Summary of Contents for Phonic AM440

  • Page 1 AM440 AM440D Compact Mixers User’s Manual ENGLISH AM440/440D...
  • Page 2: Important Safety Instructions

    AM440/440D...
  • Page 3: Table Of Contents

    APPLICATION ..........................  DIMENSIONS ...........................  DIGITAL EFFECT TABLE ......................4 SPECIFICATIONS ........................5 BLOCK DIAGRAMS ......................... 7 Phonic reserves the right to improve or alter any information suppied within this document without prior notice. V. APR , 006 AM440/440D...
  • Page 4: Introduction

    INTRODUCTION FEATURES Common Features : Thank you for choosing one of Phonic’s many quality ● compact mixers. The AM440 and AM440D Compact Audiophile-Quality & ultra low noise ● Mixers – designed by the ingenious engineers that 4 mono mic/line channels ●...
  • Page 5: Getting Started

    Set the gain so the Level Meter indicates the au- dio level is around 0 dB. This channel is now ready to be used; you can stop making the audio signal. You can repeat the same process for other chan- nels. Or not, it’s your call. AM440/440D...
  • Page 6: Making Connections

    The signal sent from these out- balanced or unbalanced signals. There are various puts is fed from the AUX send control on the AM440 numbers of these inputs depending which mixer you and the Digital Effect Processor on the AM440D.
  • Page 7: Rear Panel

    This output has extensive use, this mixer only. as it can be used to feed the signal from the mixer to an active monitor, for the monitoring of the audio sig- nal from within a booth, among other possible uses. AM440/440D...
  • Page 8: Controls And Settings

    This control is used to give a shelving boost or cut of ±5 dB to high frequency ( kHz) sounds. This will adjust the amount of treble included in the au- dio of the channel, adding strength and crispness to sounds such as guitars, cymbals, and synthesizers. AM440/440D...
  • Page 9 17. AUX / EFX Control This LED indicator will illuminate when the device The AUX control on the AM440 allows the user to hits high peaks, 6 dB before overload occurs. It is send the corresponding signal to the AUX mixing...
  • Page 10: Digital Effect Table

    Main left and right mixing bus to be applied to your main feed. 26. EFX “to Ctrl” Button This button is pushed to allow the signal from the Digital Effect processor to be sent to the Control Room outputs for monitoring purposes. AM440/440D...
  • Page 11: Master Section

    “to Ctrl Rm” sends the signal to the Control Room mixing bus for monitoring. 30. AUX “to Ctrl” Button (AM440 only) When this button is activated, the AUX send signal (the level of which is decided by the AUX send con- trol) will be sent to the Control Room mixing bus for monitoring purposes.
  • Page 12: Application

    Combining the use of different instruments with the mixer’s special functions (such as digital effect processing, in the case of the AM440D) will ensure that your audio sounds exactly the way you want it. AM440/440D...
  • Page 13: Dimensions

    DIMENSIONS Both the AM440 and AM440D share the same dimensions. * All measurements are shown in mm/inches. AM440/440D...
  • Page 14: Digital Effect Table

    00mS - .7S HEAVY PHASER  TAP DELAY 00mS - .7S HEAVY PHASER  TEST TONE FREQUENCY SHAPE WILD PHASER  LOW FREQUENCY 00Hz SINEWAVE WILD PHASER  MID FREQUENCY kHz SINEWAVE HIGH FREQUENCY 0kHz SINEWAVE PINK NOISE 0Hz~0kHz AM440/440D...
  • Page 15: Specifications

    / as far left as possible, channels /4 as far right as possible. Reference=+6dBu) Master @ unity, channel fader down -86.5 dBu -86.5 dBu Master @ unity, channel fader @ unity -84 dBu -84 dBu S/N ratio, ref to +4 >0 dB >0 dB AM440/440D...
  • Page 16 00VAC, 0VAC, supply, depends on region) 0~40VAC, 50/60Hz 0~40VAC, 50/60Hz Weight .7kg (.75 lbs) .7 kg (.78 lbs) Dimensions (WxHxD) 4 x 55 x 5mm 4 x 55 x 5mm (.5” x .6” x 8.86”) (.5” x .6” x 8.86”) AM440/440D...
  • Page 17: Block Diagrams

    AM440 BLOCK DIAGRAM AM440/440D...
  • Page 18 AM440D BLOCK DIAGRAM AM440/440D...
  • Page 19 AM440/440D...
  • Page 20 AM440/440D...
