The LED will now report the last system shutdown by flashing for one minute in the following grouped patterns:
L L E E D D
F F L L A A S S H H E E S S
One
Two
Three
Four
Six
Seven
Eight
The LED will stop flashing when the ignition is turned on.
r r e e a a r r d d e e f f o o g g g g e e r r c c o o n n t t r r o o l l
The rear defogger output has a factory default setting of O O N N . Do not connect the Blue/White wire if this feature
is not to be used.
t t i i m m e e r r m m o o d d e e
This unit can be programmed to start and run the engine every three hours. The engine will run for the pro-
grammed run time and then shut down. After three hours, the unit will restart the engine. A maximum of six
cycles can occur.
I I M M P P O O R R T T A A N N T T ! ! Timer Mode should be used only in open areas. Never start and run the vehicle in
an enclosed space such as a garage or carport.
T T o o e e n n t t e e r r T T i i m m e e r r M M o o d d e e : :
1. Turn the ignition on.
2. Press and HOLD the activation input to the remote start.
3. Turn the ignition off while holding the activation input.
© 2005 Directed Electronics—all rights reserved
S S H H U U T T D D O O W W N N
M M O O D D E E
System timed out
Over-rev shutdown
Low or no RPM
Transmitter Shutdown (or optional push-button)
(-) Shutdown
(-) Neutral safety shutdown (H2/6 BLACK/WHITE)
Wait-to-start timed out
