IMPORTANT: PLEASE READ THESE
INSTRUCTIONS THOROUGHLY BEFORE USING
THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR
FUTURE REFERENCE.
IMPORTANT USER INFORMATION
These notes are provided in the interest of safety. You
must read them carefully before installing or using this
appliance.
- This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision responsible for their safety. Children of less than 3
years should be kept away unless continuously supervised.
- This tumble dryer is intended for domestic use only.
- The room must be adequately ventilated to avoid back flow
of gases into the room from appliances burning gas or any
other fuels. This includes open fires.
INSTRUCTIONS FOR USE
C8317 INTEGRATED
TUMBLE DRYER
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for White Knight C8317
Summary of Contents for White Knight C8317
- Page 1 INSTRUCTIONS FOR USE C8317 INTEGRATED TUMBLE DRYER IMPORTANT: PLEASE READ THESE INSTRUCTIONS THOROUGHLY BEFORE USING THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR FUTURE REFERENCE. IMPORTANT USER INFORMATION These notes are provided in the interest of safety. You must read them carefully before installing or using this appliance.
- Page 2 - Exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances burning gas or any other fuels. - Any electrical work required to install the appliance should be carried out by a qualified person. - This tumble dryer should be serviced by an appointed service organization and only genuine spare parts used.
- Page 3 - Remove all objects from pockets such as lighters and matches. - Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer.
-
Page 4: Installation
INSTALLATION The tumble dryer is fully compatible with any 600mm deep kitchen units and complies with stringent EEC regulations. Your dryer is provided with a vent hose which will extend to approx 2.4m (8ft). We strongly recommend that this is vented through the wall with the attachment provided. The position of the hole (100mm diameter) for the vent directly behind the tumble dryer is shown in the diagram. -
Page 5: Control Panel Guide
THE FILTER The filter is found, as seen from the diagram, by opening the door and must always be in position when drying items in the appliance. To allow the dryer to operate efficiently it should be cleaned after each drying cycle. Do not be alarmed by the amount of fluff deposited on the mesh. - Page 6 PROGRAMME DESCRIPTIONS 1. extra dry 5. iron dry 2. cupboard dry 6. damp dry 3. mid dry 7. timed dry 4. extra iron dry 8. 30 mins airing Program 1 – Extra dry: clothes are dry enough to be put away Program 2 –...
- Page 7 For energy labeling purposes (EN61121:2005) for a cotton dry load, use the maximum load weight for cotton and set the timer to the recommended drying time for cotton dry as specified on the control panel. The standard cotton programme is suitable to dry normal wet cotton laundry. It is the most efficient programme in terms of energy consumption for drying wet cotton laundry.
- Page 8 APPROVED SERVICE AGENTS: UK & SOUTHERN IRELAND Call White Knight ON 0800 988 1323 (calls are free from landlines however calls from mobiles may be charged at your network provider’s rates) OR 0344 8797422 (Calls charged at basic rate.) APPROVED SERVICE AGENT: NORTHERN IRELAND Call: Service Network 2000 ON 028 90365222 (Daytime calls cost up to 17p plus 10.5p per minute from BT lines...
-
Page 9: Door Reversal
DOOR REVERSAL APPLIANCE DOOR The door on the dryer can be positioned either with the left or right hand hinging. Please follow illustrations below to change the door position. THE DECOR DOOR The hinges can be fastened through the pre-drilled holes on either the left or right hand with the door stops being fitted on the other side. -
Page 10: Technical Data
TECHNICAL DATA Overall dimensions : height 86.5 – 89cm width 59.5cm depth 53cm Maximum dry weight of cotton, linen 7.0kg synthetics 7.0kg. For electrical ratings see plate on rear of machine. Fuse rating: 13amp. DON’TS…. Do not – Overload the dryer. Do not –... - Page 11 LAV SDO Sense Suppliers name or trade mark WHITE KNIGHT Model identifier 837, 839, 83A, 83B, 831 - TYPE Rated capacity at full load Appliance type Air Vented Energy efficiency class Energy consumption of the appliance* 519kWh The figures above is based on 160 drying cycles of the standard cotton programme at full and partial load and the consumption of the low-power modes.
- Page 12 Manufactured by: Crosslee plc. Hipperholme, Halifax, West Yorkshire HX3 8DE 4213 194 12514...
