- Page 1 PTZ-9300 Mini Sp eed Dome Camera INSTRUCTION MANUAL 100X ZOOM ON SCREEN 360 /sec 0.05 /sec PATTERN 4 DOME 4.5" DAY & NIGHT SWING 8 GROUP 8 VECTOR PRIVACY AL ARM 4 IN PRESET 128 DISPLAY CONTINUOUS SPEED LOW SPEED...
- Page 2 CAUTl0N RISK OF ELECTRIC SHOCK DO NOT OPEN TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT OPEN COVERS. CAUTl0N： N0 USER SERVICEABLE PARTS INSlDE. REFER SERVICING TO QUALIFIED SERVICE PERSONAL. This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage"...
-
Page 3: Important Safeguard
NOTICE Important Safeguard Read Instructions Read all of the safety and operating instructions before using the product. Retain Instructions Save these instructions for future reference. Attachments Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards,damage product and void warranty. -
Page 4: Table Of Contents
CONTENTS Introduction Features Pr od uct ＆Accessor i es Installation DIP Switch Setup Cabling Operation Checking Before Operation Preset and Pattern Function Pre-Check Start OSD Menu Reserved Preset Preset Swing Pattern Group Other Functions OSD Display of Main Screen H o w t o u s e 0 S D M e n u General Rules of Menu Operation Main Menu Display Menu for Main Screen... -
Page 5: Introduction
100X ZOOM 360 /sec 0.05 /sec DAY & NIGHT VECTOR CONTINUOUS SPEED LOW SPEED MOTION INTRODUCTION F ea t u r es Camera Specifications CCD Sensor :1/4"Interline Transfer CCD Zoom Magnification : x 10 Optical Zoom, x 10 Digital Zoom(Max x 100 Zoom) Day &... - Page 6 AL ARM 41N INTRODUCTION OSD (On Screen Display) Menu OSD menu is provided to display the status of camera and to configuie the functions interactively. The information such as Camera ID, Pan/Tilt Angle, Alarm Input and Preset can be displayed on screen.
-
Page 7: Product & Accessories
INTRODUCTION Product & Accessories Assembly Options Speed Dome Mounting Base Screws x 3 Ceiling Bracket Screws x 3 Thread Connector Speed Dome Pendant Bracket Groove Mounting Base Screws x 3 Speed Dome Wall Mount Bracket Spee d Dome Camera Instruction Manual... -
Page 8: Installation
INSTALLATION DIP Switch Setup Before you install the cam era, you should set the DIP switches to configure the camera ID, communication protocol. Communication Camera ID Prot ocol OPTIONS ADDRESS (ID) FUNC. FUNC. PROTOCOL 12 8 PA L Refer to the Manual NTSC Camera ID Setup... - Page 9 INSTALLATION Communication Protocol Setup Select the appropriate Protocol with DIP switch combination. Switch State Protocol (Pin 1) (Pin 2) PELCO- D, 2400 bps PELCO- D, 9600 bps PELCO- P, 4800 bps PELCO- P, 9600 bps If you want to control using DVR or P/T controller, their protocol must be identical to camera.
-
Page 10: Cabling
INSTALLATION Cabling B NC Moinitor Controller/DVR Power Speed Dome Cabling Terminal Block Power Connection Please, check the voltage and current capacity of rated power carefully. Rated power is indicated in the back of main unit. Input Voltage Range Current Consumption Roated Power D C 1 2V ~ 5 0 V 0.8A... - Page 11 INSTALLATION Video Connection Connect with BNC coaxial cable. Alarm input Conection (Not Avalible) Sensor Input +5V-12V Intemal In COM+ In 1- Sensor 1 Output Sensor 4 Output In 4- Before connecting sensors, check driving voltage and output signal type of the sensor. Since output singal types of the sensors are divided into open collector and voltage output tye in general, the cabling must be done properly after considering these typed.
