Right Side - HP Notebook User Manual

Right side

NOTE: Refer to the illustration in this section that most closely matches your computer.
Component
(1)
(2)
(3)
(4)
(5)
6 Chapter 2 Getting to know your computer
Power light
Hard drive light
Audio-out (headphone)/Audio-in
(microphone) jack
USB 3.0 port
Optical drive
Description
On: The computer is on.
●
Blinking: The computer is in the Sleep state, a power-
●
saving state. The computer shuts off power to the
display and other unneeded components.
Off: The computer is off or in Hibernation. Hibernation
●
is a power-saving state that uses the least amount of
power.
Blinking white: The hard drive is being accessed.
●
Amber: HP 3D DriveGuard has temporarily parked the
●
hard drive.
NOTE: For information about HP 3D DriveGuard,
see Using HP 3D DriveGuard on page
Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable. Also
connects an optional headset microphone. This jack does
not support optional microphone-only devices.
WARNING! To reduce the risk of personal injury, adjust
the volume before putting on headphones, earbuds, or a
headset. For additional safety information, refer to the
Regulatory, Safety, and Environmental Notices . To access
this guide, from the Start screen, type support, and then
select the HP Support Assistant app.
NOTE: When a device is connected to the jack, the
computer speakers are disabled.
NOTE: Be sure that the device cable has a 4-conductor
connector that supports both audio-out (headphone) and
audio-in (microphone).
Connects an optional USB device, such as a keyboard,
mouse, external drive, printer, scanner or USB hub.
Depending on your computer model, reads an optical disc
or reads and writes to an optical disc.
59.
