IMPORTANT SAFETY AND CARE INFORMATION PLEASE READ BEFORE SETTING UP YOUR TENT/SHELTER At the time of purchase we guarantee that this product is supplied without fault in construction, materials or function. We recommend that you assemble it as a trial before going away.
Page 3
To prevent injury caused by fire - • Do not pitch the tent/shelter near a camp fire or any other flame source • Do not use candles, matches or any other flame source in or near the tent (this includes stoves, cooking equipment, lighting and heating appliances) •...
Check that all parts are present and that you familiarise yourself with the assembly and disassembly of the product. If you have any problems, your OZtrail dealer will be able to sort it out for you. You should have the following parts: -...
Page 5
PRODUCT AND PARTS Part Description Cont. 2 x Spreader Bar (901) 1 x Tent Bag 1 x Pole Bag 1 x Peg Bag 18 x Pegs 6 x Guy Ropes...
ASSEMBLY INSTRUCTIONS Step 1 Site selection Select a sheltered camp site protected from the wind that will not allow water to pond under the tent floor. Clear a level area of all stones, twigs, etc. Step 2 Unpack your tent Unpack the contents of your tent.
Page 7
ASSEMBLY INSTRUCTIONS Step 5 Setting up the awning These steps require one or more people to do safely. I.Select the three awning spreader bars (801). These poles have a bent spigot at one end and a flat eyelet end. Place the bent spigot end into pre-drilled holes on the three adjustable roof supports under the awning ( 2 x 014 and 1 x 011 ).
Page 8
FIGURES AND ILLUSTRATIONS Figure 1 Webbing Loops Peg Loops Side Ridge Ridge Pole Sleeve Pole Sleeve...
Page 10
DISASSEMBLY INSTRUCTIONS Step Release guy ropes. Step Unzip doors and windows and collapse the tent, removing and disassembling the poles. Place the poles in the pole carry bag and tie shut. Step Remove pegs. Do not remove pegs from the ground by pulling on peg loops. This may cause the peg loops to tear out of the seam.
FOLDING INSTRUCTIONS Figure 3 Fold tent into a The width of Rectangular shape the tent should not exceed the length of the pole bag Front of tent R OLL (door unzipped)
PROLONGING THE LIFE OF YOUR TENT/SHELTER •Intermittent use only. Although our polyester fabrics are treated for extra UV resistance, continuous exposure to sun light will break the fabric down. Fading of colour is an early warning sign. These tents/shelters are not designed as permanent dwellings or structures.
UNDERSTANDING WATERPROOFNESS What is not covered by warranty! OZtrail tents use waterproof and water repellent fabrics. However, with the addition of seams, zips and other desirable features a recreational tent will not be as waterproof as a car, house or other solid structures. The following are common examples of how water can enter a tent: - Condensation - When warm moist air meets cooler air, condensation occurs.
Page 14
Replacing shock-cord in tent poles Use this procedure to replace broken or untied Shock-Cord:- 1. Start by cutting the Shock-Cord to 2/3’s the length of the Tent Pole 2. Feed the cord through the first pole section and tie a double knot. The knot will catch on the end of the fibreglass pole inside the ferrule.
Page 15
ZIPS Reducing the risk of jamming fabric in the zip ~ • When using the zip, hold the pull-tab between your thumb and forefinger with your thumb facing you. •As you are closing the zip clear the way in front and under the zip slider using the back of your hand, and cup the zip slider underneath with your remaining 3 fingers.
Page 16
In addition, defects resulting from intentional damage, negligence or unreasonable use will void the warranty. This warranty does not cover incidental expenses including property damage. Imported by: OZtrail Leisure Products PO Box 1, Sumner Park QLD 4074 www.oztrail.com.au Made in China...