-
Page 12: Operation
OPERATION Check points before operation Before power is applied, please check the cables carefully. The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked by reading DIP switch of the camera． If your controller supports multi-protocols, the protocol must be changed to match to that of the camera. -
Page 13: Starting Osd Menu
ON SCREEN DISPLAY OPERATION Starting OSD Menu Using the OSD menu, Preset, Pattern, Swing, Group and Alarm Input function can be Function configured for each application. Enter Menu Press <Call> + Preset Number [95] +<Enter> Reserved Preset Some Preset numbers are reserved to special functions. Description Function : Enters into OSD menu... -
Page 14: Preset
SWING 8 PRESET 128 OPERATION Pr eset t Function Max 128 positions can be stored as Preset position. The Preset number can be assigned from 1 to 128, but 95 is reserved for starting OSD menu. Camera characteristics (Le. White Balance, Auto Exposure) can be set up independently for each preset. -
Page 15: Pattern
PATTERN 4 OPERATION Pattern Function Pattern Function is that a camera memorizes the path (mostly curve path) by joystick of controller for assigned time and revives the path exactly as it memorized. 4 Patterns are available and Maximum 1200 communication commands can be stored in a pattern. -
Page 16: Group
GROUP 8 OPERATION Group Function The group function allows runmng sequence of Presets, Pattern and/or Swings Max 8 group can be stored. Each group can have max 20 action entities which can be preset, pattern or swing Preset speed can be set up and the repeat number of Pattern＆Swing can be set up in Group setup. -
Page 17: Other Functions
AL ARM 4 IN PRIVACY ZONE OPERATION Other Functions Power Up Action This function enables to resume the last action executed before power down. Most of actions such as Preset, Pattern, Swing and Group are available for this functlon but jog actions are not available to resume．... -
Page 18: Osd Display Of Main Screen
ON SCREEN DISPLAY OPERATION OSD Display of Main Screen Preset Label LABEL 12345 PRESET1 Action Title Image Flip I : 1 - - 4 Alarm Information Camera ID CAM 1 15/ 4/ X 1/ N P/T/Z Information P/T/Z Information Current Pan/Tilt angle in degree, zoom magnification and a compass direction. Camera ID Current Camera ID(Address). -
Page 19: General Rules Of Menu Operation
HOW TO USE OSD MENU General Rules of Key Operation for Menu The menu items surrounded with ( ) always has its sub menu. For aIl menu level, to go into sub menu, press NEAR key． To go to up-one-level menu, press FAR key. T0 mave from items to item in the menu, use joystick in the Up/Down or Left/Right. -
Page 20: Display Menu For Main Screen
HOW TO USE OSD MENU Display Setup This menu defines Enable/Disable of OSD display on Main Screen. D I S P L A Y S E T U P If an item is set to be AUTO, the item is displayed only when the CAMERA value of it is changed. -
Page 21: Privacy Zone Mask Setup
PRIVACY ZONE HOW TO USE OSD MENU PRIVACY ZONE MASK Setup <Display Setup> → <Privacy Zone> Select area in image to mask. PRIVACY ZONE [1~4] Mask No MASK NO U N D E F I N E D Select Mask number. If the selected mask has O F F D I S P L A Y C A N C E L... -
Page 22: Camera Module Setup
100X ZOOM HOW T O USE OSD MENU CAMERA SETUP <Dome Camera Setup> → <Camera Setup> Setup the general functions of zoom camera module ZOOM CAMERA SETUP F O C U S M O D E S E M I A U TO [AUTO/MANUAL/SEMIAUTO] Focus Mode D I G I T A L Z O O M... - Page 23 HOW TO USE OSD MENU Auto Exposure Setup <Dome Camera Setup>→<Camera Setup>→<Auto Exposure Setup> Backlight [ON/OFF] S E T U P - G L O B A L Sets Bacldight Compensation B A C K L I G H T AUTOI D AY / N I G H T Day/Night...
