Summary of Contents for Mega Lite AR Wash 1W
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information……………………………………………………………………………………………. 3 Specifications…………………………………………………………………………………………………….. 4 Main Power Connection…………………………………………………………………………………..5 DMX-512 Connection…………………………………………………………………...……………..5 Rigging the Fixture......................6 Main Control Menu......................7 DMX Profile......................... 9 Cleaning & Maintenance.................... 10 Parts List........................... 10... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 2 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Specifications Part Numbers Fixture 4042– Arc Wash 1W Mechanical Specifications IP Rating: IP 65 12.5 ” DMX Connectors: Cable mounted 3-pin XLR connectors Fastening System: Mounting Yoke Display: Digital 5 ” Security System: Eye bolt clip 4.25 ” 3 ” Fixture Packaged for Shipping Size: 12.5”L x 7.25”W x 5”H... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: 110V Connection Cable (USA) -
Page 6: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. -
Page 7: Main Control Menu
Main Control Menu The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options. The following will explain each function and its options. Menu Up Down Enter Press the Menu button, Use the up/down keys to select the required function Press Enter to select DMX Modes... - Page 8 Macro Effects Use the Enter keys to select the required macro effect. Use the up/down keys to select options from 1 to 15. Press Menu to confirm. Macro Speed Use the Enter keys to select the required speed of the macro effect. Use the up/down keys to select options from 1 to 15. Press Menu to confirm.
-
Page 9: Dmx Profile
Arc Wash 1W Mode A (8 Channel) DMX Chanel Function Description Value LED Color RED LED intensity 0-255 LED Color Green LED intensity 0-255 LED Color Blue LED intensity 0-255 Dimmer Dimmer Segment 1 0-255 LED Color RED LED intensity 0-255 LED Color Green LED intensity... -
Page 10: Cleaning & Maintenance
Cleaning and maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electron- ics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded. - Page 11 Mega-Lite 5718 Kenwick St San Antonio, TX 78238 Ph 210-684-2600 Fax 210-855-6279 www.mega-lite.com / info@mega-lite.com...
