- Page 1 Mini Analog Speed Dome User Manual UD.6L0201D1200A01...
- Page 2 User Manual of Mini Analog Speed Dome Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact the dealer. This manual is applicable to Mini Analog Speed Dome. This manual may contain several technically inaccurate points or printing errors, and the content is subject to change without notice.
-
Page 3: Regulatory Information
User Manual of Mini Analog Speed Dome Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 4: Safety Instruction
User Manual of Mini Analog Speed Dome Safety Instruction These instructions are intended to ensure that the user can use the product correctly to avoid danger or property loss. The precaution measure is divided into ‘Warnings’ and ‘Cautions’: Warnings: Serious injury or death may be caused if any of these warnings are neglected. - Page 5 User Manual of Mini Analog Speed Dome Cautions: Make sure the power supply voltage is correct before using the product. Do not drop the product or subject it to physical shock. Do not install the product on vibratory surface or places.
-
Page 6: Table Of Contents
User Manual of Mini Analog Speed Dome Table of Contents Chapter 1 Overview .............................. 6 Description ..............................6 Functions ..............................6 Chapter 2 Getting Started ............................. 8 Power-up Action ............................8 Basic Operations............................9 System-defined Presets ..........................9 On-screen Displays ............................10 Chapter 3 Menu Operation ..........................11... -
Page 7: Chapter 1 Overview
User Manual of Mini Analog Speed Dome Chapter 1 Overview 1.1 Description Integrated with the built-in pan/tilt unit, the mini speed dome features highly sensitive response and reliable performance. The speed dome can be adopted in various surveillance fields with its full-integral functions and features, such as corridor, large venue, meeting room, station, community, etc. - Page 8 User Manual of Mini Analog Speed Dome Privacy Mask The privacy mask allows a user to program user-defined areas that cannot be viewed by the operator of the dome system. A masked area will move with pan and tilt functions and automatically adjust in size as the lens zooms telephoto and wide.
-
Page 9: Chapter 2 Getting Started
User Manual of Mini Analog Speed Dome Chapter 2 Getting Started 2.1 Power-up Action After the power is connected, the speed dome will perform a series of self-test actions. It performs lens actions firstly, then the panning movement and the tilting movement at last. After the power-up self-test actions, the system information will be displayed for 2 minutes on the live view screen as shown below. -
Page 10: Basic Operations
User Manual of Mini Analog Speed Dome 2.2 Basic Operations You can operate the speed dome using a control device. The control devices include the control keyboards, DVRs, DVSs, etc. In this and the following chapters, operation of the speed dome by the IE browser of a DVR will be taken as an example. -
Page 11: On-Screen Displays
User Manual of Mini Analog Speed Dome Note: For Manchester code control protocol, the system-defined presets with special functions are shown as below: Table 1-1 System-defined Presets of Manchester Code Control Protocol Set Preset Function Call Preset Function Remote reboot... -
Page 12: Chapter 3 Menu Operation
User Manual of Mini Analog Speed Dome Chapter 3 Menu Operation The OSD menu tree is shown in the following figure. Note: The menu varies depending on the model of speed dome. MAIN MENUS RESTORE DOME SYS INFO DEFAULTS SETTINGS... -
Page 13: Configuring System Information
User Manual of Mini Analog Speed Dome 4. For PELCO-P/D and other private PTZ protocols, call preset 95 from the preset list in the PTZ control panel of the DVR. MAIN MENUS <SYS INFO> <DOME SETTINGS> <RESTORE DEFAULTS> <RESTORE CAMERA>... -
Page 14: Configuring System Parameters
User Manual of Mini Analog Speed Dome similar to the system information shown after the power-up action. Please refer to Section 2.1 for more details. Enter the system information display menu: MAIN MENUS > SYS INFO SYS INFO TYPE DS- XXXXX-X... - Page 15 User Manual of Mini Analog Speed Dome If the SOFT ADDR is set to OFF, the hard address set by the DIP switch is the valid address of the speed dome. Task 2: Set the broadcast address of the speed dome.