-
Page 24: Motion Setup
HOW TO USE OSD MENU Motion Setup <Dome Camera Setup>→<Motion Setup> Setup the general functions of Pan/Tilt motions. M O T I O N S E T U P Motion Lock [ON/OFF] MOTION LOCK PWR UP ACTION Group. It is possible only to run those functions. AUTO FLIP To set up and delete those functions, enter into JOG MAX SPEED... - Page 25 AL ARM 4 IN HOW TO USE OSD MENU Parking Action Setup <Dome Camera Setup>→<Motion Setup>→<Parking Action Setup> If Park Enable is set to ON, camera runs assigned function automatically PA R K I N G A C T I O N S E T U P if there is no PTZ command during assigned ''Wait Time''.
-
Page 26: Preset Setup
PRESET 128 HOW TO USE OSD MENU PRESET Setup <Dome Camera Setup>→<Preset Setup> (Except [95]) Preset Number [1~128] P R E S E T S E T U P If a selected preset is already defined, camera P R E S E T N O . moves to pre- defined position and preset C L R P R E S E T C A N C E L... - Page 27 HOW TO USE OSD MENU Edi t Pr eset Scene <Dome Camera Setup>→<Preset Setup>→<Edit Scene> Using Joystick, move camera to desired position. E D I T S C E N E - P R E S E T 1 By pressing NEAR key, save current PTZ data.
-
Page 28: Swing Setup
SWING 8 HOW TO USE OSD MENU Swing Setup <Dome Camera Setup>→<Swing Setup> Swing N umber [1~8] S W I N G S E T U P Selects Swing number to edit. If a selected Swing S W I N G N O . has not defined, "NOT USED"... -
Page 29: Pattern Setup
PATTERN 4 HOW TO USE OSD MENU Pattern Setup <Dome Camera Setup>→<Pattern Setup> Pattern Number [1~4] P A T T E R N S E T U P Selects Pattern number to edit P A T T E R B N O . If a selected pattern number is not defined UNDEFINED C L R PAT T E R N... -
Page 30: Group Setup
GROUP 8 HOW TO USE OSD MENU Group Setup <Dome Camera Setup>→<Group Setup> Cr oup N umber [1~8] G R O U P S E T U P Selects Group number to edit GROUP NO . If a selected Group number is not defined UNDEFINED "UNDEFINED"... - Page 31 HOW TO USE OSD MENU Set up items such as Action, ###, Dwell and OPT. EDIT GROUP 1 NO ACTION ### DWELL OPT 1 PRESET 00 : 03 360 2 NONE 3 NONE 4 NONE 5 NONE SAVE MOVE CURSOR ［...
-
Page 32: System Initialize
HOW TO USE OSD MENU System Initialize Clear All Data Deletes all configuration data such as display. SYSTEM I N I T I A L I Z E camera, motion setup and so on. → CLEAR ALL DATA CLR DISPLAY SET Clear Display Set Initializes Display Configuration CLR CAMERA SET... -
Page 33: Specifications
DOME 4.5 " 100X ZOOM DAY & NIGHT SPECIFICATIONS Video Signal System NTSC 1/4"Interline Transfer CCD Max. Pixels 811(H)× 508(V)410K 795(H)× 596(V)470K Effective Pixels 768(H)×494(V)380K 752(H)×582(V)440K Horizontal Res. 500 TV Line(Color),570 TV Line(B/W) S/N Ration 50 dB (AGC Off) Zoom ×10 Optical zoom, ×10 Digital Zoom Focal length F1.8,f=3.8~38mm... -
Page 34: Dimension
SPECIFICATIONS Dimension Ceiling Bracket Pendant Bracket 128 mm 1 27mm Wall Mount Bracket 200.7 mm 162.3 mm 107.7 27mm U nit (mm) Spee d Dome Camera Instruction Manual...
