Summary of Contents for Bodart&Gonay COSMOS 125
- Page 1 User and maintenance manual COSMOS 125 COSMOS 125 COSMOS 125 DF Warning: Remove the manual from the fi replace and give it to the customer along with all relevant instructions (explanations and demonstrations) Cosmos125 1 07DHCOS125A 11.10...
-
Page 2: Warranty
Dear Client, We thank and congratulate you for purchasing one of our products. Together with your supplier, we will ensure that you are entirely satisfi ed with it. Your safety and comfort will depend on using this appliance for its intended use. To get the most out of your new fi... - Page 3 EXCLUSIONS Accidents, damage, and malfunctions caused by: • A mismatch between the nominal power of the product and the heating requirements of the room • Incorrect installation or wrong connexions • Using a chimney fl ue which is not suitable and/or assembly which does not comply with the present instructions (see Chimney Assembly) •...
-
Page 4: Technical Characteristics
TECHNICAL CHARACTERISTICS Type COSMOS 125 Nr 47GV12E.. Double Cat. II , II 2E+3P 2H3P LPG Cat.I Natural gas Cat.I 2ELL G20 - 20 mbar (nat. gas) G31 - 37 mbar (LPG) - Gas category G25 - 25 mbar (nat. gas) G30-30 mbar (butane) G25 - 20 mbar (nat. -
Page 5: Architect's Drawings
Type COSMOS 125 DF Nr 47GV12DE.. Double Cat. II , II 2E+3P 2H3P LPG Cat.I Natural gas Cat.I 2ELL G20 - 20 mbar (nat. gas) G31 - 37 mbar (LPG) - Gas category G25 - 25 mbar (nat. gas) G30-30 mbar (butane) G25 - 20 mbar (nat. - Page 6 TECHNICAL PLANS Cosmos125 6...
- Page 7 Cosmos125 7...
-
Page 8: Description
DESCRIPTION FRONT VIEW AND DESCRIPTION Concentric smoke outlet duct Hot air duct and connector pipe Door closure system Door Pilot light + guard Stone base Control box and receiver Burners Gas inlet Decorative plate Baffl e Anti-explosion system Remote control Transformer Initialisation switch Manual control... -
Page 9: Exploded View
EXPLODED VIEW COSMOS 125 Cosmos125 9... - Page 10 COSMOS 125 DF Cosmos125 10...
-
Page 11: Nomenclature
37GV12065 SET DECO PLATES COSMOS 100 37GV14014 SLUDGE HATCH GAS LINK COSMOS 145/100 B/FLUE 27GV14058 ROD FOR SHORT DOOR FL COSMOS/HELIOS/SOLARIS 27GV12005 Back plate fastening Cosmos 125 27GV10006 Couple deco plate holder (up) 37GV14036 GAS LINK EXTENSION COSMOS 145 37GV12013 4 mm frame Cosmos 125... - Page 12 Control hatch Cosmos 125 DF 07GV2003 injector holder (min/max setting) 07GV006E4 CABLED VALVE STEPBYSTEP (+EES) 17GV12D003 Injector support pipe COSMOS 125 DF 27GV12D031 Gas pipe COSMOS 125 DF 07GV0054 VERTICAL PILOT LIGHT NATURAL GAS 27GV12D033 Pilot light support COSMOS 125 DF...
-
Page 13: Important Recommendations
IMPORTANT RECOMMENDATIONS - Ensure there is always a 1.5 cm space between the door and the brickwork - Keep all fl ammable materials away from the appliance (nylon fabric, fl ammable liquids, etc.) Furniture must also be kept at least one metre from the appliance - WARNING: children and people who are not familiar with the appliance must refrain from operating it. -
Page 14: Using The Remote Control
8.1. USING THE STANDARD REMOTE CONTROL* STARTING THE PILOT LIGHT: diagram 1 The remote control must be in the OFF position to start the pilot light. Press the right button (POWER) once. The ON mode will fl ash. Next validate by pushing the left button (SET). The ON mode will continue to be displayed. - Page 15 cosmos ME 1 10 sec °C °C °C = OK! AUTO THERMOSTATIQUE THERMOSTATIC THERMOSTATISCH... °C MANUAL 15 sec °C °C MANUAL MANUAL °C MANUAL cosmos IT 2 °C AUTO °C °C °F °C °F Cosmos125 15...
- Page 16 Cosmos125 16...