-
Page 16: Protocol Settings
User Manual of Mini Analog Speed Dome 3. Click IRIS+ button to confirm and exit. Fan parameter configuration You can set the FAN CONTROL as ON, TEMP or OFF. Heat parameter configuration You can set the HEAT CONTROL as ON, TEMP or OFF. -
Page 17: Configuring Image Parameters
User Manual of Mini Analog Speed Dome Configure the N/M LED CURRENT and FAR LED CURRENT to adjust the brightness of NEAR, MEDIUM and FAR LEDs. HEIGHT(M): Set the reference height for the speed dome. The value ranges from 1 to 10m. - Page 18 User Manual of Mini Analog Speed Dome Setting the focus mode Steps: (1) Move the cursor to FOCUS using the direction buttons and click IRIS+ to enter. (2) Click up/down direction buttons to set the focus mode to AF, MF or HAF.
- Page 19 User Manual of Mini Analog Speed Dome AUTO: The speed dome is capable of automatically switching from Black and White mode (NIGHT) and Color mode (DAY) regarding to the lightening conditions. It is the default mode. NIGHT (B/W): You can switch the IR cut filter into Black and White mode to increase then lens sensitivity in low light conditions DAY (Color): You can switch it to DAY mode in normal lighting conditions.
- Page 20 User Manual of Mini Analog Speed Dome Set the Gain Gain value. The value of gain indicates the amplification degree of the original image signal. You can set the value from 0 to 15. Gain limit. The higher gain value you set, the more noises will appear in the image. You can set the maximum user configurable gain value from 0 to 15 to limit the gain range and control the noises in the image.
-
Page 21: Configuring Privacy Mask
User Manual of Mini Analog Speed Dome Selecting this mode, the viewed image retains color balance automatically according to the current color temperature. Task 9: Configure the image flip. If you turn the IMAGE FLIP function on, the image will be flipped 180 degree along its central axis, like the mirror reflection of the image. - Page 22 User Manual of Mini Analog Speed Dome MAIN MENUS > DOME SETTINGS > PRIVACYS PRIVACY BLANKS BLANK NUM BLANK STATUS SET BLANK CLEAR BLANK BACK EXIT Figure 3-8 Privacy Mask Configuration Menu 2. Choose the privacy mask number: Steps: (1) Move the cursor to BLANK NUM and click IRIS+ to enter the editing mode.
-
Page 23: Configuring Osd Settings
User Manual of Mini Analog Speed Dome Move the cursor to BLANK STATUS. Click IRIS+ button to enter the editing mode and click the up and down direction buttons to set it ON or OFF. Note: If no privacy mask has been configured, you cannot set the status as ON. -
Page 24: Configuring Ptz Control Parameters
User Manual of Mini Analog Speed Dome 3.4 Configuring PTZ Control Parameters Purpose: You can configure panning, tilting and zooming movements, and configure PTZ control functions including presets, patrols, patterns, etc. for the speed dome.； 3.4.1 Configuring PTZ Parameters Enter PTZ configuration menu: MAIN MENU >... -
Page 25: Configuring Presets
User Manual of Mini Analog Speed Dome Image freeze This feature enables the live view to switch directly from the current scene to another scene that is defined by a preset, without showing the middle areas between these two scenes. It reduces the use of bandwidth in a digital network system and it also provides privacy protection for the middle areas. -
Page 26: Configuring Patrols
User Manual of Mini Analog Speed Dome A preset is a user-defined monitoring position/point. You can simply call the preset number to change the monitor scene to the defined position. Steps: 1. Move the cursor to enter preset configuration submenu: MAIN MENU >... - Page 27 User Manual of Mini Analog Speed Dome MAIN MENU > DOME SETTINGS > PATROLS PATROLS PATROL NUM EDIT PATROL PREVIEW CLEAR PATH PATROL_D BACK EXIT Figure 3-13 Patrol Configuration Menu Choose the patrol number. Steps: (1) Move the cursor to PATROLS NUM and click IRIS+ to enter edit mode.
-
Page 28: Configuring Patterns
User Manual of Mini Analog Speed Dome up to 32 presets in sequence for a patrol. Press IRIS+ to save the new settings or press IRIS- to cancel and return to the previous menu. Preview the patrol. Move the cursor to PREVIEW and click IRIS+ to preview the current patrol. You can click IRS+ again to stop the preview. -
Page 29: Configuring Time Tasks
User Manual of Mini Analog Speed Dome Note: Up to 4 patterns can be configured. 3. Edit the pattern. Steps: (1) Move the cursor to EDIT PATTERN and click IRIS+ to enter edit mode. REMAIN MEMORY DONE: OPEN QUIT: CLOSE... - Page 30 User Manual of Mini Analog Speed Dome Steps: 1. Move the cursor to enter the TIME TASK submenu: MAIN MENU > DOME SETTINGS > TIME TASK TIME TASK TASK NUM TASK STATE TASK ACT NONE TASK TIME TASK PREVIEW TASK CLEAR...
