Lightronics FXLD154WAI Owner's Manual

Version 0.1

FEATURES AND SPECIFICATIONS

LEDS: 54 1 Watt LEDs ( 36 white, 18 amber)
Beam angle: 25 º
Control system: DMX-512
DMX channels: 4
DMX connectors: 3 pin XLR
LED lifetime: 60,000 hours
Voltage: 90 - 259 VAC / 24 VDC
Max power consumption: 56 Watts
Size: 9.1/4"D x 8 3/8"W x 8 3/8"H
Body material: Cast Aluminim
Body color: black
Weight: 8.8 lbs

DESCRIPTION

The FXLD154WAI is a PAR style WHITER/AMBER
LED lighting fixture. It is suitable for stage, disco,
night club, and other artistic applications. It has
several stand alone control modes, a master/slave
mode, and can operate via a DMX-512 external signal.
A double yoke enables it to be operated in several
positions.

INSTALLATION

LOCATION

The FXLD154WAI is intended for
ONLY.
Locate the unit in a well ventilated area away from
moisture and heat. Holes are provided on the yokes to
install a lighting bar pipe clamp. A safety cable should
also be used. Do not block any vent holes.

POWER CONNECTIONS

The FXLD154WAI has a line cord for connection to a
120 VAC, 15 Amp, 60Hz, grounded service.
RISK OF ELECTRIC SHOCK
The safety ground pin on the power cord must be used.

DMX CONNECTIONS

A system using DMX control should be connected as a
chain of devices. In other words the control signal
cable should proceed from the controller to the first
www.lightronic.com
Lightronics Inc.
FXLD154WAI LED FIXTURE
OWNERS MANUAL
INDOOR USE
CAUTION
509 Central Drive Virginia Beach, Va 234354
receiving device and then to others in a continuous
"daisy chain" fashion.
The fixture has a DMX IN and a DMX OUT connector
to be used to connect the chain. The control cable
should NOT be split into a multiple run star
arrangement with a cable running from the controller
directly to each receiving device pack.

DMX CONNECTOR PIN ASSIGNMENTS

There are two different connectors which can be used
for DMX control. They are both XLR type connectors.
Some units use 3 pin connectors. Others use 5 pin
connectors. The FXLD154WAI receives a DMX signal
on the 3 pin MALE connector on the back of the unit.
The 3 pin FEMALE connector is used to connect the
next DMX device on the control chain. If your console
uses a 5 pin connector you can make up an adapter
cable to accommodate this. The table below shows the
pin assignments for BOTH the 3 pin and 5 pin
connectors.
IN # SIGNAL NAME
1 DMX COMMON
2 DMX DATA -
3 DMX DATA +
4 NOT USED
5 NOT USED
