- Page 1 MODEL: DFS-7515-01, DFS-7515-02, DFS-7515-03 DFS-7515-04, DFS-7515-05, DFS-7515-06 www.tsicustomerservice.com 1-888-674-7517 Twin-Star International, Inc; Delray Beach, FL 33445 Made in China • Printed in China A486 www.tsicustomerservice.com https://manual-hub.com/...
-
Page 2: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons including the following: 1. Read all instructions before using this appliance. 2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this appliance. -
Page 3: Getting Started
TIBLES À AU MOINS 0.9M(3 PIEDS) DE LA PARTIE FRONTALE DE L’APAREIL DE CHAUFFAGE ET ÉLOIGNÉS DES CÔTÉS. 120V~ 1500 AVERTISSEMENT: RISQUE DE CHOC ÉLECTRIQUE NE PAS OUVRIR AUCUN Twin-Star International, Inc. ENTRETIEN DES PIÈCES INTÉRIEURES PAR L’UTILISATEUR www.twinstarhome.com Made In China VEA EL INSTRUCTIVO PARA DETALLES DE SERVICIO Fabriqué en Chine AVISO: DESCONECTE LA ENERGÍA ANTES DE LIMPIAR O REPARAR... - Page 4 OPERATION INSTRUCTIONS Control Panel Location Control Panel Main Power Switch Heater Settings The Power switch supplies power to all of the The power Switch must be in the ON position to functions of the Fire Cube including the flame use the heater. effect and heater.
-
Page 5: Bulb Replacement
BULB REPLACEMENT Tools Required for Assembly Clear, 40-watt, E12 socket base light bulb Phillips Head Screwdriver (candelabra base, B bulb). 1. Remove the Phillips head screws. 2. Remove back panel to access light bulb. Light bulb retaining spring 4. Pull away the bulb retaining spring, 3. -
Page 6: Troubleshooting Guide
TROUBLESHOOTING GUIDE Problem Root Cause Corrective Action 1. No power Power cord was not plugged into Check that unit is plugged directly into a standard 120 volt outlet. the outlet. 2. Fire Cube does not 2a. No incoming power from the 2a. -
Page 7: Exploded View
EXPLODED VIEW Part Part Name Part Number Power Switch P06-S Heater Switch - Y16-S204-P06 750W/1500W Ember bed Y17-S238-P02 Heater/Blower Assembly Y16-S204-P01 Flame Generator Drive Motor P10-Q-S Note, the scale and size of your parts may be different depending on your exact model. A486 www.tsicustomerservice.com https://manual-hub.com/... -
Page 8: Year Limited Warranty
1-YEAR LIMITED WARRANTY The manufacturer warrants that your new Electric stove is free from manufacturing and material defects for a period of one year from date of puchase, subject to the following conditions and limitations. 1. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times.
