wire connection guide

immobiliser harness wiring diagram

N N O O T T E E : : All wires are BLACK. Each pair is an immobiliser circuit
input and output. Each wire is marked with its function. The descrip-
tion listed below is the marking on each wire and then its function,
in brackets.
___
1
___
2
___
3
___
4
___
5
___
6

power harness wiring diagram

N N O O T T E E : : All wires are BLACK. Each wire is marked with its function.
The description listed below is the marking on each wire and then
its function, in brackets.
___
1
___
2
___
3
N N O O T T E E : : Please remove all wire description tags from wiring after
connection to the vehicle.
4
Fuel Pump Output (Fuel Pump Interrupt Com)
STR: Starter Side (Starter Interrupt Com)
IGN: Key Side (Ignition Interrupt 87)
Fuel Pump Input (Fuel Pump Interrupt 87)
STR: Key Side (Starter Interrupt 87)
IGN: Ignition Side (Ignition Interrupt Com)
+12V
GND1 (Ground 1)
GND2 (Ground 2)
