Motherboard
User's Manual
www.giadatech.com
MI-D2700G
Version 001
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its
antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
"To comply with FCC RF exposure compliance requirements. The antennas used for this transmitter must be installed to provide
a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other
antenna or transmitter."
All right reserved
Advertisement
Table of Contents
Related Manuals for Giada MI-D2700G
Summary of Contents for Giada MI-D2700G
- Page 1 Motherboard User’s Manual www.giadatech.com MI-D2700G Version 001 This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
-
Page 2: Table Of Contents
www.giadatech.com Contents Gratitude …………………………………………………………………………… 4.12 LCD Firmware Download (Jp5) …………………………………… 4.13 VGA_OUT …………………………………………………………… About the product ………………………………………………… …………… 4.14 SPDIF ………………………………………………………………… 1. Picture of the motherboard ……………………………………………… 4.15 USB POWER (Jp1) ………………………………………………… 2. Features …………………………………………………………………… 4.16 AUTO POWER ON (J5) …………………………………………… 2.1 Processor ………………………………………………………………... -
Page 3: Gratitude
I. About the product 1. Picture of the motherboard Thank you for choosing Giada motherboard. ® Giada D2700G is based on Intel Atom™ Processor and NM10 chipset, with ® New Generation NVIDIA GF119™ GPU. It supports DDR3 800/1066 Dual-channel memory, on-board HD-AUDIO sound card and gigabit LAN. -
Page 4: Features
www.giadatech.com II. Hardware installation 2. Features 2.5 Power management · Support APM and ACPI; 2.1 Processor · Compatible with energy star “Green PC”. · ® On-board Intel Atom™ Processor D2700 ® · On-board New Generation NVIDIA ION™ GPU, 512MB VRAM. (NVIDIA GF119) 2.6 Expansion slot ·... -
Page 5: Layout Of Motherboard
www.giadatech.com 1. Layout of motherboard 2. Installing memory Please install the memory in accordance with the following procedures: · Align the golden finger of the memory to the groove of the interface slot and pay attention the concave hole of golden finger should be aligned to the convex point of the slot. -
Page 6: Install Expansion Slot Card
www.giadatech.com 3. Install expansion slot card 4. Motherboard jumper setting Installing extended devices Note:The user should notice that all sockets are marked with PIN1. The mark “#” Installing Mini-PCIE extended devices indicates the ex-factory default values. At the rear panel of motherboard is two Mini-PCIE extended slots, to which the user can connected WIFI module and Bluetooth module etc. -
Page 7: Clr_Cmos
www.giadatech.com 4.3. CLR_CMOS(CMOS pin) The correct time, system hardware and other information are saved in the CMOS memory of the motherboard. The interruption the computer’s power 2 3 4 won’t cause the loss of this information, for the CMOS is powered by the battery on the motherboard. - Page 8 www.giadatech.com 4.4. F_USB2 (frond-end USB pin) In case the USB ports on the rear panel of the machine case are not enough, the user can use the two sets of extension USB pins provided by this motherboard. These ports support USB 2.0 devices. The definitions of the ports are described below: USB+IR Signal...
-
Page 9: F_Audio
www.giadatech.com 4.5. F_ AUDIO(Pins for front-end audio adapter) 4.6. COM Needle inserted definition These audio adapter ports allow you to connect to the wire harness of the audio adapter. After connection, you can easily control the audio output/microphone through the front panel of the host (Note: Don’t connect the wire to Pin 4). The definitions of the ports are described below: Definition Definition... -
Page 10: Jlvds
www.giadatech.com 4.7. JLVDS(LVDS 30pin) LVDS POWER Signal LCD_BKL_ON LCD_ADJ Signal Signal LVDS_A_TXDN0 LVDS_A_TXDP0 LVDS CONNETOR LVDS_A_TXDN1 LVDS_A_TXDP1 LVDS_A_TXDN2 LVDS_A_TXDP2 LVDS_A_TXCN LVDS_A_TXCP Signal LVDS_A_TXDN3 LVDS_A_TXDP3 BLT_DOWN LVDS_B_TXDN0 LVDS_B_TXDP0 BLT_UP LCD_AUTO LVDS_B_TXDN1 LVDS_B_TXDP1 LCD_MEMU LVDS_B_TXDN2 LVDS_B_TXDP2 DISPLAY_ON LVDS_B_TXCN LVDS_B_TXCP LED_R LVDS_B_TXDN3 LVDS_B_TXDP3 LED_G LVDS_PWR LVDS_PWR... -
Page 11: F_Panel
www.giadatech.com 4.8. F_ PANEL (Front-end control panel) 4.9 SPK_L, SPK_R This socket is used to connect the flat cables on the front-end panel. 4.10 5V POWER Definition Definition Pin# Signal +HDLED（VCC） +PLED(VCC) PW_BN RST_SW... -
Page 12: Beep
www.giadatech.com 4.11 BEEP 4.13 VGA_OUT Pin# Signal VSYNC Pin# Signal HSYNC GREEN BLUE DDC_DATA DDC_CLK 4.12 LCD Firmware Download (JP5) 4.14 SPDIF Pin# Signal SDAA Pin# Signal SCLA SPDIF_OUT... -
