Mega Lite Halo 5R User Manual

Hide thumbs

Advertisement

Quick Links

USER MANUAL

Table of Contents

Safety Information
Features
DMX Profile......................................................................................................................... 8
Cleaning & Maintenance.............................................................................................10
Parts List............................................................................................................................10
. 3
.. 4
...5
.. 6
...
...... 6
...7

Advertisement

loading
Need help?

Need help?

Do you have a question about the Halo 5R and is the answer not in the manual?

Questions and answers

Related Manuals for Mega Lite Halo 5R

Summary of Contents for Mega Lite Halo 5R

  • Page 1: Table Of Contents

    USER MANUAL Table of Contents Safety Information Specifications .. 4 Features ...5 Main Power Connection .. 6 DMX-512 Connection ..6 Main Control Menu ...7 DMX Profile......................... 8 Cleaning & Maintenance.....................10 Parts List..........................10...
  • Page 3 Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5.

  • Page 4: Specifications

    Specifications Part Numbers Fixture 1200-Halo 5r Mechanical Specifications Lamp: Phillips 5R lamp LED lamp: 16 RGB Series 3in1 LED s Pan: 480° Tilt: 280° Rotating Gobo: 1 Rotating Gobo wheel 7 Gobos +open Gobo flow effect Gobo roto bounce effect...
  • Page 5 Color 1: Open 2: Red 3: Green 4: Yellow 5: Blue 6: Magenta 7: Orange 8: Light Blue Gobo s Rotating Gobo Wheel 1: Open 2: Gobo 1 3: Gobo 2 4: Gobo 3 5: Gobo 4 6: Gobo 5 7: Gobo 6 8: Gobo 7 Note;...

  • Page 6: Main Power Connection

    Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. This device is equipped with a auto switching power supply that will allow you to work from 100V-240V 50/60Hz The occupation of the connection-cable is as follows: Cable (USA) Cable (EU)

  • Page 7: Main Control Menu

    Main Control Menu The control board on the fixture base is your interface to access and control all the functions on the unit. Its digital display gives you a code view of the options and functions. The following will explain each function and its options. 5718 Kenwick St San Antonio.
  • Page 8 Set Pan Press Enter to confirm Reverse (No) (Yes) Use the up/down keys to select the Pan movements reversed. Press Enter to confirm Set Tilt Press Enter to confirm Reverse Tilt Tilt (No) (Yes) Use the up/down keys to select the Tilt movements reversed. Press Enter to confirm System Press Enter to confirm Reset...

  • Page 9: Dmx Profile

    DMX Profile Halo 5R 15 Channel Mode DMX Channel Function Description Value 0-255 Pan Fine Pan Fine 0-255 Tilt Tilt 0-255 Tilt Fine Tilt fine 0-255 Fast 0-84 85-170 Pan/Tilt Speed Slow 171-255 No Function 0-249 Control Reset 250-254 No Function...
  • Page 10 0-63 Prism 64-255 No Function 0-15 Prism Rotate Prism Rota Clockwise (Slow to Fast) 16-136 Prism Rota Counter Clockwise (Fast to Slow) 137-255 Halo 5R 19 Channel Mode DMX Channel Function Description Value 0-255 Pan Fine Pan Fine 0-255 Tilt...
  • Page 11 Green Pulse (slow to fast) 170-199 Blue Pulse (slow to fast) 200-229 White Pulse (slow to fast) 230-255 LED Strobe Strobe (slow to fast) 0-255 Halo 5R 29 Channel Mode DMX Channel Function Description Value 0-255 Pan Fine Pan Fine 0-255...
  • Page 12 Open 0-15 16-31 Green 32-47 Yellow 48-63 Colors Blue 64-79 Magenta 80-95 Orange 96-111 Light Blue 112-127 Forward and Backward Rainbow Effect (slow to fast) 128-255 Open 0-15 Gobo 1 16-31 Gobo 2 32-47 Gobo 3 48-63 Gobo 4 64-79 Gobo Gobo 5 80-95...

  • Page 13: Cleaning & Maintenance

    Cleaning and maintenance Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electron- ics checked by an expert every 2 years. The following points have to be considered during the inspection: 1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.

  • Page 14: Warranty Information

    Warranty Information Limited Warranty Unless otherwise stated, your product is covered by a one year parts and labor limited warranty. Dichroic filters and glass gobos are not guaranteed against breakage or scratches to coating. It is the owner s responsibility to furnish receipts or invoices for verification of purchase, date, and dealer or distributor.
