  • Page 1: Color Monitor

    Color Monitor C170 English User’s Guide...
  • Page 2 First Edition (August / 2004) Note : For important information, refer to the Monitor Safety and Warranty manual that comes with this monitor. ii i...
  • Page 3: Table Of Contents

    Safety (Read first)...2 Setting up the monitor ...3 Product Description...3 Workplace preparation ...3 Working Practices ...4 Caring for your Monitor ...4 Connecting your Monitor...5 Switching on your Monitor...6 Device Driver Installation...7 Windows 95/98 ...7 Windows 2000/Me...8 Windows XP ...9 Adjusting Your Monitor...10 User controls...10 On-screen display (OSD) controls...11 Further Information ...15...
  • Page 4: Safety (Read First)

    í í í...
  • Page 5: Setting Up The Monitor

    SVGA 800 x 600, or VGA 640 x 480 at 60Hz. In addition to your monitor, your option package includes the following: User's Guide and Installation Files CD • Monitor Safety and Warranty Information Manual • C170 Color Monitor Quick Setup Guide • Power Cord • C170 Color Monitor •...
  • Page 6: Working Practices

    • Gently wipe the covers and the screen with a soft cloth. Do not use solvents or abrasives. • Remove finger marks and grease with a damp cloth and mild detergent. • Never use flammable cleaning materials to clean your IBM monitor or any other electrical apparatus.
  • Page 7: Connecting Your Monitor

    Connecting your Monitor Be sure to read the ‘Safety’ • Before setting up the monitor, ensure that the power is turned off to the Information located in the monitor, computer system, and other attached devices. Monitor Safety and Warranty • Carefully set the monitor face-down with the underside facing you. Information Manual before carrying out this procedure.
  • Page 8: Switching On Your Monitor

    Switching on your Monitor 1. Switch on your computer. 2. Switch on your monitor by pushing and releasing the power switch marked [ at the front of the bezel. [To switch off your monitor, push and release the power switch again.] 3.
  • Page 9: Device Driver Installation

    9. Ensure that the CD drive letter is selected, and then select the DRIVERS folder. 10.Select IBM C170 monitor and click OK. The files will be copied from the CD to your hard disk drive. 11.Close all open windows and remove the CD.
  • Page 10: Windows 2000/Me

    14.Ensure that the CD drive letter is selected, and then select the DRIVERS folder. 15.Select IBM C170 monitor and click OK. The files will be copied from the CD to your hard disk drive. 16.Close all open windows and remove the CD.
  • Page 11 14.Ensure that the CD drive letter is selected, and then select the DRIVERS folder. 15.Select IBM C170 monitor and click OK. The files will be copied from the CD to your hard disk drive. 16.Close all open windows and remove the CD.
  • Page 12: Adjusting Your Monitor

    Adjusting Your Monitor User controls The image is already optimized for many display modes, however the user controls can be used to adjust the image to your liking. The settings are saved after adjustment and when exiting the OSD and will be effective thereafter.
  • Page 13: On-Screen Display (Osd) Controls

    On-screen display (OSD) controls The settings adjustable with the user controls are viewed through the On - The LCD monitor needs Screen Display (OSD). Press the enter button [ time to become thermally menu. stable the first time you turn it on each day.
  • Page 14 OSD Icon Horizontal Image Position Position/Size Vertical Position Horizontal Size Vertical Size Rotation Parallelogram Image Shape Trapezoid Pincushion Pincushion Balance Geometry Reset Description Moves the screen left and right . Moves the screen up and down. Adjusts image width Adjusts image height Turns image clockwise or counterclockwise To correctly adjust the skew of the...
  • Page 15 OSD Icon Select from standard white colors. Preset Color Color Adjusts Red, Green and Blue intensity User Color Point Resets custom color to original value Reset Custom Color Display the detailed information of resolution, model name and microcode. Information Options The language chosen affects only the language of the OSD.
  • Page 16 OSD Icon Factory Default Options Menu Position Video Input Level Exit Description Reset should return all available functions (apart from language which should not change unless adjusted via the LANGUAGE menu) to their factory presets. Changes the position of the OSD on the screen.
  • Page 17: Further Information

    Further Information The display mode the monitor uses is controlled by the computer. Therefore, Display modes refer to your computer documentation for details on how to change display modes. If possible, configure your computer for 1024 x 768 addressability at 85Hz vertical refresh rate.
  • Page 18: Power Management

    Power State Indicator Steady green Active off Steady amber * There may be a slight delay before the picture reappears. Partner, IBM has determined that this product ® guidelines for energy efficiency. Restoring Screen Operation Normal Press a key or Blank move the mouse.*...
  • Page 19: Troubleshooting

    Troubleshooting If you have a problem setting up or using your monitor, you may be able to solve it yourself. Before calling your retailer or IBM, try the suggested actions that are appropriate to your problem. Problem Screen is blank and power indicator is off.
  • Page 20 Possible Problem Cause CHECK The monitor is SIGNAL CABLE not receiving a message is video signal shown and power indicator is steady green. Image appears The color setting to be discolored may be incorrect. Suggested Action Check that the signal cable is firmly connected to the computer.
  • Page 21: Help And Service Information

    If you are unable to correct the problem yourself, you may seek further help as follows: Call the IBM Support Center In other countries contact your dealer, retailer, or other IBM authorized If possible, stay by your computer. Your Technical Servicer.
  • Page 22: Specifications

    < 5 W Separate, RGB Analog, 0.7Vp-p/75 ohm, positive Separate DDC 2B IBM, VESA 30-85 kHz 50-160Hz 10 to 40° C (50 to 95° F) - 20 to 60° C (-4 to 140° F) - 20 to 60° C (-4 to 140° F)
  • Page 23: Service Information

    Service Information The following parts are for use by IBM service, or IBM authorized dealers, to support the customer warranty. Parts are for service use only. 31P9652 31P9653 31P9654 31P9655 31P9656 31P9657 31P9661 31P9745 Model Type 6737 Video Description US,CAN,EMEA...
  • Page 24: Notices And Trademarks

    Any reference to an IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property right may be used instead.
  • Page 25 Trademarks The following terms, used in this publication, are trademarks or service marks of the IBM Corporation in the United States, other countries, or both; HelpCenter and the E logo are U.S Govt. registered trademarks. NERGY NERGY Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in the United States, other countries, of both.
