DFI-3108-01, DFI-3108-02, DFI-3108-03,
Warning: This is an unvented, electric appliance.
DO NOT attempt to burn wood or manufactured
firelogs in or on this appliance or grate.
A423
MODEL/ MODELE/ MODELO:
DFI-3108-04, DFI-3108-05
www.tsicustomerservice.com
Distributed by • Distribuido por • Distribué par • Twin-Star International, Inc; Delray Beach, FL 33445
Made in China • Printed in China • Fabricado en China • Impreso en China • Fabriqué en China • Imprimé en Chine
Advertencia: Este es un aparato eléctrico sin
ventilación. NO intente quemar leños fabricados ni
madera dentro o sobre este aparato o su parrilla.
Avertissement : Il s'agit d'un appareil électrique
non ventilé. NE PAS tenter de faire brûler du bois
ou des bûches fabriquées dans l'appareil ou sur
la grille.
1
www.tsicustomerservice.com
Advertisement
Table of Contents
Related Manuals for Twin-Star International duraflame DFI-3108-01
Summary of Contents for Twin-Star International duraflame DFI-3108-01
- Page 1 Distributed by • Distribuido por • Distribué par • Twin-Star International, Inc; Delray Beach, FL 33445 Made in China • Printed in China • Fabricado en China • Impreso en China • Fabriqué en China • Imprimé en Chine Warning: This is an unvented, electric appliance.
-
Page 2: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons including the following: 1. Read all instructions before using this appliance. 2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this appliance. -
Page 3: Getting Started
VOLTS WATTS FURNISHINGS AND OTHER COMBUSTIBLES AT LEAST 3 FEET(0.9M) FROM 120V ~ 1500 THE FRONT OF THE HEATER AND AWAY FROM THE SIDE AND THE REAR. Twin-Star International, Inc. CAUTION: RISK OF ELECTRICAL SHOCK 220391 www.twinstarhome.com DO NOT OPEN NO USER... -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS Tools Required for Assembly Phillips Head Screwdriver Leg Assembly Fasten the legs to the base using the Align the 2 mounting tabs into the Slide the legs outward to lock in bracket. place. When locked in position included screws,1 per leg the screw hole from step 3 will be aligned. - Page 5 OPERATION INSTRUCTIONS Control Panel Location Control Panel NOTE: Please operate the remote transmitter at a slow measured pace. Press the remote control buttons with an even motion and gentle pressure. Repeatedly pressing buttons in rapid succession may cause the transmitter to malfunction. A423 www.tsicustomerservice.com...
- Page 6 OPERATION INSTRUCTIONS Description Function Icon The Power button supplies power to all of the functions of POWER the stove and will illuminate the flame effect. This switch must be lit for any of the functions to work. Use +or -to increase or decrease the flame brightness levels. FLAME Our stove consists of a infrared type heater.
-
Page 7: Bulb Replacement
BULB REPLACEMENT Tools Required for Assembly Phillips Head Screwdriver Clear, 40-watt, E12 socket base light bulb (candelabra base, B bulb). Unplug the stove. Remove the screws holding the stove back panel in place. Remove the back panel to access the light bulb. REMOVE Pinch the spring clip to loosen the spindle, and gently turn and pull the rubber gromet out of the... -
Page 8: Troubleshooting Guide
TROUBLESHOOTING GUIDE Problem Root Cause Corrective Action 1. No power, buttons Power cord was not plugged into Check that unit is plugged directly into a standard do not light up. the outlet. 120 volt outlet. 2. Stove does not 2a. No incoming power from the 2a. -
Page 9: Exploded View
EXPLODED VIEW Part Part Name Part Number Control Panel Y15-S168-P32 Legs SL-3108-BLK Heater/Blower Assembly Y15-S168-01 Main PCBA Y15-S168-P15 Flame Generator/Spinner Y15-S168-P11 Flame Generator Drive Motor P10-Q Emberbed Y15-S168-P02 Remote control P130 Note, the scale and size of your parts may be different depending on your exact model A423 www.tsicustomerservice.com... -
Page 10: Fcc/Ic Information
FCC/IC INFORMATION Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 11: Year Limited Warranty
1-YEAR LIMITED WARRANTY The manufacturer warrants that your new Electric Stove is free from manufacturing and material defects for a period of one year from date of puchase, subject to the following conditions and limitations. 1. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times.
