User Manual
English
Congratulations on the purchase of your
Leica DISTO™ D330 .
Carefully read the Safety Instruc-
tions and the User Manual before
using this product.
The person responsible for the instrument must
ensure that all users understand these directions and
adhere to them.
Contents
............................................. 1
................................................................ 6
................................................... 8
........................................................... 10
.......................................................... 11
........................................................... 13
............................................................ 19
Leica DISTO™ D330 776176 en
Safety Instructions
Symbols used
The symbols used in the Safety Instructions have the
following meanings:
WARNING:
Indicates a potentially hazardous situation or
an unintended use which, if not avoided, will result in
death or serious injury.
CAUTION:
Indicates a potentially hazardous situation or
an unintended use which, if not avoided, may result
in minor injury and/or in appreciable material, finan-
cial and environmental damage.
Important paragraphs which must be adhered
to in practice as they enabled the product to be used
in a technically correct and efficient manner.
Use of the instrument
Permitted use
•
Measuring distances
•
Computing functions, e. g. areas and volumes
•
Measuring tilts
1
Safety Instructions
D
EN
F
I
E
P
NL
J
RUS
CZ
Advertisement
Table of Contents
Related Manuals for Leica DISTO D330
Summary of Contents for Leica DISTO D330
-
Page 1: Table Of Contents
Operation ............10 Measuring ............11 Use of the instrument Functions ............13 Appendix ............19 Permitted use • Measuring distances • Computing functions, e. g. areas and volumes • Measuring tilts Leica DISTO™ D330 776176 en Safety Instructions... - Page 2 This person is also accountable for the deployment of personnel and for The Leica DISTO™ is designed for use in areas perma- their training and for the safety of the equipment nently habitable by humans, do not use the product when in use.
-
Page 3: Safety Instructions
Leica Geosystems home page at ments. http://www.leica-geosystems.com/treatment or Make sure the Leica DISTO™ optic is kept clean and received from your Leica Geosystems dealer. that there is no mechanical damage to the bumpers. CAUTION:... -
Page 4: Laser Classification
WARNING: • Connect the equipment into an outlet on a circuit different from that to which the receiver is The Leica DISTO™ conforms to the most strin- connected. gent requirements of the relevant standards and • Consult the dealer or an experienced radio/TV regulations. - Page 5 Laser Notice No. 50, dated June 24, 2007. US 5949531 PATENTS: WO 9427164 WO 0244754 WO 0216964 EP 1195617 WO 9818019 Type: Leica DISTO D330 Power: 3V / 0.3A Made in Austria www.leica-geosystems.com Leica DISTO™ D330 776176 en Safety Instructions...
-
Page 6: Start-Up
A built-in sensor automatically detects the orienta- Remove the batteries before any long period tion of the positioning bracket and adjusts the zero of non-use to avoid the danger of corrosion. point of the instrument accordingly. Start-up Leica DISTO™ D330 776176 en... - Page 7 Double (partial height) measurement Timer - button 10 Save constant value, call up constant value 10 Storage - button 11 Historical memory, call up values 11 Menu/equal - button 12 Spirit level (numeric) 12 Clear/off - button Leica DISTO™ D330 776176 en Start-up...
-
Page 8: Menu Functions
(pressed long) - You are in the 31 Indirect height the units set and the first menu item "Unit" are 32 Detail display displayed. button (pressed short) pages through each menu item. Menu functions Leica DISTO™ D330 776176 en... - Page 9 The following units can be set for tilt measurements: the new settings made in the submenu items . Units for tilt Pressing the button for longer in the menu +/- 0.0° allows you to quit the settings function without 0.00% saving. Leica DISTO™ D330 776176 en Menu functions...
-
Page 10: Operation
RESET and confirm, the instrument defaults to the factory settings. A reset returns the following values to their factory settings: • Reference (rear) • Display illumination (ON) • Beep (ON) • Unit (m(mm)) Operation Leica DISTO™ D330 776176 en... -
Page 11: Measuring
Press the button for longer to display additional information on the measurement, for example the tilt angle , the distance measured and the indi- rect height Press button again to switch off horizontal measurement. Leica DISTO™ D330 776176 en Measuring... - Page 12 Press to stop continuous measurement. The values for maximum and minimum distances are shown in the display as well as the last measured value in the summary line. Measuring Leica DISTO™ D330 776176 en...
-
Page 13: Functions
Press this button to take the first length measurement (e.g. length). Press it again to take the second length measurement (e.g. width). The result is displayed in the summary line. Press the button for longer to calculate the circumference Leica DISTO™ D330 776176 en Functions... - Page 14 Press and hold the key to display additional infor- mation about the measurement, such as the angle included by the first two measurements and the perimeter of the triangle Functions Leica DISTO™ D330 776176 en...
- Page 15 Holding the buttons down increases the rate of change of the values. Once the desired value (a) has been reached it can be confirmed with the button. The value (b) and the intermediate line flashes (the Leica DISTO™ D330 776176 en Functions...
- Page 16 Keep the instrument as horizontal as possible. Press and hold down this button to trigger continuous measurement, sweep the laser back and forth and up and down over the ideal target point. Functions Leica DISTO™ D330 776176 en...
- Page 17 Press this button three times ; the display possible shows the following symbol . The laser is Press and hold down this button to trigger switched on. continuous measurement, sweep the laser up and Aim at the upper point (1). Leica DISTO™ D330 776176 en Functions...
- Page 18 After the last beep the measurement is and make it available for further calculations by taken and the value is displayed. pressing button The timer can be used for all measurements. Functions Leica DISTO™ D330 776176 en...
-
Page 19: Appendix
(use target plate) Area/volume calculation of Wrong measure- Darken target (measure room data ment, background in different lighting brightness too high conditions) Addition / subtraction Laser beam inter- Repeat measurement Indirect measurement rupted using Pythagoras Leica DISTO™ D330 776176 en Appendix... - Page 20 Aiming at high gloss surfaces may deflect the laser Tripod thread beam and lead to measurement errors. Battery life, up to Against non-reflective and dark surfaces the Type AAA, 2 x 1.5V 5 000 measurements measuring time may increase. Appendix Leica DISTO™ D330 776176 en...
- Page 21 Do not use aggressive cleaning agents or solutions. Handle the instrument as you would a telescope or camera. Warranty The Leica DISTO™ D330 comes with a three* year warranty from Leica Geosystems AG. More detailed information can be found at: www.disto.com All illustrations, descriptions and technical specifica- tions may be subject to change without prior notice.
-
Page 22: Dk S Nfin
Appendix Leica DISTO™ D330 776176 en...
