Summary of Contents for ProVisual CDV-2085IR-WDR
- Page 1 Ultra Wide Dynamic ProVisual, INC. www.provisualusa.com IR Waterproof Dome Camera 3399 NW 72nd Ave. Suite 123 Miami, Florida 33122. United states Phone:(001) 305-594-4151 User's Manual...
- Page 2 Use a mild detergent and wipe gently. 5. Do not put the camera in a place with interference. When this camera is installed near the equipment like wireless communication device which emits strong electromagnetic field, some irregularity such as noise on monitor screen may happen. CDV-2085IR-WDR...
- Page 3 3.Features All directional bracket All directional bracket, easy control. “SEAWOLF” Image Sensor This camera adopts innovative DPS (Digital Pixel System) image sensor and image OSD Menu processing technology. The sensor picks up details from each pixel based on hundreds of samples per video frame. vs CCD's limited exposures, to ensure wider Powerful OSD menu operation function, allows for setting of various parameters and dynamic range than is possible with analog CCD.
- Page 4 4.Parts instruction Camera installation 1. Loose the 3 glass cover screws by screwdriver , CDV-2085IR-WDR take the glass cover out. 2. Loose the Installed setscrews , to separate the 1. Dome Enclosure: to protect subpanel from camera body. camera lens and body.
-
Page 5: Osd Menu Operation
NORMAL (LOW/NORMAL/HIGH) LENS SELECT (MANUAL/DC) FLUORESCENT (OFF/CRR/CRR2) Dipping Rotation D/N CONTROL AUTO (OFF/AUTO/GPIO) LANGAGE SELECT ENGLISH (ENGLISH/CHINESE) CDV-2085IR-WDR SAVE DEFAULT (CANCEL) 5.Dimensions WDR ZONE SELECT: NORMAL METER PRESETS NORMAL METER PRESETS PRESETS WD NORMAL WD NORMAL/SAFE AREA/ATM/LOW 1/3 SAVE CANCEL... -
Page 6: Lens Select
WDR Control: LENS SELECT: Press Enter to show the menu, move the cursor to WDR Control, set MEDIUM, Move cursor to LENS SELECT, set LENS SELECT by Right and Left button as : NORMAL, LOW, HIGH by left and right button, choose the setting for WDR in MANUAL, DC:DC Automatically. -
Page 7: Technical Parameter
Technical parameter: CDV-2085IR-WDR Model Sensor 1/3” DPS Sensor (SEAWOLF) NTSC Video Format Resolution 690HTVL-E 0Lux,(IR-ON ) Mini illumination Image technology PIXIM 3D Noise Reduction S/N Ratio >50dB AGC OFF WDR control Ultra Wide Dynamic Range: Medium / Normal / Low / High...
