Bryant ERVBBSVB Product Data page 3

VENTILATOR ACCESSORY NUMBER NOMENCLATURE
Product
KV - - Ventilator Accessory Kit
Series
A - - Original Series
B - - Second Series
Type
AC01 - - Accessory
CN01 - - Control
TM01 - - Timer
Package Quantity
01 - - Single Pack
KIT NUMBER
KVAAC0101HOD Exterior Intake and Exhaust Hood
KVAAC0101HCO Concentric Intake and Exhaust Hood
KVBCN0101CBS
KVBCN0101CLC
KVBCN0101CLT Bryant OneTouch Control
KVBCN0101CST Standard HRV Control
KVATM010120C 20 Minute Push Button Timer
KVATM010160M
KVBAC0101KIT Airflow Measuring Kit
CONTROL FAN SPEED
DESCRIPTION CONTROL
Latent
OneTouch
Basic
Standard
Control features
Basic Control:
Allows the user to manually set fan speed to low or high as
required to maximize comfort.
Standard Control:
Offers automatic dehumidistat control and the option to select
continuous or intermittent fan operation. Setting the wall control to
low will activate the continuous mode.
OneTouch Control:
Allows control of ventilator with the touch of a button. This
control will operate as a main wall control. The OneTouch will
operate the unit in Intermittent Mode (20 minutes per hour),
continuous low speed, continuous high speed, and off.
Latent Control (ERVs only):
Low Exchange Mode—If the relative humidity inside the building
is lower than selected, air exchange would occur with the outside at
high speed. If the relative humidity inside the building is higher
1 2 3 4 5
K V B C N
DESCRIPTION
Basic HRV Control
Latent Control
60 Minute Timer
HUMIDISTAT
CONTROL
Yes Yes
Yes No
Yes No
Yes Yes
6 7 8 9 10 11
0 1 0 1 B B
WHERE USED
Used as a single intake/exhaust for SVB1100, SHB1100 models only
Used with all HRVs
Used with ERVs only
Used with all ERVs and HRVs as a main wall control
Used with all HRVs
Used with all HRVs when 20 minute manual operation is required
Used with all HRVs, time is adjustable between 10 and 60 minutes
Used with all ERVs and HRVs to balance intake/exhaust airflow
DEHUMIDISTAT
CONTROL
No
No
No
Yes
than selected, air exchange would occur with the outside at low
speed. This ensures continuous air exchange for constant air
quality.
Intermittent Mode—If the relative humidity inside the building is
higher than selected, no air exchange would occur and the system
would turn off. If the relative humidity inside the building is lower
than selected, air exchange would occur with the outside at high
speed. This mode is ideal for maintaining the proper humidity level
when the continuous mode cannot.
Automatic Defrost Cycle Features
All models offer a non- -electric defrost cycle feature which
prevents frost and ice buildup within the heat recovery core. When
the outside air temperature falls below 23_F (- -5_C) it is
electronically sensed and the dampers close the outside air ports.
This allows warm indoor air to recirculate within the heat recovery
core. The frequency of this cycle increases as the outside air
temperature decreases.
3
12
S
Control Description
BBS - - Bryant Basic Control
BLC - - Bryant Latent Control
BLT - - Bryant OneTouch Control
BST - - Bryant Standard Control
Accessory Description
HCO - - Concentric Intake/Exhaust Hood
HOD - - Intake Hood
KIT - - Airflow Measuring Kit
Timer Description
20C - - 20 Minute Timer Kit
60M - - 60 Minute Timer Kit
2 Required
CONTINUOUS INTERMITTENT
MODE
Yes
Yes
Yes
Yes
MODE
Yes
Yes
No
Yes
