Programmable Features - Code Alarm CA-500 Installation Instructions Manual

NOTE: Once you enter the programming mode, do not allow more that 15 seconds to pass between steps, or
the programming will be terminated.

PROGRAMMABLE FEATURES:

Feature LtsFlash1X
1. Run Time 5 Min.
2. Ign. 2 Off During Crank
3. Parking Lights ON
4. Tach Mode Tachless
5. Voltage Level > .5V B4 Start
6. Diagnostics Off
7. Door Locks 1 Sec/1 Sec
8. Crank Time 0.8Sec
9. Gas/Diesel Gas
10.1 BTN Press Press & Hold
To Program Features:
1. Turn the ignition key to the ON position.
2. Press and release the program switch 3 times.
3. Immediately turn the ignition key OFF, then back to ON.
4. Press and release the program switch 2 times.
5. Use the STAR Button to advance to the feature that you want to change. EXAMPLE - If you need to change
programmable feature number 3, press and release the STAR Button 3 times in succession. The parking lights
will flash 3 times confirming that selected feature 3 can now be programmed.
6. Use the LOCK Button to change the selection of the programmable feature.
Lts Flash 2X Lts Flash 3X
10 Min. 15 Min.
On During Crank
Flash
Tach
< .5V B4 Start
On
3.5 Sec/3.5 Sec 1 Sec/Dbl 1 Sec
1.0 Sec 1.5 Sec
Diesel 10 Diesel 15
2 Press Start
10
Lts Flash 4X Default
20 Min. 10 Min.
On
Steady
Tach
> 0.5
Off
1 Sec/1 Sec
2.0 Sec 1.0
Diesel 20 Gas
2 Press Start
