1 1 8 8 I I G G N N I I T T I I O O N N C C O O N N T T R R O O L L L L E E D D L L O O C C K K — — O O N N , , OFF: : When programmed ON the doors will lock when the key is on and all doors
are closed.
1 1 9 9 F F A A C C T T O O R R Y Y A A L L A A R R M M D D I I S S A A R R M M — — W W I I T T H H U U N N L L O O C C K K , , BEFORE UNLOCK, REMOTE START ONLY: : In the default setting the factory
alarm disarm output will disarm the factory alarm system any time the button(s) controlling Unlock is pressed. The
"Before Unlock" output to disarms the factory alarm before the unlock output activates and before remote start is
activated. The "Remote Start Only" output disarms the factory alarm only before the remote start is activated.
2 2 0 0 F F A A C C T T O O R R Y Y A A L L A A R R M M D D I I S S A A R R M M P P U U L L S S E E S S — — S S I I N N G G L L E E , , DOUBLE: : Selectable for a single or double-pulse for the vehicle's factory
alarm disarm input requirements.
2 2 1 1 C C O O M M F F O O R R T T C C L L O O S S U U R R E E — — ON, , O O F F F F : : The system can be programmed to close the windows when the system is armed. A
20-second output starts 200mS after the last lock pulse. The Comfort Closure output will be canceled if the unlock
button is pressed. If programmed ON, the lock output wire provides this function.
s s h h u u t t d d o o w w n n d d i i a a g g n n o o s s t t i i c c s s
The unit has the ability to report the cause of the last shutdown of the remote start system. To enter diagnostic mode:
1.
2.
3.
4.
5.
3 3 0 0
Turn the ignition off.
Press and H H O O L L D D the Program switch.
Turn the ignition on and then off.
Release the Program switch.
Press and release the Program switch.
© 2005 Directed Electronics—all rights reserved
