USER MANUAL
Safety Information........................................................................3
Specifications..............................................................................4
Main Power Connection.................................................................5
DMX-512 Connection....................................................................5
DMX Profile ................................................................................................6
Main Control Menu......................................................................................7
Rigging the Fixture........................................................................8
Cleaning & Maintenance.............................................................................8
Parts List.....................................................................................................8
Advertisement
Table of Contents
Related Manuals for Mega Lite drama z fresnel 200
Summary of Contents for Mega Lite drama z fresnel 200
-
Page 1: Table Of Contents
USER MANUAL Table of Contents Safety Information………………………………………………………………3 Specifications…………………………………………………………………...4 Main Power Connection………………………………………………………..5 DMX-512 Connection…………………………………………………………..5 DMX Profile ....................6 Main Control Menu..................7 Rigging the Fixture……………………………………………………………...8 Cleaning & Maintenance................8 Parts List.....................8... -
Page 3: Table Of Contents Safety Information
Check that the unit has not been damaged during transport Protection Against Fire 1. Maintain a minimum of 1 foot distance from any type of flame. 3. Replace fuse only with the specified type and rating. 4. Do Not install the unit to close to a heat source. 5. -
Page 4: Specifications
Technical Information Part Numbers Fixture 7025-CW Drama Z Fresnel 200 Cool White 7025-WW Drama Z Fresnel 200 Warm White 7025-BD Removable Barn Door (included) 70250GH removable Gel Holder (accessory) Mechanical Specifications 17.25” / 18.5” With Cable DMX Connectors: 3 and 5 pin XLR connectors in/out... -
Page 5: Main Power Connection
Main Power Connection Caution! Do not connect fixture to a dimmer system. This unit has Auto switching power supply. It will respond to 110V or 220V automatically This unit must be earthed. (electronically grounded) Replace fuse only with the specified type and rating. The occupation of the connection-cable is as follows: This fixture is equipped with an electronic power supply that will let the unit operate from 100V to 240V from 50Hz to Cable (USA) -
Page 6: Dmx Profile
DMX Profile Drama Z Fresnel Mode 2 CH DMX Chanel Function Description Value Dimmer LED intensity 0-255 Zoom Linear Zoom 0-255 Drama Z Fresnel Mode 3 CH DMX Chanel Function Descriptions Value Dimmer LED intensity 0-255 Zoom Linear Zoom 0-255 No Function Strobe (slow to fast) 1-127... -
Page 7: Main Control Menu
Main Control The control board on the fixture base is your interface to access and control all the functions on the unit. It’s digital display gives you a code view of the options and functions. The following will explain each func- tion and its options. -
Page 8: Rigging The Fixture
Rigging the fixture Caution! 1. The installations must be carried out by an authorized dealer or trained profes- sional. 2. Unit may cause severe injures if you have doubts concerning the safety do not install. When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi- ence including but not limited to calculating working loads, material being used and periodic safety inspections. -
Page 9: Warranty Information
Warranty Information Warranty Conditions -Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty. -LEDs are not guaranteed to match in color temperature or output. -It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor. If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