Page 13: Usb Power (Jp1)
www.giadatech.com 4.15 USB POWER (JP1) 4.17 HDMI DDC 4.16 AUTO POWER ON (J5) Do not change default. J5 AUTO POWER ON DISABLE ENABLE... -
Page 14: Rear Panel Interface
Note The descriptions relating to BIOS in this Manual can only be used for reference as the BIOS version of the motherboard is upgraded continuously. Giada provides no guarantee that the contents in this Manual be consistent with the information you acquire. -
Page 15: Main Menu
www.giadatech.com 1. Main menu can press DEL to enter the BIOS interface if no error is found. If the indicative information disappears before you can act, you can shut off the computer and When the system enters the CMOS Setup menu, you can see the main menu turn on it again, or you can press the key RESET on the machine case. -
Page 16: Main (Standard Bios Setup)
www.giadatech.com · Exit (option of exit) 3. Advanced (Advanced BIOS setup) This item includes load optimal defaults/load failsafe defaults value/discard changes/ discard changes and exit. 2. Main (standard CMOS setup) Fig 3.3 4. Boot Configuration Fig 3.2 · System time (hh:mm:ss) Use this item to set the time for the computer, with the format as “hour/minute/second”. -
Page 17: Security Setup
www.giadatech.com · · Interrupt 19 Capture [Disabled] Quiet Boot To start the system quietly. If you use some PCI extension cards with built-in firmware program (like · Add On ROM Display Mode [Force BIOS] SCSI extension card) and you want to start the system through Interrupt 19, This item allows you to set the display mode of the device’s firmware you can set this item as [Enabled]. -
Page 18: Exit
www.giadatech.com If this function is selected, the following information will appear: 6. Exit Enter New Password hhhhhh Then, enter the password with not more than eight characters and press <Enter>. BIOS will requires to enter the password again. Once you enter it again, BIOS will save the set password. -
Page 19: Software Installation
www.giadatech.com IV. Software installation NOTE：Pictures below just showing the driver install steps, please see the real In Fig 4.1, click "Driver ", another UI appears as shown in Fig 4.2. product for detailed information. 1. Install driver for motherboard After you complete the installation of the operating system, you should then install the driver for the motherboard. -
Page 20: Install Driver For Chipset
www.giadatech.com 1.1. Installing driver for Chipset 1.2 Install Sound card driver After you click “Install” behind the “Intel Chipset driver” in the interface of After you click “Install” behind the “Realtek HD audio driver” in the interface of Fig. 4.2, a dialog box as shown in Fig. 4.3 will pop up. Then you can click Next Fig. - Page 21 www.giadatech.com 1.3 Installing driver for on-board LAN chip 1.4 Installing driver for graphic card After you click “Install” behind the “Realtek 10/100/1000 LAN Driver” in the To install the driver for graphic card, you can click “Install” behind “XXX VGA interface of Fig.
- Page 22 www.giadatech.com After the initial installation of the driver, the default state of microphone is 2. HD-AUDIO sound card setup mute. You need to turn it on manually, as shown in Fig. 4.8 and 4.9. · For Windows XP SP2: The control panel of the audio adapter will appear after the driver is installed, as shown in Fig.
- Page 23 www.giadatech.com For Windows Vista: For Windows Vista: After the driver for the audio adapter is installed, you can click the Audio Manager In accordance with the sound card driver finished, in the lower at the lower right corner. The initial interface will pop up, as shown in Fig. 4.11 screen interface feet click on the audio manager, pop-up initial and 4.12.
- Page 24 www.giadatech.com Click the right upper part of the control interface—Advanced Setup for Device, If a MIC is used, please select the corresponding front or rear mode and set the the interface shown in Fig. 4.12 will pop up. Then select “separate all input jacks device as default.
- Page 25 www.giadatech.com Select Redistribution of Connectors. Then an interface will pop up, as Changes or modifications not expressly approved by the party responsible for shown in Fig. 4.15. After that, set the corresponding output. compliance could void the user's authority to operate the equipment NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
