Summary of Contents for THOR THPS-600R-12

  • Page 1 THPS-600R Series Pure Sine Wave Inverter User’s Manual...
  • Page 2: Table Of Contents

    AC Safety Grounding………………………………………………….. 12~13 DC Wiring Connections…………………….…………………………. 13~14 Inverter Operation……………………………………………………… 4. Troubleshooting……….……………………………………………………… 5. Maintenance…………………………………………………………………… 6. Warranty……………………………………………………………………….. Copyright :This manual is the copyright of Thor Manufacturing. Inc. And may not be reproduced or copied without the express permission of the owner.
  • Page 3: Important Safety Information

    1. Important Safety Information WARNING! Before installing and using the Inverter, you need to read Following safety information carefully. 1-1. General Safety Precautions 1-1-1. Do not expose the Inverter to water, mist, snow, or dust. To reduce the risk of hazard, do not cover or obstruct the ventilation shaft. Do not install the Inverter in a zero-clearance compartment.
  • Page 4: Features

    2. Features Pure sine wave output (THD < 3%) Output frequency:50 / 60Hz switch selections Input & output fully isolated design High efficiency 88~94% Driving highly reactive & capacitive load at start moment. Tri-Color indicators show input voltage & output load level Loading controlled cooling fan Advanced microprocessor Protection:Input low voltage...
  • Page 5: Electrical Performance

    2-2. Electrical Performance Model No. Specification Item THPS-600R-12 THPS600R-24 THPS-600R-48 THPS-600R-212 THPS-600R-224 THPS-600R-248 Input voltage 100 / 110 / 120V +/- 5% 220 / 230 / 240V +/- 3% Output Voltage Frequency 50 / 60Hz +/- 0.05% (Switch Selections) Efficiency (full load) 87.0%...
  • Page 6: Mechanical Drawings

    2-3. Mechanical Drawing 7 [0.28] 179 [7.05] PURE SINE WAVE INVERTER INPUT LEVEL LOAD LEVEL FAULT AC OUTPUT FREQ. 50Hz 60Hz 151.01 [5.95]...
  • Page 7: Instructions

    3. Instructions This power inverter series is one of the most advanced line of mobile AC power systems. To get the most effective power inverter, it must be installed and used properly. Please read the instructions of this manual before you install and operate this model.
  • Page 8 3-1-4. Load Level:Display AC Load Watts LED Status Load Condition Orange 200W ~ 450W Red Blink Over 580W 3-1-5. Failure:Display failure status OVP:over voltage protection UVP:under voltage protection OTP:over temperature protection OLP:over load protection 3-1-6. AC outlet (Outlet Sockets available): North America (GFCI) North America Continental Europe (SCHUKO)
  • Page 9: Rear Panel Operation

    3-2. Rear Panel Operation: DC INPUT WARNING : REVERSE POLARITY WILL DAMAGE UNIT NEG(-) POS(+) CHASSIS GROUND DC INPUT WARNING : REVERSE POLARITY WILL DAMAGE UNIT REMOTE PORT NEG(-) POS(+) CHASSIS GROUND 3-2-1. Remote ON / OFF switch for S600R model only. 3-2-1-1.
  • Page 10 3-2-2. Ventilation Shaft: Be sure to keep it a distance (at least 1 inch) form surrounding things. 3-2-3. Input terminals: Connect the input terminal to 12V / 24V / 48V battery or other 12V / 24V /48V power source. 【+】represents positive, and【-】represents negative. Reverse polarity connection will blow the internal fuse and may damage the inverter permanently.
  • Page 11: Installation

    3-3. Installation: The power inverter should be installed in an environment that meets the following requirements: 3-3-1. Dry – Do not allow water to drip on or enter into the inverter. 3-3-2. Cool – Ambient air temperature should be between 0℃ and 33℃, the cooler the better.
  • Page 12: Quick Hook - Up And Testing

    3-4. Quick hook – up and testing: For a quick hook – up of the power inverter to check its performance before going ahead with installation, please follow these guidelines: 3-4-1. To check its performance, unpack and inspect the power inverter the switch is OFF.
  • Page 13 3-4-3. Before proceeding further, carefully check that cable you have connected does tie negative terminal of inverter to the negative output power source. CAUTION ! Reverse polarity connection will blow the fuse in inverter and may permanently damage the inverter. Damage caused by reverse polarity connection is not covered by warranty.
  • Page 14: Ac Safety Grounding

    3-5. AC Safety Grounding: During the AC wiring installation, AC input and output ground wires are connected to the inverter. The AC input ground wire must be connected to the incoming ground from AC utility source. The AC output ground wire should go to the grounding point for your loads ( for example, a distribution panel ground bus ).
  • Page 15: Dc Wiring Connections

    While the pure sine wave output of the Inverter is equivalent to the waveform provided by utilities, compliance with UL standards requires us to test and recommend specific GFCI. Thor Mftg. has tested the following GFCI – protected 20A receptacles and found that they function properly when connected to output.
  • Page 16 Increasing DC cable size helps improve the situation. Thor Mftg. Inc. recommends the following cables for optimum inverter performance. (apply both 120V and 230V versions) Model No Wire AWG Inline Fuse THPS-600R-12 100A THPS-600R-24 100A THPS-600R-212 THPS-600R-224 Also, use only high quality copper wiring and keep cable length short, (a maximum of 3-6 feet).
  • Page 17: Inverter Operation

    42.0 to 60.0 VDC for 48V models The Inverter will indicate high and low DC voltage conditions as follows: Dc Input over Dc Input under Dc Input under Model Voltage shut-down Voltage alarm Voltage shut-down THPS-600R-12 15.3 11.0 10.5 THPS-600R-24 30.6 22.0 21.0 THPS-600R-48 61.2 44.0...
  • Page 18: Troubleshooting

    4. Troubleshooting: WARNING! Do not open or disassemble the THPS-600R Inverter. Attempting to service the unit yourself may cause an electrical shock or fire. Problems and Symptoms Possible Cause Solutions Low output voltage Using average reading Use true RMS reading (110V:195-105VAC, Voltmeter.
  • Page 19: Maintenance

    24 months from the date of purchase and will repair or replace any defective power inverters if you directly returned them to us with postage paid. Please note that Thor Mftg. is only responsible for ensuring our products are operational before delivering. This warranty will be considered void if the unit has been misused, altered, or accidentally damaged.
  • Page 20 Thor Manufacturing Inc. 7050 W Palmetto Park Rd Suite 15 Boca Raton, FL 33433 Toll free phone: 1-866-955-THOR (8467) Web: http://www.thorpowerproducts.com...