-
Page 17: Manual Operation
8.2. SETTING THE FIREPLACE MANUALLY Set the fi replace manually when the remote control batteries are fl at or there is a malfunction or a poor connexion between the remote and the fi replace (n° 16 of the description on page 8). This is a plasticised tab at the end of a cable (normally always accessible). -
Page 18: Initialisation
8.3. INITIALISING THE STANDARD REMOTE CONTROL When the fi replace is installed, the remote control must be initialised to establish a connection between it and the fi replace. It is also sometimes necessary to repeat this operation after changing batteries or making repairs. Important: warning! Initialisation must be done by a trained person and infrequently. -
Page 19: Maintenance
MAINTENANCE - Never clean the appliance when it is hot! Wait until it has cooled down - Dusting: Do not use strong or liquid products. A dry rag or sponge is recommended - Soiled areas can be restored with SPECIAL HIGH TEMPERATURE aerosols (Bodart & Gonay) available from your supplier - Do not use a strong product to clean the window. -
Page 20: 10 Troubleshooting
10 TROUBLESHOOTING PROBLEM SOLUTION No spark - Turn on the power - Check the sensor cables - Check the ground wire No pilot light - Check the gas intake - Check that the valve is open The pilot light goes out - Check the gas intake - Check the TK connexion The burner won’t light... -
Page 21: Installation Manual
Installation manual COSMOS 125 COSMOS 125 COSMOS 125D Cosmos125 21... -
Page 22: Important Recommendations
- The appliance must be installed in compliance with the legislation in effect. We recommend that you comply with local installation legislation in effect for the air vent: + The COSMOS 125 and COSMOS 125D gas fi replace air vent connexion must be done by a certifi ed installer. -
Page 23: Chimney Assembly
CHIMNEY ASSEMBLY 2.1. Chimney confi guration - The only fl ues allowed are the: Metaloterm Ontop US dia 100/150 system or the Poujoulat 100/150 Dualis PGI system. The appliance can also be installed with a fl ue of 130/200 in diameter (see diagram below) using an adapter (reference USVG1013 from Metaloterm Ontop). -
Page 24: Existing Chimney
2.2. If there is already a chimney (Category C31s) The chimney fl ue for the Cosmos 125 and 125D must be clean, airtight and have a diameter of at least 150. The “existing chimney” component (with the Metaloterm cleaning kit only) is an integral part of the installation. - Page 25 The distance L between the opening in a wall and a terminal positioned higher is determined as follows: - If ∆H < 0.50m L ≥ 2 m - If 0.50m ≤ ∆H < 1m L ≥ 1m The distance L between the opening in a wall and a terminal positioned lower (with the outlet in the roof or in a vertical wall) must be: L + ∆H >...
-
Page 26: Draught Limiter
2.4. Installing the draught limiter The limiter should be installed when the difference between vertical length and horizontal length is largely more than 3 meters (in favor of vertical). when the difference is close to 3 meter, check fi rst the combustion without draught limiter (which might not be necessary thanks to local parameters). - Page 27 2. Remove the door: A + B + C + ..3. + 4. Cosmos125 27...
-
Page 28: Soft Heating System
4. FIREPLACE INSTALLATION AND CONNEXION - Plan for gas arrival on the right side of the appliance - Place the COSMOS 125/125D in the ventilated recess (a thread of air of minimum fi ve cm between the fi replace and any other materials including insulation, with entry and exit holes for decompression) IMPORTANT: Maintain a thread of air between the fi... - Page 29 - Open or remove the door (see page 26+27) - Remove the stones (E), burners (F) and dismantle the hatch (remove the two screws to take it out) *: for the Cosmos 125 DF, also refer to page 31 Cosmos125 29...
- Page 30 - Reconnect the appliance tube to the gas line (on the right side of the appliance) (1/2» female gas line). The gas lines must be clean. Check that there are no leaks: shut off all gas appliances for fi ve minutes and check that the gas counter does not increase. - Use an extension if required (supplied) - Reconnect the transformer.
- Page 31 NOTE FOR THE COSMOS 125 DF: OPENING DOORS The two glass doors of the COSMOS 125 DF do not have the same opening system. The door in front of the pilot light opens as described above. The other door, located behind the pilot light, opens as follows: To open, use the key tool to push back the latch.
-
Page 32: Changing The Ng Injector To Lpg
4. Unscrew the burner injector and replace it 5. ADJUSTMENT: Turn the adjustment screw on the valve by 3/4 turn (clockwise) 6. Change the grey label, write down the serial number of the appliance and tick the LPG box COSMOS 125 COSMOS 125DF 0461/10... -
Page 33: Fireplace Fitting
FIREPLACE FITTING - COMBUSTIBLE MATERIALS: Must not be placed in the immediate vicinity of the fi replace, of the hot air outlets, or of the chimney fl ue. The safety distance for the fi replace fi tting depends on the degree of fl ammability of the material used (see NF DTU 24.1 and 24.2 standards or local norms). -
Page 34: Table Of Contents
TABLE OF CONTENTS USER AND MAINTENANCE MANUAL WARRANTY TECHNICAL CHARACTERISTICS ARCHITECT’S DRAWINGS DESCRIPTION EXPLODED VIEW NOMENCLATURE IMPORTANT RECOMMENDATIONS USING THE FIREPLACE 8.1. USING THE REMOTE CONTROL 8.2. MANUAL OPERATION 8.3. INITIALISATION MAINTENANCE TROUBLESHOOTING INSTALLATION MANUAL IMPORTANT RECOMMENDATIONS CHIMNEY ASSEMBLY 2.1. CONFIGURATION 2.2.
