Instructions for use

and maintenance

Argos

Att ention: Remove the instructions from the ﬁ replace and give them to the client,

along with the necessary instructions (explanations and demonstrations)

07DHARGA

02.06

Argos 1

Table of Contents

Need help?

Do you have a question about the ARGOS Gaz and is the answer not in the manual?

Questions and answers

Summary of Contents for Bodart&Gonay ARGOS Gaz

Page 1: Instructions For Use
Instructions for use and maintenance Argos Att ention: Remove the instructions from the ﬁ replace and give them to the client, along with the necessary instructions (explanations and demonstrations) 07DHARGA 02.06 Argos 1...
Page 2: Guarantee
Dear Client, We thank you and congratulate you on the purchase of one of our products. Your supplier and we will not rest until we have given you complete satisfaction. Your safety and comfort depend above all on the reasonable manner in which you use this appliance. To help you, we recommend that you read these instructions immediately and keep them in a safe place.
Page 3 EXCLUSIONS Accidents, damage and malfunctions connected with: unsuitability of the rated power of the appliance for the heat requirements of the premises; incorrect installation or connections; use of an unsuitable ﬂ ue lining and/or installation not conforming to these instructions (chimney installation);...
Page 4: Data Sheet
DATA SHEET Type ARGOS Gaz No. 47GV74E Double cat. II , II 2E+3P 2H3P Gaz LPG Cat.I Natural gas Cat.I 2ELL - Category of gas G20 - 20 mbar (gaz nat.) G25 - 25 mbar (gaz nat.) G31 - 37 mbar (propane) G25 - 20 mbar (gaz nat.)
Page 5: Dimensions
DIMENSIONS Argos 5...
Page 6 6 Argos...
Page 7 Argos 7...
Page 8 8 Argos...
Page 9: Description
DESCRIPTION FRONT VIEW AND DESCRIPTION Door Burners Control box and reception sensor + fan control Decorative plate Concentric fume exhaust ﬂ ue Warm air duct and connection nozzle Gravel Pilot light + thermocouple + electrode Stone support Door-opening/anti-explosion system Baﬄ e Gas inlet Remote control Door-opening tool...
Page 10: Exploded View
EXPLODED VIEW 10 Argos...
Page 11 OPCIONES Y RECAMBIOS ARGOS 740 OPTIONS AND SPARE PARTS ARGOS 740 RECAMBIOS / SPARE PARTS Concepto Description Code MARCO PUERTA MONTADO ARGOS 740 V MOUNTEDD DOOR FRAME ARGOS 740 AIR-VENT 37GV74004 MARCO PUERTA SOLDADO ARGOS 740 V WELDED DDOOR FRAME ARGOS 740 AIR-VENT 27GV74012 VITROCERAMICA ARGOS 740 PLANO 71 CERAMIC GLASS FLAT 718x498 THICK.
Page 12: Important Recommendations
IMPORTANT RECOMMENDATIONS Check that there is always at least 1cm between the door and the frame or masonry. Keep all readily inﬂ ammable objects away from the appliance (nylon fabrics, inﬂ ammable liquids, etc.). Furniture items must be kept at a minimum distance of 1m from the appliance. ATTENTION: children and people who do not know how to operate the air-vent gas ﬁ...
Page 13 Argos 13...
Page 14: Maintenance
MAINTENANCE Never clean the glass when it is hot! Wait for it to cool down. Dusting: do not use an aggressive product or liquid; a dry cloth or preferably dry foam is recommended. Soiled areas can be restored using SPECIAL HIGH TEMPERATURE (Bodart&Gonay) spray paints availa ble from your supplier.
Page 15: Using The Remote Control
USING THE REMOTE CONTROL LIGHTING THE PILOT LIGHT: “Argos Me1.1” diagram To light the pilot light, the remote control must be in OFF mode. Press the right (POWER) butt on once, ON mode ﬂ ashes, then validate the operation by pressing the left (SET) butt on, and ON mode remains on the display.
Page 16: Operating Faults
OPERATING FAULTS FAULTS SOLUTIONS - Check that it is switched on. - Check and replace the fuse. The fan is not working. - Check (and replace) the thermal safety switch. Waiting for the appliance to be at the right tempe- - Check (and replace) the variator.
