Operation mechanism and working range.
Working temperature range.
maximum cooling
minimum cooling
maximum heating
minimum heating
Schematic diagram of refrigeration
1. Schematic diagram of cooling type
2. Schematic diagram of heat pump type
1. Indoor heat-exchanger
4. Accumulator
7. Outdoor heat-exchanger
10. One-way valve
1
Indoor side DB/WB ( )
32/23
21/15
27/-
20/-
2. Connecting pipe
5. Compressor
8. Master capillary
11. Four-way reversing valve
Outdoor side DB/WB ( )
43/26
21/15
24/18
-5/-6
3. Check valve
6. Filter
9. Auxiliary capillary
