Videology 20B40x Family Instruction Manual

Wide dynamic range pixim
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wide Dynamic Range Pixim
Instruction Manual
Prior to Using This Document: Videology reserves the right to modify the information
in this document as necessary and without notice. It is the user's responsibility to be
certain they possess the most recent version of this document by going to
www.videologyinc.com
comparing revision letters, located in the document's footer.
For technical assistance with this product, please contact the supplier from whom the
product was purchased.
Videology Imaging Solutions, Inc. USA
37M Lark Industrial Parkway
Greenville, RI 02828
Tel: 401-949-5332
Fax: 401-949-5276
Doc # INS 20B40x
Revision: B
20B40x Family
or linking directly to:
Issue Date: 12/19/2008
Page 1 of 10
http://www.videology.com/xxxxx
Videology Imaging Solutions, B.V. Europe
Neutronenlaan 4
NL-5405 NH Uden, Netherlands
Tel: +31 (0) 413-256261
Fax: +31 (0) 413-251712
and

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 20B40x Family and is the answer not in the manual?

Questions and answers

Related Manuals for Videology 20B40x Family

Summary of Contents for Videology 20B40x Family

  • Page 1 Instruction Manual 20B40x Family Prior to Using This Document: Videology reserves the right to modify the information in this document as necessary and without notice. It is the user’s responsibility to be certain they possess the most recent version of this document by going to www.videologyinc.com...

  • Page 2: Table Of Contents

    Table Of Contents Document History....................3 General Information ..................3 2.1. Safety Precautions ..................3 Camera Setup....................4 3.1. Menu & Setting Details ................4 3.2. Screen Display (OSD).................. 5 3.3. OSD Menu Enter/Exit................... 5 3.4. Main Menu ....................6 Camera Features &...

  • Page 3: Document History

    1. Document History Revision Issue Date Reason Rev A 12-12-08 Initial release 08-0046 2. General Information 2.1. Safety Precautions • Do not disassemble the unit • Do not put objects inside the unit • Make sure that no metal objects or flammable substances get inside the camera. It could cause fire, short-circuits or damages.

  • Page 4: Camera Setup

    Camera Setup 3.1. Menu & Setting Details MAIN MENU SETUP ID DISPLAY ID : ON or OFF CAMERA ID : 12 CHARACTER ID POSITION : UP-LEFT or UP- LENS MANUAL DC : LEVEL (Range +10 to -40) WDR : LEVEL (Range +20 to -20) WB CONTROL MANUAL : LEVEL (Range 2,500K ON : LEVEL (Range 0 to 38)

  • Page 5: Screen Display (Osd)

    Five key switchboard RIGHT key UP key CENTER key DOWN key LEFT key 2nd VIDEO Figure 1. 3.2. Screen Display (OSD) CENTER KEY Used to access the menu mode, and also used to confirm the setting. UP / DOWN KEY Used to choose the desired menu selection.

  • Page 6: Main Menu

    3.4. Main Menu SETUP ID DISPLAY ID The ID name will be displayed in the monitor. The name will not be displayed in the monitor. CAMERA ID You can write up to 12 characters. ID POSITION Select the on screen position of the camera ID. LENS MANUAL Select when using a manual lens.

  • Page 7: Camera Features & Dimensions

    Functional Selection Switch (box model only) You can choose NTSC or PAL via a switch Figure 2. 4. Camera Features & Dimensions 4.1. Product Features High Resolution The camera has 480 lines of horizontal resolution and 460 lines of vertical resolution. Superior Wide Dynamic Image Quality The camera has very Wide Dynamic Range via a Pixim DSP Chip Set.

  • Page 8: Product Dimensions

    RS232 - an optional RS232 board is available 4.2. Product Dimensions Doc # INS 20B40x Issue Date: 12/19/2008 Revision: B Page 8 of 10...

  • Page 9: Camera Specifications

    5. Camera Specifications 20B40x 21B40x NTSC Pick-up Device 1/3 inch CMOS (Dynamic Range Sensor) Total of Pixels (H x V) 742 x 552 Horizontal Resolution 480 Horizontal TV Lines (color) Scanning System 525 lines interlaced 625 lines interlaced Synchronization Internal / External Video Output 1.0Vp-p/75 ohm Composite Iris Control...

  • Page 10: Troubleshooting