Page 17 Argos 17...
Page 18 18 Argos...
Page 19 Argos 19...
Page 20 Bodart & Gonay s.a. Parc Artisanal de Harzé - Rue de Lambinon, 3 - B - 4920 HARZE (Aywaille) +32(0)4 239 93 93 info@b-g.be www.b-g.be 20 Argos...
Page 21: Installation Instructions
INSTALLATION INSTRUCTIONS Argos Att ention: Remove the instructions from the ﬁ replace and give them to the client, along with the necessary instructions (explanations and demonstrations). 07DHARGA 02.06 Argos 23...
Page 22: Important Recommendations
IMPORTANT RECOMMENDATIONS Check that the appliance installed is right for the type of gas used (the appliance can be installed for natural gas or propane). Your supplier is the SPECIALIST chosen by BODART & GONAY to represent your region. For your SAFETY and SATISFACTION, we recommend that you have them carry out your installation.
Page 23 Check that there is always at least 1cm between the door and the frame or masonry. Keep all readily inﬂ ammable objects away from the appliance (nylon fabrics, inﬂ ammable liquids, etc.). Furniture items must be kept at a minimum distance of 1m from the appliance. ATTENTION: children and people who do not know how to operate the air-vent gas ﬁ...
Page 24: Chimney Installation
CHIMNEY INSTALLATION The only permitt ed ﬂ ues are: Ontop system US diam. 130/200 or POUJOLAT 130/200 EI The gas outlet must be protected mechanically by a grill if it is positioned less than 2.2 m from the ground. ANY ACCESSIBLE PART OF THE FLUE MUST BE PROTECTED TO PREVENT BURNING. The rules of the French DTU 24.2.2 and Pr NBN 61-002 for Belgium are in force to prevent any risk of ﬁ...
Page 25 Installing the draught limiter n˚7 n˚7 n˚7 Argos 27...
Page 26: Installing And Connecting The Fireplace
INSTALLING AND CONNECTING THE FIREPLACE Plan for the gas intake on the right of the appliance. Place the Argos in the ventilated alcove. Connect the chimney ﬂ ue to the outside of the ﬁ replace (“ONTOP” or “POUJOLAT” ﬂ ue). Att ention: the temperatures of the outer surfaces of the chimney ﬂ...
Page 27: Fan Installation
Remove the stone supports and burner. Remove the right ﬂ ap (gas connection). Connect the connection tube to the gas pipe (on the right of the appliance) (1/2” gas). The gas pipes must be free of dirt. Check there are no leaks, turn oﬀ all gas appliances and check that the meter does not move for 5 minutes.
Page 28: Changing The Injector From Natural Gas To Lpg
Argos Optifire minimum 10 mm minimum 10 mm 10 mm 745 mm 200+20 =mini.220mm 200 mm 200 mm 50+230+50 50+260+50 =mini.330 mm =mini.360mm 140 mm Argos Infire Argos Optifire CHANGING THE INJECTOR FROM NATURAL GAS TO LPG Follow the ﬁ rst 5 steps for dismantling the hatch. Remove the main injector and the pilot light protection cage.
Page 29 Changement de l'injecteur de la veilleuse N°11 Verandering van de sproeier van de waakvlam Changing the pilotlight-injector N°11 N°11 N°10 N°7 07DHCOSIV COSMOS 100 - COSMOS 145 - HELIOS - SOLARIS - ARGOS Changement d'injecteur(s) - Verandering van de sproeier(en) - Changing the injector(s) H: 5mm M=230 COSMOS 100 GN...
Page 30: Initialisation
INITIALISATION 32 Argos...
Page 31 Important: warning! The initialisation operation must only be done by a qualiﬁ ed person and must only be done in rare cases. It also requires work on the remote control as well as in the appliance. Argos 33...
Page 32: Table Of Contents
CONTENTS INSTRUCTIONS FOR USE AND MAINTENANCE GUARANTEE DATA SHEET DIMENSIONS DESCRIPTION EXPLODED VIEW IMPORTANT RECOMMENDATIONS MAINTENANCE USING THE APPLIANCE USING THE REMOTE CONTROL Operating faults INSTALLATION INSTRUCTIONS IMPORTANT RECOMMENDATIONS CHIMNEY INSTALLATION INSTALLING AND CONNECTING THE FIREPLACE CHANGING THE INJECTOR FROM NATURAL GAS TO LPG INITIALISATION Bodart &...