-
Page 31: Configuring Zone
User Manual of Mini Analog Speed Dome (4) Click IRIS+ to confirm the settings and exit. Note: The weekday can be set to be from Monday to Sunday or Whole Week; the H refers to Hour and the M refers to Minute. -
Page 32: Clearing Ptz Control Settings
User Manual of Mini Analog Speed Dome Note: Up to 8 zones can be configured. 3. Configure the zone area. Steps: (1) Move the cursor to EDIT ZONE and click IRIS+ button to enter the edit mode. (2) You can see SET LEFT LIMIT on the screen. Click the direction buttons to set the left limit stop. -
Page 33: Others
User Manual of Mini Analog Speed Dome DIAGNOSTICS DIAGNOSTICS HIGH TEMP PAN LOST HIGHEST TEMP 47° C TILT LOST LOW TEMP CAMERA LOST LOWEST TEMP 23° C VIDEO LOSS LOW VOLTAGE POWER UP BACK EXIT BACK EXIT Figure 3-21 Self-diagnostics... -
Page 34: Restoring Default Dome Settings
User Manual of Mini Analog Speed Dome You can modify the password and enable/disable the password protection to prevent unauthorized settings of the speed dome. After you set and enable the password, you need to input the password every time you call preset 95 to enter the menu. -
Page 35: Restoring Default Camera Settings
User Manual of Mini Analog Speed Dome Zoom limit Max Optical Zoom Zoom speed High Slow shutter IR cut filter D/N level AE mode Auto Exposure compensation White balance Auto Auto-flip Proportional pan Park time 5 seconds Park act None... -
Page 36: Appendix
User Manual of Mini Analog Speed Dome Appendix Appendix 1 Lightning & Surge Protection This product adopts TVS plate lightning protection technology to avoid damage caused by pulse signal that is below 3000V, like instantaneous lighting stroke, surging, etc. According to the actual outdoor situation, necessary protection measures must be taken, besides ensuring the electrical safety. -
Page 37: Appendix 2 Rs485 Bus Connection
User Manual of Mini Analog Speed Dome Appendix 2 RS485 Bus Connection General Property of RS485 Bus According to RS485 industry bus standard, RS485 is a half-duplex communication bus which has 120Ω characteristic impendence, the maximum load ability is 32 payloads (including controller device and controlled device). - Page 38 User Manual of Mini Analog Speed Dome faraway. At this time, the dome will be uncontrollable, or self-running, etc. Controller Device Star Shape Connection Figure A-4 For such case, the best way is adding a RS485 distributor. This product can effectively change the star-shape connection to which satisfies the requirement of RS485 industry standard, in order to avoid those problems and improve the communication reliability.
- Page 39 User Manual of Mini Analog Speed Dome Problem Possible Reasons To Solve the Problem dome can tightly. 2. RS485+ or RS485-wire is 2. Change a RS485 wire. controlled broken. but not 3. The speed dome is too far away 3. Add a terminal resistor.
-
Page 40: Appendix 3 24Vac Wire Gauge & Transmission Distance
User Manual of Mini Analog Speed Dome Appendix 3 24VAC Wire Gauge & Transmission Distance The following table describes the recommended max. distance adopted for the certain wire gauge when the loss rate of 24VAC voltage is less than 10%. For the AC driven device, the maximum voltage loss rate is 10% allowable. -
Page 41: Appendix 4 Table Of Wire Gauge Standards
User Manual of Mini Analog Speed Dome Appendix 4 Table of Wire Gauge Standards American Cross-sectional Bare Wire British Wire Wire Gauge Area of Bare Gauge(mm) Gauge SWG Wire(mm2) 0.750 0.4417 0.800 0.5027 0.900 0.6362 1.000 0.7854 1.250 1.2266 1.500 1.7663...
