USER MANUAL
Safety Information...............................................................3
Specifications.....................................................................4
Main Power Connection........................................................5
DMX-512 Connection...........................................................5
Main Control Menu..............................................................6
LED Orientation..................................................................8
Rigging the Fixture..............................................................8
DMX Profile.....................................................................................9
Cleaning & Maintenance...............................................................13
Parts List.......................................................................................13
Advertisement
Table of Contents
Related Manuals for Mega Lite MW1
Summary of Contents for Mega Lite MW1
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information……………………………………...………………3 Specifications………………………………………...…………………4 Main Power Connection…………………………...…………………..5 DMX-512 Connection……………………………..…………………...5 Main Control Menu……………..…………………………………..….6 LED Orientation………………………………………………………...8 Rigging the Fixture……………………………………………………..8 DMX Profile..................9 Cleaning & Maintenance...............13 Parts List..................13... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Specifications Part Numbers Fixture Lamp Flight Case 1215 - MW1 7 Osram RGBW 40W LED CAS-1210-4 Quad Road Case Mechanical Specifications 6.18” Pan: 540° 8/16 Bit Tilt: 270° 8/16 Bit 12.75” 3.75” DMX Connectors: 3 and 5-pin XLR connectors Power Connectors: Power Con Type 2.5”... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. Power link maximum 5 units at 110V This device is equipped with a auto switching power supply that will allow you to work from 100V-240V 50/60Hz The occupation of the connection-cable is as follows: Cable (USA) Cable (EU) -
Page 6: Main Control Menu
Display Control Main Control DMX Yes Mode 14Ch The control board on the fixture base is your interface to access and control all the functions on the unit. It’s LCD display gives you a code Enter Invert view of the options and functions. The following will explain each func- tion and its options. - Page 7 Calibration Main Menu DMX Address Fixture Calibration Manual Warning this function is for trained factory technicians! Information Password Calibration Fixture Reset Pan Fine Tilt Display Tilt Fine Network P/T Speed Fixture Reset Main Menu DMX Address Fixture Fixture Reset Manual Lets you reset motor function on the fixture Information Motor Reset...
-
Page 8: Led Orientation
LED Orientation Rigging the fixture Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained professional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. 3. Unit is to be 24inches away from flammable materials (decoration material) 4. -
Page 9: Dmx Profile
DMX Profile MW1 11Ch Mode DMX Channel Function Description Value Init Value Pan Course 0-255 Pan Fine Tilt Course 0-255 Tilt Pan Fine 0-255 Tilt Fine Tilt Fine 0-255 P/T Speed Pan and Tilt Speed (fast to slow) 0-255 Closed... - Page 10 MW1 18 Ch Mode Init Function Description Value Channel Value 0-255 Pan Fine Pan Fine 0-255 Tilt Tilt 0-255 Tilt Fine Tilt Fine 0-255 P/T Speed Pan and Tilt Speed (fast to slow) 0-255 Dimmer Dimmer Off to Full 0-255...
- Page 11 Shutter Macro Speed (slow to fast) 0-255 Back Ground Back Ground Color 0-255 Zoom Zoom (wide to narrow) 0-255 Control No Function 0-250 Fixture Reset 251-255 MW1 38 Ch Mode Init DMX Channel Function Description Value Value 0-255 Pan Fine Pan Fine 0-255 Tilt Tilt...
- Page 12 LED Color Red 3 0-255 LED Color Green 3 0-255 LED Color Blue 3 0-255 LED Color White 3 0-255 LED Color Red 4 0-255 LED Color Green 4 0-255 LED Color Blue 4 0-255 LED Color White 4 0-255 LED Color Red 5 0-255...
-
Page 13: Cleaning & Maintenance
Cleaning and Maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electronics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded. - Page 14 Customer Support Mega Lite has a customer support line to provide set up help and to answer any question should you encounter a prob- lem. Please visit our website for any other related technical documents. For service related issue please contact our service dept.
