Summary of Contents for Twin-Star International Chimney Free DFI020ARU
- Page 1 A Twin-Star International Br and MODEL: DFI020ARU www.tsicustomerservice.com Twin-Star International, Inc; Delray Beach, FL 33445 Made in China • Printed in China • Fabricado en China • Impreso en China • Fabriqué en China • Imprimé en Chine REV-1 www.tsicustomerservice.com...
-
Page 2: Getting Started
GETTING STARTED 1. The serial number is located on the back of the fireplace, the serial number is necessary for product warranty registration and customer service. Serial Number Model Number 2 . Go to www.tsicustomerservice.com for product warranty registration. If you are unable to complete registration save your proof of purchase for warranty purposes. -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons including the following: 1. Read all instructions before using this appliance. 2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this appliance. - Page 4 OPERATION INSTRUCTIONS THERMOSTAT HEATER FLAME MAIN POWER SWITCH Control Panel The fireplace can be operated by either the remote control or the control panel. POWER FLAME HEATER EMBERBED UNDULATION REV-1 www.tsicustomerservice.com...
-
Page 5: Operation Instructions
OPERATION INSTRUCTIONS FUNCTION ICON DESCRIPTION The MAIN POWER switch supplies power to all of the POWER function of the fireplace. The switch must be in the ON position for any functions or the remote to work. Each time the FLAME button is pressed, the intensity of the FLAME flame decreases. -
Page 6: Troubleshooting
TROUBLE SHOOTING Problem Root Cause Corrective Action No power, the power switch Normal operation Check that the unit is plugged into a standard 120V outlet. is in ON position. Logs Glow, flame effect Check whether Flame Generator drive motor is running . If not call the Spinner Motor. -
Page 7: Exploded View
EXPLODED VIEW Part Part Name Part Number Blower/Heater Assembly Y07-C26-P01 Emberbed Circuit Board Y09-C40-P44 Flame Generator Drive Motor P10-Q Main power switch Control panel circuit board Y09-C40-P32 Knob for heater temperature control Main circuit board Y13-C40-P15 Power cord Remote control Y09-C40-P62 CARE AND MAINTENANCE •... -
Page 8: Fcc/Ic Information
FCC/IC INFORMATION NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 9: Year Limited Warranty
1-YEAR LIMITED WARRANTY The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of puchase, subject to the following conditions and limitations. 1. Install and operate this Electric Appliance in accordance with the installation and operating instructions furnished with the product at all times. - Page 10 A Twin-Star International Br and www.tsicustomerservice.com REV-1 www.tsicustomerservice.com...
