Getting to know your processor
To prevent children from detaching the battery cover from the battery
holder, you can use the Cochlear Nucleus CP800 Series Tamper
™ ®
Resistant Battery Cover. You can also lock the standard battery module
or the rechargeable battery module to the processing unit.
Cochlear supplies a battery charger to recharge the rechargeable battery
module. For more information, see Replacing and recharging batteries.

Coil and coil cable

The coil is a small round disk that you place over the implant. It
transfers electromagnetic signals from your processing unit to the
implant. The coil is attached to a removable coil cable, which plugs into
the processing unit. The coil and coil cable are available in a choice of
colours and lengths. For more information, see Changing the coil cable.
1 2
Figure 5: Coil only (1) and coil with cable (2)
12 - CP810 Sound Processor User Guide © Cochlear Limited 2010
