEN equipment. Using other materials than original OERTZEN equip- ment (union respectively hose marked with “OERTZEN”) or using materials which have not expressively been approved by OERTZEN in writing voids all warranties and product liability. Worn out and/or defective high pressure hoses must never be repaired and reused, but replaced immediately. - Page 5 The unit must not be placed or operated in areas jeopardised by fire or explosions. During working at fuel stations the “Technical Rules for flammable Liquids” (TfbF) to be considered. Consumables to be handled thoroughly. Technical safety regulations and environmental rules to be followed. Machine not to be started in case power cable, plugs, switches, etc.
-
Page 6: Design, Operation, Illustrations
Design, Operation, Illustrations The hot water high pressure cleaner comprises an inline plunger high pressure pump with safety shut-down system a high capacity oil heating system with stainless steel heat exchanger. The high pressure pump is directly flanged to the electric motor. It sucks the feed water from a level controlled water tank and directs it via the safety/ control unit into a heating coil where it is heated up to operating temperature. -
Page 8: Start-Up/Shut-Down
• Fill in all consumables required • Check correct oil level of high pressure pump (dip stick), only oil qualities approved by OERTZEN to be used (OERTZEN OSP special pump oil). • Check high pressure pump/pump connections for leaks • Machine only to be run with absolutely clean water. Thoroughly flush water supply hose before connection. - Page 9 (indicator lamp c) fill tank. Tank to be properly closed after filling. Anti-Scalant Tank Filling Fill anti-scalant tank (28) with OERTZEN anti-scalant liquid ORM 30. Never run the machine with empty anti-scalant tank. Tank to be properly closed after filling.
- Page 10 Operation Open water source. Unlock and release spray pistol, bleed the unit until blister-free water emerges. Turn ON/OFF/burner switch (2 a) into position I. Adjust thermostat (23 a) to required working temperature. Turn ON/OFF/burner switch (2 a) into position "burner". Carry out cleaning task.
- Page 11 Detergent Dosing Only detergents approved by OERTZEN to be used. Use of hazardous detergents or detergents not approved by OERTZEN ceases warranty and product liability. Depending on the kind of detergent, it can be used in hot or cold water mode. Follow manufacturer's instructions.
- Page 12 Reel off high pressure hose and thoroughly clean it. In case of damage replace it for safety reasons. Using other materials than original OERTZEN equipment (hand nut respec- tively hose marked with “OERTZEN”) or using materials which have not expressively been approved by OERTZEN in writing ceases warranty and product liability.
-
Page 13: Maintenance And Care
First oil change to be carried out after 50 operating hours, further oil changes due every 500 operating hours, however, min. once a year. Only OERTZEN OSP special pump oil to be used. Take care that waste oil will be treated as per regulations. - Page 14 The anti-scalant is an acid, i.e. corrosive! Therefore, protective clothing/mask/gloves to be put on! Only use OERTZEN anti-scalant liquid ORM 30 In areas with excessive water hardness, at least every 200 operating hours the system should be flushed with anti-scalant liquid during regular maintenance.
- Page 15 Otherwise maintenance intervals to be shortened. Only original OERTZEN spare parts to be used. Otherwise warranty and product liability will be ceased. CE Declaration of Conformity expires. All maintenance instructions laid down in this manual are part of our...
- Page 16 Frost Protection Frost-protection of the machine is of vital interest, as frost can cause severe damage on the entire system. The best frost protection is to store the machine/accessories in a permanently frost-protected area. If there is a risk of temperatures below freezing point during storage and/or transportation, the machine to be frost-protected as follows: •...
-
Page 17: Electric Wiring Diagram
6. Electric Wiring Diagram 7. Technical Data Technical Data SuperMagnum 220 ELC Flow rate, adjustable 960 l/h Unloading pressure * 230 bar Max. working pressure, adjustable 210 bar Water temperature, adjustable 30 – 140 °C Normal current (50 Hz) 3 ~ 400 V... -
Page 18: Trouble Shooting
Repair work to be carried out by qualified personnel. Disconnect the machine from electric power source during repair/maintenance work. Only original OERTZEN spare parts and accessories to be used. Use of other materials ceases all warranty obligations. Malfunction...
