Component
(6) USB 3.0 ports (2)
(7) Audio-out (headphone)/Audio-in
(microphone) jack
(8) Memory card reader
(9) USB 3.0 charging (powered) port
(10) HDMI port
Description
NOTE: For disc compatibility information, go to the Help
and Support web page (see
Follow the web page instructions to select your computer
model. Select Drivers & Downloads, and then follow the on-
screen instructions.
Each USB 3.0 port connects an optional USB device, such
as a keyboard, mouse, external drive, printer, scanner or
USB hub.
Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable. Also
connects an optional headset microphone. This jack does
not support optional microphone-only devices.
WARNING! To reduce the risk of personal injury, adjust
the volume before putting on headphones, earbuds, or a
headset. For additional safety information, refer to the
Regulatory, Safety, and Environmental Notices . To access
this guide, from the Start screen, type support, and then
select the HP Support Assistant app.
NOTE: When a device is connected to the jack, the
computer speakers are disabled.
NOTE: Be sure that the device cable has a 4-conductor
connector that supports both audio-out (headphone) and
audio-in (microphone).
Reads optional memory cards that store, manage, share, or
access information.
To insert a card:
Hold the card label-side up, with connectors facing the slot,
insert the card into the slot, and then push in on the card
until it is firmly seated.
To remove a card:
Press in on the card it until it pops out.
Connects an optional USB device, such as a keyboard,
mouse, external drive, printer, scanner or USB hub.
Standard USB ports will not charge all USB devices or will
charge using a low current. Some USB devices require
power and require you to use a powered port.
NOTE: USB charging ports can also charge select models
of cell phones and MP3 players, even when the computer is
off.
Connects an optional video or audio device, such as a high-
definition television, any compatible digital or audio
component, or a high-speed HDMI device.
More HP resources on page
Multimedia features
3).
25
