  • Page 1 THPS 1000, 2000 & 3000 Series Pure Sine Wave Inverter User’s Manual...

  • Page 2: Important Safety Instructions

    1. Important Safety Instructions WARNING! Before using the Inverter, read and save the safety instructions. 1-1. General Safety Precautions 1-1-1. Do not expose the Inverter to rain, snow, spray, bilge or dust. To reduce risk of hazard, do not cover or obstruct the ventilation openings.
  • Page 3 2. Features Pure sine wave output (THD < 3%) Output frequency：50 / 60Hz switch selections Input & output fully isolated design Power Saving Mode to conserve energy High efficiency 89~94% Driving highly reactive & capacitive loads at start moment Tri-Color indicators show input voltage & output load level Loading controlled cooling fan Advanced microprocessor Protection：Input low voltage...
  • Page 4 Model No. Specification Item THPS-1000-12 THPS-1000-24 THPS-1000-48 THPS-1000-212 THPS-1000-224 THPS-1000-248 Input voltage 100 / 110 / 120V +/- 5% 220 / 230 / 240V +/- 3% Output Voltage Frequency 50 / 60Hz +/- 0.05% (Switch Selectable) < Efficiency (full load) Max. 89.0% 92.0% 93.0%...
  • Page 5 Model No. Specification Item THPS-2000-12 THPS-2000-24 THPS-2000-48 THPS-2000-212 THPS-2000-224 THPS-2000-248 Input voltage 100 / 110 / 120V +/- 5% 220 / 230 / 240V +/- 3% Output Voltage Frequency 50 / 60Hz +/- 0.05% (Switch Selectable) < Efficiency (full load) Max. 89.0% 92.0% 93.0%...
  • Page 6 Model No. Specification Item THPS-3000-12 THPS-3000-24 THPS-3000-48 THPS-3000-212 THPS-3000-224 THPS-3000-248 Input voltage 100 / 110 / 120V +/- 5% 220 / 230 / 240V +/- 3% Output Voltage Frequency 50 / 60Hz +/- 0.05% (Switch Selectable) < Efficiency (full load) Max. 88.0% 91.0% 92.0%...

  • Page 7: Mechanical Drawings

    2-3. Mechanical Drawings THPS1000 154.00 [6.06] PURE SI NE WAVE IN VERT ER 10 00 W INPUT LEVEL LOAD LEVEL ST A TU S REMOTE FREQ. PWR. S AV . AC OU TP UT THPS1000 182.00[7.17]...
  • Page 8 177.00 [6.97] PURE SINE WAVE INVERTER REMO. INPUT LEVEL LOAD LEVEL STATUS FREQ. PWR. SAV. AC OUTPUT 209.00 [8.23]...

  • Page 9: Front Panel Operations

    3. Introduction This power inverter series is one of the most advanced line of mobile AC power systems. To get the most effective power inverter, it must be installed and used properly. Please read the instructions of this manual before you install and operate this model.
  • Page 10 3-1-3. Input Level：Display Input Voltages LED Status DC 12V DC 24V DC 48V RED Slow Blink 10.3~10.6 20.5~21.2 40.8~42.4 10.6~11.0 21.2~21.8 42.4~43.5 ORANGE 11.0~12.1 21.8~24.1 43.5~48.1 GREEN 12.1~14.2 24.1~28.6 48.1~56.3 ORANGE Blink 14.2~15.0 28.6~30.0 56.3~59.6 OVER RED Blink 15.0 30.0 59.6 3-1-4.
  • Page 11 3-1-6. Status：Display Power & Fault Status Green LED LED Signal Status Solid Power OK Slow Blink Power Saving Red LED LED Signal Status n i l n i l Intermittent Blink d i l 3-1-7. Power Saving Mode: Power Saving Mode is adjustable and set by the Dip Switches, S1, S2 and S3 on the front panel.
  • Page 12 3-1-8. AC outlets (available): North America (GFCI) NEMA 5-20R Continental European NEMA 5-15R Australia / New Zealand United Kingldom Universal IEC-1 HARD WIRE IEC-2...

  • Page 13: Rear Panel Operations

    3-2. Rear Panel Operations： DC INPUT POS(+) NEG(-) THPS-1000 REMOTE PORT CHASSIS GROUND REVERSE POLARITY WILL DAMAGE UNIT THPS-2000 THPS-3000 POS(+) DC INPUT NEG(-) REMOTE WARNING: PORT REVERSE POLARITY WILL DAMAGE UNIT CHASSIS SHOCK HAZARD. GROUND DO NOT OPEN. NO USER SERVICEABLE PARTS INSIDE.
  • Page 14 3-2-3. DC Input Terminal： Connect DC input terminal to 12V / 24V / 48V battery or the other power sources. 【＋】represents positive, and【－】represents negative. Reverse polarity connection will blow the internal fuse and may damage the inverter permanently. DC Input Voltage Model Minimum Maximum...
  • Page 15 3-4. Installation： The power inverter should be installed in an environment that meets the following requirements： 3-4-1. Dry – Do not allow water to drip on or enter into the inverter. 3-4-2. Cool – Ambient air temperature should be between 0℃ and 40℃, the cooler the better.
  • Page 16 3-5. DC Wiring Connections： Follow this procedure to connect the battery cables to the DC input terminals of the Inverter. The cables should be as short as possible (less than 10 feet / 3 meters ideally) and large enough to handle the required current in accordance with the electrical codes or regulations applicable to the installation.

  • Page 17: Loose Connections

    3-5-1. Connect the cables to the power input terminals on the rear panel of the inverter. The red terminal is represents positive (+) and black terminal represents negative (-). Insert the cables into the terminals and tighten the screw to clamp the wires securely. WARNING! Ensure all the DC connections are tight (torque to 9 –...
  • Page 18 THPS-1000 DC INPUT POS(+) NEG(-) REMOTE PORT CHASSIS GROUND INLINE FUSE BATTERY THPS-2000 THPS-3000 Battery to inverter cable connection POS(+) DC INPUT NEG(-) REMOTE WARNING: PORT REVERSE POLARITY WILL DAMAGE UNIT CHASSIS SHOCK HAZARD. GROUND DO NOT OPEN. NO USER SERVICEABLE PARTS INSIDE.
  • Page 19 3-6. AC Safety Grounding The AC output ground wire should go to the grounding point for your loads ( for example, a distribution panel ground bus ). 3-6-1. Neutral Grounding (GFCI’S) 3-6-1-1. 120V models The neutral conductor of the AC output circuit of the Inverter is automatically connected to the safety ground during inverter operation.
  • Page 20 3-7. Inverter Operation： To operate the power inverter, use the ON / OFF switch on the Front panel to turn the power on. Then the power inverter is ready to deliver AC power to your loads. If there is several loads use, turn them on separately after the inverter is “ON”...

  • Page 21: Troubleshooting

    4. Troubleshooting： WARNING! Do not open or disassemble the Inverter. Attempting to service the unit yourself may cause the risk of electrical shock or fire. Problems and Symptoms Possible Cause Solutions “No AC Power Output” STATUS illuminates the red LED a.

  • Page 22: Maintenance

    5. Maintenance： To keep your inverter operating properly, there is very little maintenance required. You should clean the exterior periodically with a damp cloth to prevent accumulation of dust and dirt. At the same time, tighten the screws on the DC input terminals.
